TECHNICAL SPECIFICATION
CEN ISO/TS 17892-11
SPÉCIFICATION TECHNIQUE
TECHNISCHE SPEZIFIKATION
October 2004
ICS 13.080.20; 93.020
English version
Geotechnical investigation and testing - Laboratory testing of
soil - Part 11: Determination of permeability by constant and
falling head (ISO/TS 17892-11:2004)
Reconnaissance et essais géotechniques - Essais de sol Geotechnische Erkundung und Untersuchung -
au laboratoire - Partie 11: Détermination de la perméabilité Laborversuche an Bodenproben - Teil 11: Bestimmung der
au perméamètre à charge constante ou variable (ISO/TS Durchlässigkeit mit konstanter und fallender Druckhöhe
17892-11:2004) (ISO/TS 17892-11:2004)
This Technical Specification (CEN/TS) was approved by CEN on 2 December 2003 for provisional application.
The period of validity of this CEN/TS is limited initially to three years. After two years the members of CEN will be requested to submit their
comments, particularly on the question whether the CEN/TS can be converted into a European Standard.
CEN members are required to announce the existence of this CEN/TS in the same way as for an EN and to make the CEN/TS available
promptly at national level in an appropriate form. It is permissible to keep conflicting national standards in force (in parallel to the CEN/TS)
until the final decision about the possible conversion of the CEN/TS into an EN is reached.
CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,
Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,
Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: rue de Stassart, 36  B-1050 Brussels
© 2004 CEN All rights of exploitation in any form and by any means reserved Ref. No. CEN ISO/TS 17892-11:2004: E
worldwide for CEN national Members.

Contents Page
Foreword.3
1 Scope .5
2 Normative references .5
3 Terms and definitions .5
4 Test procedure.6
4.1 General requirements.6
4.1.1 Grading, particle structure and volume .6
4.1.2 Properties of water .6
4.1.3 Degree of saturation.6
4.2 Falling head .12
4.2.1 Apparatus .12
4.2.2 Test arrangement.13
4.2.3 Soil type and specimen dimensions.13
4.3 Constant head test in the permeameter .14
4.3.1 Apparatus .14
4.3.2 Test arrangement.14
4.3.3 Soil type and specimen dimensions.14
4.4 Constant head testing in the triaxial cell.15
4.4.1 Apparatus (see Figure 2).15
4.4.2 Test arrangement.16
4.4.3 Preparation of apparatus .16
5 Test results.17
5.1 Falling head .17
5.2 Constant head.18
5.3 Permeability in the triaxial cell .18
Bibliography .20
Figures
Figure 1 — Water flow in a soil specimen.6
Figure 2 — Example for test arrangement for triaxial cell test .7
Figure 3 — Example for a test arrangement for constant head permeameter test.9
Figure 4 — Example for a test arrangement for compression permeameter test.10
Figure 5 — Apparatus for enclosing a specimen in a rubber membrane .11
Tables
Table 1 — Back pressure as function of initial saturation .7
Table 2 — Correction factor αα to allow for the viscosity of water .8
αα
Table 3 — Classes of permeability tests .12
Table 4 — Example for test arrangement as a function of soil type .12

Foreword
This document (CEN ISO/TS 17892-11:2004) has been prepared by Technical Committee CEN/TC 341
“Geotechnical investigation and testing”, the secretariat of which is held by DIN, in collaboration with Technical
Committee ISO/TC 182 “Geotechnics”.
According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following
countries are bound to announce this Technical Specification: Austria, Belgium, Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta,
Netherlands, Norway, Poland, Portugal, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
CEN ISO/TS 17892 consists of the following parts, under the general title Geotechnical investigation and testing —
Laboratory testing of soil:
 Part 1: Determination of water content
 Part 2: Determination of density of fine grained soil
 Part 3: Determination of particle density - Pycnometer method
 Part 4: Determination of particle size distribution
 Part 5: Incremental loading oedometer test
 Part 6: Fall cone test
 Part 7: Unconfined compression test on fine grain soils
 Part 8: Unconsolidated undrained triaxial test
 Part 9: Consolidated triaxial compression tests on water saturated soils
 Part 10: Direct shear tests
 Part 11: Determination of permeability by constant and falling head
 Part 12: Determination of the Atterberg limits
Introduction
This document covers areas in the international field of geotechnical engineering never previously standardised. It
is intended that this document presents broad good practice throughout the world and significant differences with
national documents is not anticipated. It is based on international practice (see [1]).
1 Scope
This document is intended for use in earthworks and foundation engineering. It specifies laboratory test methods to
establish the coefficient of permeability of water through water-saturated soils. In the proposed laboratory tests soil
specimens are subjected to a flow of water passing through the specimen. The water pressure conditions and
volume of water passing through the specimens are measured for evaluation of the permeability.
