EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 12697-24July 2004ICS 93.080.20English versionBituminous mixtures - Test methods for hot mix asphalt - Part24: Resistance to fatigueMélanges bitumineux - Méthodes d'essai pour enrobés àchaud - Partie 24: Résistance à la fatigueAsphalt - Prüfverfahren für Heißasphalt - Teil 24:Beständigkeit gegen ErmüdungThis European Standard was approved by CEN on 2 March 2004.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2004 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 12697-24:2004: E

Two-point bending test on trapezoidal shaped specimens.22 A.1 Principle.22 A.1.1 General.22 A.1.2 Element test.22 A.1.3 Fatigue line.23 A.2 Equipment.23 A.2.1 Test machine.23 A.2.2 Thermostatic chamber.23 A.2.3 Measuring equipment.24 A.3 Specimen preparation.24 A.3.1 Sawing and storing.24 A.3.2 Characteristics of the specimens.25 A.3.3 Embedding Check.25 A.3.4 Stabilisation of the specimens.26 A.3.5 Gluing the ends.26 A.4 Procedure.27 A.4.1 Preparing the test equipment.27 A.4.2 Carrying out the fatigue test.27 A.4.3 Choice of the strain.27 A.4.4 Number of element tests.28 A.5 Calculation and expression of results.28 A.6 Test report.30 A.7 Precision.30 Annex B (normative)
Two-point bending test on prismatic shaped specimens.31 B.1 Principle.31

Three-point bending test on prismatic shaped specimens.37 C.1 Principle.37 C.1.1 General.37 C.1.2 Element test.37 C.1.3 Fatigue line.37 C.2 Equipment.37 C.2.1 Test machine.37 C.2.2 Load cell.37 C.2.3 Extensometer and displacement sensor.37 C.2.4 Clamping device.38 C.2.5 Data acquisition equipment.38 C.2.6 Thermostatic chamber.38 C.2.7 Other general equipment.38 C.2.8 Check on the operation of the complete equipment and the mounting of the specimen.38 C.3 Specimen preparation.38 C.3.1 Manufacturing and sawing.38 C.3.2 Bulk density.38 C.3.3 Storing.38 C.3.4 Clamping devices preparation.39 C.4 Procedure.39 C.4.1 Preparing the test equipment.39 C.4.2 Carrying out the fatigue test.39 C.4.3 Load function, extensometer signal function, and displacement function recording.39 C.4.4 End of test.40 C.5 Calculation and expression of results.40 C.5.1 Calculation of the stress function and the strain function at a cycle.40 C.5.2 Calculation of the dynamic modulus, phase difference angle, and density of dissipated energy at one cycle.41 C.5.3 Determination of the fatigue law and energy law.42 C.6 Test report.43 C.7 Precision.43 Annex D (normative)
Four-point bending test on prismatic shaped specimens.44 D.1 Principle.44 D.1.1 General.44 D.1.2 Element test.44 D.1.3 Fatigue line.45 D.2 Equipment.46 D.2.1 Test machine.46 D.2.2 Clamping device.46 D.2.3 Thermostatic chamber.46 D.2.4 Electronic data registration equipment.46 D.2.5 Check on the operation of the complete equipment and the mounting of the specimen.47

Indirect tensile test on cylindrical shaped specimens.52 E.1 Principle.52 E.2 Equipment.52 E.2.1 Test machine.52 E.2.2 Loading.52 E.2.3 Displacement.52 E.2.4 Thermostatic chamber.52 E.2.5 Recording and measuring system.52 E.2.6 Loading frame.53 E.2.7 Positioning rig.54 E.2.8 Glue.54 E.3 Specimen preparation.55 E.3.1 Test specimen.55 E.3.2 Specimen dimensions.55 E.3.3 Position of the deformation and loading strips.55 E.3.4 Conditioning.55 E.4 Procedure.56 E.5 Calculation and reporting of results.56 E.6 Test report.59 E.7 Precision.59 Bibliography.60

