EN 15102:2007+A1:2011

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Dekorative Wandbekleidungen - Rollen- und PlattenformRevêtements muraux décoratifs - Rouleaux et panneauxDecorative wall coverings - Roll and panel form91.180Interior finishingICS:Ta slovenski standard je istoveten z:EN 15102:2007+A1:2011SIST EN 15102:2008+A1:2011en,fr,de01-november-2011SIST EN 15102:2008+A1:2011SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 15102:2007+A1
September 2011 ICS 91.180 Supersedes EN 15102:2007English Version
Decorative wall coverings - Roll and panel form
Revêtements muraux décoratifs - Rouleaux et panneaux
Dekorative Wandbekleidungen - Rollen- und Plattenform This European Standard was approved by CEN on 23 September 2007 and includes Amendment 1 approved by CEN on 4 August 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2011 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 15102:2007+A1:2011: ESIST EN 15102:2008+A1:2011

Factory production control . 12A.1General . 12A.2General requirements . 12A.3Equipment . 13A.3.1Testing . 13A.3.2Manufacturing . 13A.4Raw materials . 13A.5Product testing and evaluation . 13A.6Non-conforming products . 14A.7Traceability . 14A.8!Initial inspection of factory and of FPC . 14A.9Continuous surveillance of FPC" . 15Annex B (normative)
!Extended application rules within a group of product for the reaction to fire tests . 16B.1Sampling . 16B.2Product parameter having an influence on the product's fire performance of wall coverings . 16B.3End-use application parameters . 16B.4Tests conducted according to EN 13823 intended for an extended application . 17B.4.1Investigation of a group of product on different parameters . 17B.4.2Usage of the test results obtained during the first step . 17B.5Tests conducted according to EN ISO 11925-2 intended for an extended application . 17B.5.1Investigation of a group of product on different parameters . 17B.5.2Usage of the test results obtained during the first step" . 17Annex ZA (informative)
Relationship between this European Standard and the Essential Requirements of EU Directive 89/106/EEC, EU Construction Products Directive . 19ZA.1Scope and relevant characteristics . 19SIST EN 15102:2008+A1:2011

1 Scope This European Standard applies to all forms of wallcovering products in roll and panel form as defined in
EN 235 supplied for hanging onto internal walls, partitions or ceilings, by means of an adhesive, whose primary purpose is decorative. However, certain wallcovering products may confer minor sound absorbtion and thermal resistance properties. It also provides for the evaluation of conformity of products to the requirements of this standard. It does not apply to wall coverings whose primary purpose is structural or protective (e.g. vapour or moisture barriers). 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 71-3:1994, Safety of toys — Part 3: Migration of certain elements EN 12149:1997, Wallcoverings in roll form — Determination of migration of heavy metals and certain other elements, of vinyl chloride monomer and of formaldehyde release EN 12524, Building materials and products — Hygrothermal properties — Tabulated design values EN 12667, Thermal performance of building materials and products — Determination of thermal resistance by means of guarded hot plate and heat flow meter methods — Products of high and medium thermal resistance EN 12781:2001, Wallcoverings — Specification for cork panels EN 13085:2001, Wallcoverings — Specification for cork rolls EN 13238, Reaction to fire tests for building products — Conditioning procedures and general rules for selection of substrates EN 13501-1, Fire classification of construction products and building elements — Part 1: Classification using data from reaction to fire tests !EN 13823, Reaction to fire tests for building products — Building products excluding floorings exposed to the thermal attack by a single burning item" EN ISO 354, Acoustics — Measurement of sound absorption in a reverberation room (ISO 354:2003) EN ISO 9001:2000, Quality management systems — Requirements (ISO 9001:2000) EN ISO 11654, Acoustics — Sound absorbers for use in buildings — Rating of sound absorption
(ISO 11654:1997) SIST EN 15102:2008+A1:2011

1) Table is the same as given in the Decision of the Commission 2010/82/EU of 2010-02-09 (see OJEU L38 of 2010-02-11). SIST EN 15102:2008+A1:2011