The results obtained serve to calculate groundwater flow and to assess the permeability of man-made impervious
layers and filter layers.
2 Normative references
The following referenced document is indispensable for the application of this document. For dated references,
only the edition cited applies. For undated references, the latest edition of the referenced document (including any
amendments) applies.
prEN 1997-2, Eurocode 7 - Geotechnical design — Part 2: Ground investigation and testing.
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1
flow rate
Q
quantity of water passing through a specimen per unit time, t
3.2
discharge velocity
v
rate of flow of water per unit area of soil (including particles and voids) normal to the direction of flow
3.3
hydraulic gradient
i
ratio of the difference in total head of water (head loss), h, between two gland points, to the length of the flow path,
l (distance between the gland points measured in the direction of flow, see Figure 1)
Key
1 Standpipe head
2 Standpipe
3 Filter block
4 Filter block
5 Specimen
Figure 1 — Water flow in a soil specimen
3.4
undisturbed sample
normally a sample of quality class 1 or at least 2 according to prEN 1997-2
3.5
coefficient of permeability
k
in accordance with Darcy's law for laminar flow, the coefficient of permeability of a water-saturated soil, k, is the
ratio of the discharge velocity, v, to the hydraulic gradient, i
NOTE  For partly saturated soil, the coefficient of permeability is always smaller than for fully water-saturated soil due to
turbulence caused by air voids and non-function of .capillary action.
4 Test procedure
4.1 General requirements
4.1.1 Grading, particle structure and volume
Grading and particle structure shall not alter while measuring the permeability. Consolidation and swelling should
substantially be completed before the measurements are done.
In clay swelling and consolidation cannot completely be avoided unless provisions are made to prevent it.
Therefore, the height of the specimen should be locked or the load regulated to prevent changes in height. The
height of the specimen should be recorded and any significant change in height should be accounted for, both in
terms of expelled water and in change of seepage path.
4.1.2 Properties of water
The water used for testing shall not wash out constituents of the specimen, deposit any dissolved or suspended
matter in it or alterthe colloidal state of the soil.
As far as possible, water similar in type to the pore water shall be used, de-aired tap water generally being
adequate. Where necessary (e.g. where marine sediments are to be tested), the water shall be treated or obtained
from a given source so that the natural conditions can be reliably reproduced.
4.1.3 Degree of saturation
4.1.3.1 The specimen shall remain saturated during the measurement of the permeability.
4.1.3.2 Saturation of the specimen can be achieved by applying a back pressure u (as specified in Table 1),
which is produced by subjecting the pore water in the specimen to a hydrostatic pressure which shall be
maintained throughout the test. This may be accomplished using the test arrangement shown in Figure 2.
Table 1 — Back pressure as function of initial saturation
Initial saturation Back pressure
S u
r 0
% kN/m
100 0
95 300
90 600
85 900
Key
9 Pressure gauge
1 Top plate
10 Burette to determine the quantity of inflowing water
2 Cell top with spiral groove
11 Vessel containing pressurized de-aired water
3 Filter block with k greater than or equal to ten times that of
12 Supply of de-aired water
the specimen
13 Inlet for cell water and cell pressure, σ
4 Specimen
14 Valve
5 Rubber membrane with O-rings
15 Piston for applying anisotropic load to the specimen
6 Pedestal
l Specimen height (= length of seepage path)
7 Glass tube with vent opening less than 1 mm in diameter 0
8 Graduated glass cylinder or volume change sensor p Pressure to produce hydraulic gradient
In tests with back pressure, the pressure in the vent opening (7) should be raised to correspond to the back-pressure u and the
pressure p raised to p + u .
Figure 2 — Example for test arrangement for triaxial cell test
At full saturation, the quantities of water entering and leaving a specimen shall be equal, with constant pressure
and constant hydraulic gradient being assumed.
Disturbed specimens are normally not fully saturated with water, the same applying to specimens in which the pore
water pressure dropped as the specimen was taken, thus releasing dissolved gas. Air dissolved in the water
passing through the specimen may be retained in the specimen and thus reduce the latter's permeability.
There are also other methods to saturate specimens. It can be done e.g. by flushing the specimen with water or by
replacing the air in the dry specimen by CO before filling the specimen with water. Bubbles of CO can more easily
2 2
be solved in water.
4.1.4 Hydraulic gradient
For testing purposes, the hydraulic gradient may be selected to satisfy practical considerations as long as the flow
characteristics given by the gradient complies with Darcy's law. In case of doubt whether the test conditions comply
with Darcy's law the hydraulic gradient has to be varied to check it. Where the flow is not linear, the hydraulic
gradient in the laboratory shall approximate that in the field.
