This European Standard specifies requirements and gives recommendations for the design, materials, construction, testing, operation, maintenance and abandonment of pipeline systems used for transportation in the petroleum and natural gas industries.
It applies to pipeline systems on land (see exclusion below) and offshore, connecting wells, production plants, process plants, refineries and storage facilities, including any section of a pipeline constructed within the boundaries of such facilities for the purpose of its connection. The extent of pipeline systems covered by this European Standard is illustrated in Figure 1.
This European Standard applies to rigid, metallic pipelines. It is not applicable for flexible pipelines or those constructed from other materials, such as glass-reinforced plastics.
This European Standard is applicable to all new pipeline systems and can be applied to modifications made to existing ones. It is not intended that it apply retroactively to existing pipeline systems.
It describes the functional requirements of pipeline systems and provides a basis for their safe design, construction, testing, operation, maintenance and abandonment.
On-land supply systems used by the European gas supply industry from the input of gas into the on-land transmission network up to the inlet connection of gas appliances are excluded from the scope of this European Standard.
Erdöl- und Erdgasindustrie - Rohrleitungstransportsysteme (ISO 13623:2009 modifiziert)
!Diese Europäische Norm legt Anforderungen fest und enthält Empfehlungen hinsichtlich Konstruktion, Werkstoffen, Bauausführung, Prüfung, Betrieb, Instandhaltung und Stilllegung (Aufgabe) von Rohrleitungs-systemen, die in der Erdöl- und Erdgasindustrie für Transportzwecke verwendet werden.
Sie gilt für Rohrleitungssysteme an Land (siehe nachstehende Ausnahme) und Offshore, bei Anschlussbohrungen, in Produktionsanlagen, Prozessanlagen, Raffinerien und für Speichereinheiten, einschließlich aller Rohrleitungsabschnitte, die innerhalb solcher Einrichtungen zu deren Verbindung verwendet werden. Der Umfang der in dieser Europäischen Norm behandelten Rohrleitungssysteme ist in Bild 1 dargestellt.
Diese Europäische Norm gilt für starre Rohrleitungen aus Metall. Sie gilt nicht für flexible Rohrleitungen oder Rohr¬leitungen aus anderen Werkstoffen, z. B. glasfaserverstärkte Kunststoffe.
Diese Europäische Norm gilt für alle neuen Rohrleitungssysteme und kann für die an den vorhandenen Rohrleitungssystemen durchgeführten Änderungen angewendet werden. Eine rückwirkende Anwendung auf vorhandene Rohrleitungssysteme ist nicht beabsichtigt.
Sie beschreibt die funktionellen Anforderungen an Rohrleitungssysteme und dient als Grundlage für deren sichere Konstruktion, Bauausführung, Prüfung, Betrieb, Instandhaltung und Stilllegung (Aufgabe).
Versorgungssysteme an Land, die von der Europäischen Gasversorgungsindustrie benutzt werden, sind vom Anwendungsbereich dieser Norm ausgeschlossen, ausgenommen von der Einspeisung des Erdgases in die Rohrleitungstransportsysteme an Land bis zum Eingangsanschluss gasbetriebener Endgeräte."