Class F may be declared, which is an equivalent to "No Performance Determined" (NPD) for this characteristic, when use of wall covering product is not subject to the national regulatory requirements on reaction to fire. Table 1 — Classes of reaction to fire performance for decorative wall coverings in roll and panel form Product a Maximum mass per unit area (g/m2) Maximum thickness (mm) Class b Wallcoverings on cellulose fibre base 190 0,9 D-s3, d2 Wallcoverings on cellulose fibre base and polymer coated or printed 470 0,7 Wallcoverings on a mixture of cellulose and polyester fibre base 160 0,3 Wallcoverings on a mixture of cellulose and polyester fibre base and polymer coated or printed 410 0,5 Wallcoverings on polymer coated fabric base 510 0,7 Wallcoverings of woven textile with a backing consisting of cellulose fibre or cellulose and polyester fibre 450 0,8 Wallcoverings of foamed PVC with a backing consisting of cellulose fibre or cellulose and polyester fibre 310 1,8 a Products in accordance with EN 15102 mounted on a substrate of at least class A2-s1,d0 with a minimum thickness 12 mm and with minimum density 800 kg/m3 using starch, or starch/PVA, or cellulose/PVA adhesive applied at a maximum 200 g/m2. b Class as provided for in Table 1 of the Annex to Commission Decision 2000/147/EC. When option b) is applied and where required by the test methods, the wallcovering product shall be tested in its end use conditions according to Annex B. In this case, the class declared shall be followed also by the associated mounting and fixing conditions (only if relevant for this class)." 4.2 Release of formaldehyde The release of formaldehyde from the wallcovering product shall be declared when subject to regulatory requirement and may be declared otherwise. The formaldehyde release, when tested in accordance with
Test C of EN 12149:1997 (as modified in Annex A of EN 12781:2001 or EN 13085:2001 for cork wallcovering products in panel form and roll form respectively) shall not exceed 120 mg/kg of wallcovering. If no formaldehyde or products containing formaldehyde are added during the manufacturing process of the wallcovering product, and the raw materials are declared by the supplier to contain less than 120 mg/kg of formaldehyde, then testing is not necessary. 4.3 !Release of other dangerous substances" 4.3.1 Heavy metals and specific elements 4.3.1.1 Requirements The migration of heavy metals and specific elements from the wallcovering product, expressed as mg/kg of wallcovering, shall not exceed the values given in !Table 2" (after correction according to 4.3.1.2) when measured in accordance with Test A of EN 12149:1997. If none of these substances are added during the SIST EN 15102:2008+A1:2011

Antimony Sb No upper limit Arsenic As 25 Barium Ba 500 Cadmium Cd 25 Chromium Cr 60 Lead Pb 90 Mercury Hg 20 Selenium Se 165
!Table 3" — Analytical correction factor Element Sb As Ba Cd Cr Pb Hg Se Analytical correction factor (in percentage) 60 60 30 30 30 30 50 60
Although no direct testing of reaction to fire is needed for CWFT products, indirect testing of product parameters can be necessary to ensure that the product meets the definition required for CWFT status. NOTE 2
Three specimens, each sample from a separate unit, with units selected according to the procedure of 5.2.2.1. " SIST EN 15102:2008+A1:2011

Factory production control A.1 General The manufacturer shall establish, document and maintain a factory production control (FPC) system to ensure that the subsequent wallcovering products placed on the market conform to the declared performance characteristics. The FPC system shall consist of procedures, regular inspections and tests and/or assessments and the use of the results to control raw and other incoming materials or components, equipment, the production process and the product. All the elements, requirements and provisions adopted by the manufacturer shall be documented in a systematic manner in the form of written policies and procedures. This production control system documentation shall ensure a common understanding of the conformity evaluation and enable the achievement of the required product characteristics and the effective operation of the production control system to be checked. Factory production control therefore brings together operational techniques and all measures allowing maintenance and control of the conformity of the product with its technical specifications. Its implementation may be achieved by controls and tests on measuring equipment, raw materials, processes, machines and manufacturing equipment and finished product, and by making use of the results thus obtained. A.2 General requirements As a minimum, the FPC system shall fulfil the requirements as described in the following clauses of EN ISO 9001:2000, where applicable: – 4.2 (except 4.2.1 a)), – 5.1e), 5.5.1, 5.5.2, – Clause 6, – 7.1 (except 7.1 a)), 7.2.3 c), 7.4, 7.5, 7.6, – 8.2.3, 8.2.4, 8.3, 8.5.2. The FPC system shall: – be made specific to the products covered by this European Standard, and – ensure that the products placed on the market conform to the declared performance characteristics. The FPC system may be part of
...
