EN 13476-3:2007

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Plastics piping systems for non-pressure underground drainage and sewerage - Structured-wall piping systems of unplasticized poly(vinyl chloride) (PVC-U), polypropylene (PP) and polyethylene (PE) - Part 3: Specifications for pipes and fittings with smooth internal and profiled external surface and the system, Type BSystemes de canalisations en plastique pour les branchements et les collecteurs d'assainissement sans pression enterrés - Systemes de canalisations a parois structurées en poly(chlorure de vinyle) non plastifié (PVC-U), polypropylene (PP) et polyéthylene (PE) - Partie 3: Spécifications pour les tubes et raccords avec une surface interne lisse et une surface externe profilée et le systeme, de Type BKunststoff-Rohrleitungssysteme für erdverlegte drucklose Abwasserkanäle und -leitung - Rohrleitungssysteme mit profilierter Wandung aus weichmacherfreiem Polvinylchlorid (PVC-U), Polypropylen (PP) und Polyethylen (PE) - Teil 3: Anforderungen an Rohre, Formstücke und das Rohrleitungssystem, Rohrtyp BTa slovenski standard je istoveten z:EN 13476-3:2007SIST EN 13476-3:2007en;fr;de93.030Zunanji sistemi za odpadno vodoExternal sewage systems23.040.20Cevi iz polimernih materialovPlastics pipesICS:SLOVENSKI
STANDARDSIST EN 13476-3:200701-julij-2007

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 13476-3May 2007ICS 93.030 English VersionPlastics piping systems for non-pressure underground drainageand sewerage - Structured-wall piping systems of unplasticizedpoly(vinyl chloride) (PVC-U), polypropylene (PP) andpolyethylene (PE) - Part 3: Specifications for pipes and fittingswith smooth internal and profiled external surface and thesystem, Type BSystèmes de canalisations en plastique pour lesbranchements et les collecteurs d'assainissement sanspression enterrés - Systèmes de canalisations à paroisstructurées en poly(chlorure de vinyle) non plastifié (PVC-U), polypropylène (PP) et polyéthylène (PE) - Partie 3:Spécifications pour les tubes et raccords avec une surfaceinterne lisse et une surface externe profilée et le système,de Type BKunststoff-Rohrleitungssysteme für erdverlegte druckloseAbwasserkanäle und -leitung - Rohrleitungssysteme mitprofilierter Wandung aus weichmacherfreiemPolvinylchlorid (PVC-U), Polypropylen (PP) und Polyethylen(PE) - Teil 3: Anforderungen an Rohre, Formstücke unddas Rohrleitungssystem, Rohrtyp BThis European Standard was approved by CEN on 5 March 2007.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2007 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 13476-3:2007: E

Virgin PVC-U material 32 Annex B (normative)
Utilisation of non-virgin PVC-U material 33 B.1 Reprocessable and recyclable material from pipes and fittings 33 B.2 External reprocessable and recyclable materials with agreed specification 33 B.3 External reprocessable and recyclable materials not covered by an agreed specification 33 Annex C (normative)
Virgin PP material 35 Annex D (normative)
Utilisation of non-virgin PP material 36 D.1 Reprocessable and recyclable material from pipes and fittings 36 D.2 External reprocessable and recyclable materials with an agreed specification 36 D.3 External reprocessable and recyclable materials not covered by an agreed specification 36 Annex E (normative)
Virgin PE material 37 Annex F (normative)
Utilisation of non-virgin PE material 38 F.1 Reprocessable and recyclable material from pipes and fittings 38 F.2 External reprocessable and recyclable materials with an agreed specification 38 F.3 External reprocessable and recyclable materials not covered by an agreed specification 38 F.4 External reprocessable and recyclable material from PE rotational-moulded fittings and other components 39 Annex G (normative)
Impact test at 23 °C 40 Annex H (normative)
Impact test at −−−− 10 °C 41 Annex I (normative)
Ring flexibility test at 20 % diametric deflection 42 Annex J (informative)
Survey of possible use of reprocessable and recyclable material 43