1 Scope This document specifies the methods for characterising the fatigue of bituminous mixtures by alternative tests, including bending tests and direct and indirect tensile tests. The tests are performed on compacted bituminous material under a sinusoidal loading or other controlled loading, using different types of specimens and supports. The procedure is used to rank bituminous mixtures on the basis of resistance to fatigue, as a guide to relative performance in the pavement, to obtain data for estimating the structural behaviour in the road and to judge test data according to specifications for bituminous mixtures. Because this document does not impose a particular type of testing device, the precise choice of the test conditions depends on the possibilities and the working range of the used device. For the choice of specific test conditions, the requirements of the product standards for bituminous mixtures shall be respected. The applicability of this document is described in the product standards for bituminous mixtures. Results obtained from different test methods are not assured to be comparable. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 12697-6, Bituminous mixtures — Test methods for hot mix asphalt — Part 6: Determination of bulk density of bituminous specimen. EN 12697-26, Bituminous mixtures — Test methods for hot mix asphalt — Part 26: Stiffness. EN 12697-27, Bituminous mixtures — Test methods for hot mix asphalt — Part 27: Sampling. EN 12697-29, Bituminous mixtures — Test methods for hot mix asphalt — Part 29: Determination of the dimensions of bituminous specimen. EN 12697-31, Bituminous mixtures — Test methods for hot mix asphalt — Part 31: Specimen preparation, gyratory compactor. EN 12967-33, Bituminous mixtures — Test methods for hot mix asphalt — Part 33: Specimen preparation by roller compactor. 3 Terms, definitions, symbols and abbreviations For the purposes of this document, the following terms and definitions, symbols and abbreviations apply. 3.1 General 3.1.1 fatigue reduction of strength of a material under repeated loading when compared to the strength under a single load 3.1.2 conventional criteria of failure (constant displacement) number of load applications, Nf/50, when the complex stiffness modulus has decreased to half its initial value

EN 12697-26); bi is the base, in millimetre (mm); hi is the height, in millimetre (mm); ei is the width, in millimetre (mm). 3.3.4 Symbols The symbols are as follows, with a strain of 1 microstrain (µstrain) being equal to 10–6 by convention: 3.3.4.1 Sample i hI is the height, in millimetres (mm) bI is (A) small base or (B) base, in millimetres (mm) eI is the thickness, in millimetres (mm) mI is the mass, in grams (g) vi% is the vacuum achieved by the geometric method as a proportion of atmospheric pressure, in per cent (%) Kσi is the constant for consideration of the geometry of specimen at constant strength, in inverse millimetres (mm–1) 3.3.4.2 Strength at head and greatest tension at specimen i at level of tension εj max Pij is the amplitude of the strength with which the head is applied, in Newtons (N) σj max is the greatest relative tension of the specimen, corresponding to the strength, with which the head is applied 3.3.4.3 Fatigue life of a specimen i at the level of tension σj max Nij is the fatigue life. 3.3.4.4 Fatigue life relative to sample i at the strain level εj Nij is the conventional fatigue life. 3.3.4.5 Fatigue line pσ
is the slope of fatigue line ln(σj max) = f (ln(Nij)) 6σˆ is the tension corresponding with 106 cycles, in megapascals (MPa) yxσs is the estimation of the residual standard deviation of the natural logarithms of fatigue lives 6σ∆ˆ is the confidence of 6σˆfor a probability of 95 %

is the phase angle of the approximate strain function, in radians (rad) Dc is the displacement at instant t, in microns (µm) 2D0 is the total amplitude of displacement function, in microns (µm) DDE is the density of dissipated energy, in megapascals (MPa) or megajoules per cubic metre (MJ/m3) DE(total) is the total density of dissipated energy throughout the whole test, in megajoules per cubic metre (MJ/m3) DDE (x)
is the density of dissipated energy at cycle x, in megajoules per cubic metre (MJ/m3) EXT is the instant extensometer signal, in millimetres (mm) L is the distance between supports, in millimetres (mm) MD is the dynamic modulus, in megapascals (MPa) N is the number of cycle at end of test P is the instant load, in megapascals (MPa) W is the total density of dissipated energy throughout the whole test, in megajoules per cubic metre (MJ/m3) b is the width of specimen, in millimetres (mm) e is the thickness of specimen, in millimetres (mm)

is the instant stress, in megapascals (MPa) σ a is the approximate stress function value, in megapascals (MPa) σ c is the cyclic amplitude of stress function, in megapascals (MPa) Φ is the phase difference angle, in degrees (°) 3.5 Four-point bending test on prismatic shaped specimens 3.5.1 (complex) stiffness modulus ratio S = Smix,n × eiφ of the calculated stress and strain during cycle n in the specimen NOTE The stiffness modulus defines the relationship between stress and strain for a linear viscoelastic material subjected to sinusoidal loading. 3.5.2 initial (complex) stiffness modulus values for the initial modulus Smix,0 in megapascals (MPa) of the complex modulus and for the initial phase lag φo in degrees of
the complex modulus taken at the 100th load application 3.5.3 fatigue life Ni,j,k number of cycles for specimen i, corresponding with the chosen failure criteria j (e.g. conventional failure j = f/50) at the set of test conditions k (temperature, frequency and loading mode; e.g. constant deflection level, or constant force level, and or any other constant loading condition) 3.5.4 test condition k set of conditions at which a specimen is tested. This set contains the applied frequency f0, the test temperature Θ and the loading mode (constant deflection, or constant force, and or constant dissipated energy per cycle) 3.5.5 average fatigue life of a series of specimens value defined according to a failure criteria j on a series of m specimens at a test condition k given by: mNeN∑==mi)kj,i,(lnk,J1 (7)
