European foreword
This document (prEN 4869-001:2023) has been prepared by the Aerospace and Defence Industries
Association of Europe — Standardization (ASD-STAN).
After enquiries and votes carried out in accordance with the rules of this Association, this document has
received the approval of the National Associations and the Official Services of the member countries of
ASD, prior to its presentation to CEN.
This document is currently submitted to the CEN Enquiry.
oSIST prEN 4869-001:2023
prEN 4869-001:2023 (E)
Introduction
The family of connectors used on this standard are in accordance with EN 3645-001. The optical
termini, which are using the expanded beam technology, are specially adapted to the cavities of this
kind of connectors. It is particularly suitable for use in zones of severe environmental conditions on
board aircraft, applying EN 2282.
oSIST prEN 4869-001:2023
prEN 4869-001:2023 (E)
1 Scope
This document specifies the general characteristics, the conditions for qualification, acceptance and
quality assurance, as well as the test programs and groups for threaded ring coupling circular
connectors with expanded beam termini, intended for use in a temperature range from −55 °C to 125 °C
continuous.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
EN 2591-100, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 100: General
EN 2591-101, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 101: Visual examination
EN 2591-102, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 102: Examination of dimensions and mass
EN 2591-302, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 302: Climatic sequence
EN 2591-304, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 304: Damp heat steady state
EN 2591-308, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 308: Sand and dust
EN 2591-311, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 311: Low air pressure
EN 2591-312, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 312: Air leakage
EN 2591-315, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 315: Fluid resistance
EN 2591-403, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 403: Sinusoidal and random vibration
EN 2591-407, Aerospace series — Elements of electrical and optical connection — Test methods —
Part 407: Dura
...