NOTE The flow behaviour of coarse-grained soil deviates from laminar flow as described by Darcy's law, if the hydraulic
gradient exceeds a certain level, i.e. the discharge velocity increases non-linearly with increasing hydraulic gradient due to the
influence of inertial forces. For fine-grained soil the discharge velocity decreases non-linearly with decreasing hydraulic gradient
when passing a certain lower level.
4.1.5 Temperature
4.1.5.1 Testing shall be carried out at approximately constant ambient temperature (± 2 °C), with which the
temperature of the specimen and water shall be in equilibrium. The temperature shall be measured and recorded.
4.1.5.2 To obtain reproducible results, the value of k as determined in the test shall be converted to a
reference temperature of 10 °C using the following empirical equation (1) from Poiseuille:
k = α × k (1)
T
1,359
α = (2)
1+ 0,0337 ×T + 0,00022×T
where
T is the water temperature (°C) throughout the test;
k is the coefficient of permeability at ambient temperature (m/s);
T
α is a correction factor, to be calculated or taken from Table 2. For intermediate values linear interpolation is
allowed.
A reference temperature of 10 °C equals the average temperature of groundwater. A different temperature may be
used where required.
Table 2 — Correction factor α to allow for the viscosity of water
Temperature T
5 10 15 20 25
[°C]
Correction factor
1,158 1,000 0,874 0,771 0,686
α [–]
4.1.6 Specimen dimensions
4.1.6.1 Specimen diameter and height shall be selected so as to prevent any inhomogeneities influencing the
test results.
4.1.6.2 The ratio of maximum particle size to specimen diameter or length shall be not less than 1 : 5 for
non-uniform and 1 : 10 for uniform soils.
4.1.6.3 For cohesive (fine-grained) soil, the cross-sectional area of the specimen A shall be not less than
2 2
1000 mm and for coarse-grained soil, not less than 2000 mm , unless the test equipment requires the use of
larger specimens (see 4.4.4).
4.1.7 Measurement of standpipe heads
4.1.7.1 For permeable to highly permeable soil specimens, the difference in head shall not be measured
between the specimen ends but only across the length of that part of the specimen through which the water is
flowing (see Figure 3), in order to prevent any loss of head and to prevent the result being affected by interference
effects at the specimen ends.
Key
1 Inlet for de-aired water
9 Graduated scale
2 Pinch cock or ball valve
10 Graduated cylinder
3 Inlet reservoir
11 Cell
4 Outlet reservoir
h Difference in piezometric heads
5 Filter
h Difference in head in inlet and outlet reservoirs
w
6 Perforated plate with wire gauze
l Length of seepage path
7 Specimen
l Specimen height
8 Piezometric tubes 0
Figure 3 — Example for a test arrangement for constant head permeameter test
4.1.7.2 Standpipes (piezometric tubes) shall have an internal diameter of 3 mm to 4 mm and be located at a
minimum of 15 mm from the top and bottom ends of the specimen. The end of the tube entering the specimen shall
be protected by a wire gauze against blockage. In the case of soil with low permeability, the loss of head between
the standpipes and cell is small enough to be ignored so that the difference in head between inlet and outlet may
be regarded as being equal to the difference in head across the specimen.
4.1.8 Measurement of water flow
4.1.8.1 The quantity of water flowing through the specimen shall be measured at steady-state flow conditions.
4.1.8.2 In constant head tests with large quantities of water passing through the specimen, the overflow at the
outlet end shall be measured.
4.1.8.3 Where the quantities of water passing through the specimen are small, measurement shall be carried
out using piezometric tubes (see Figure 4) or capillary tubes, due consideration being given to the possibility of
evaporation falsifying the results. This may be avoided by increasing the hydraulic gradient, provided this is not
inconsistent with the other conditions described in 4.1.4.
Key
1 Inlet for de-aired water
2 Detachable piezometric tube of cross-
sectional area a
3 Three-way cock
4 Rubber seal
5 Filter blocks
6 Specimen holder
7 Specimen with height l
8 Top plate
9 Device to apply vertical load, with
compression gauge
10 Container (with overflow to produce
constant head)
h Water head at start of measurement
h Water head at time t
Figure 4 — Example for a test arrangement for compression permeameter test
4.1.8.4 In falling head tests, the volume of water passing through the specimen is equal to the internal volume
of the standpipe as defined by the difference in level of two consecutive readings.
NOTE  The water flow can be regarded as steady if, at a constant head, the quantity of water entering the specimen and that
leaving it per unit time remains constant.
4.1.9 Prevention of bypass seepage
4.1.9.1 Bypass seepage due to small stones and other foreign matter embedded in specimens and cavities
between the specimen and the wall of the cell or test mould shall be prevented as it suggests a higher permeability
than
...