This document (EN 13476-3:2007) has been prepared by Technical Committee CEN/TC 155 “Plastics piping systems and ducting systems”, the secretariat of which is held by NEN. This European Standard shall be given the status of a national standard, either by publication of an identical text or by endorsement, at the latest by November 2007, and conflicting national standards shall be withdrawn at the latest by November 2007. This standard is a Part of a System Standard for plastics piping systems of particular materials for a specified application. There are a number of such System Standards. System Standards are based on the results of the work being undertaken in ISO/TC 138 “Plastics pipes, fittings and valves for the transport of fluids”, which is a Technical Committee of the International Organization for Standardization (ISO). They are supported by separate standards on test methods to which references are made throughout the System Standard. The System Standards are consistent with general standards on functional requirements and on recommended practice for installation. EN 13476 consists of the following Parts under the general title Plastics piping systems for non-pressure underground drainage and sewerage - Structured-wall piping systems of unplasticized poly(vinyl chloride) (PVC-U), polypropylene (PP) and polyethylene (PE): — Part 1: General requirements and performance characteristics; — Part 2: Specifications for pipes and fittings with smooth internal and external surface and the system, Type A; — Part 3: Specifications for pipes and fittings with smooth internal and profiled external surface and the system, Type B (this standard); — Part 4: Assessment of conformity (CEN/TS); — Part 5: Guidance for installation (CEN/TS).1 For pipes and fittings which have conformed to the relevant national standard before May 2007, as shown by the manufacturer or by a certification body, the national standard may continue to be applied until May 2009.
National standards specifically for pipes and fittings for the transport of surface water are not considered to be conflicting with this standard and may thus be allowed to coexist. According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
1 The feasibility of this project is under study.

Introduction This standard provides optional choices for impact resistance (see Annex G and Annex H) and ring flexibility (see Annex I). As appropriate, the individual countries may select between those options in their national forewords.

This part is applicable to pipes and fittings with smooth internal and profiled external surfaces, designated as Type B.
It specifies test methods and test parameters as well as requirements.
This part is applicable to: a) structured-wall pipes and fittings, which are intended to be used buried underground outside the building structure, reflected in the marking of products by “U”; b) structured-wall pipes and fittings, which are intended to be used buried underground both outside (application area code “U”) and within the building structure (application area code “D”), reflected in the marking of products by “UD”. This part is applicable to structured-wall pipes and fittings with or without an integral socket with elastomeric ring seal joints as well as welded and fused joints. This part covers a range of pipe and fitting sizes, materials, pipe constructions, stiffness classes, application classes, and tolerance classes and gives recommendations concerning colours. NOTE 1 It is the responsibility of the purchaser or specifier to make the appropriate selections from these aspects, taking into account their particular requirements and any relevant national regulations and installation practices or codes.
NOTE 2 For dimensions larger than DN 1200 OD/ID this document may be applied regarding appearance, colour, physical and mechanical characteristics as well as performance requirements. 2 Normative references
The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 476, General requirements for components used in discharge pipes, drains and sewers for gravity systems EN 580, Plastics piping systems  Unplasticized poly(vinyl chloride) (PVC-U) pipes  Test method for the resistance to dichloromethane at a specified temperature (DCMT) EN 681-1, Elastomeric seals  Materials requirements for pipe joint seals used in water and drainage applications  Part 1: Vulcanized rubber EN 681-2, Elastomeric seals  Materials requirements for pipe joint seals used in water and drainage applications  Part 2: Thermoplastic elastomers EN 681-4, Elastomeric seals  Materials requirements for pipe joint seals used in water and drainage applications  Part 4: Cast polyurethane sealing elements EN 727, Plastics piping and ducting systems  Thermoplastics pipes and fittings  Determination of Vicat softening temperature (VST)

Plastics piping systems for non-pressure underground drainage and sewerage  Structured-wall piping systems of unplasticized poly(vinyl chloride) (PVC-U), polypropylene (PP) and polyethylene (PE)  Part 2: Specifications for pipes and fittings with smooth internal and external surface and the system, Type A CEN/TS 14541:2007, Plastics pipes and fittings for non-pressure applications  Utilisation of non-virgin PVC-U, PP and PE materials

EN ISO 1133:2005, Plastics  Determination of the melt mass-flow rate (MFR) and the melt volume-flow rate (MVR) of thermoplastics (ISO 1133:2005) EN ISO 1167-1, Thermoplastics pipes, fittings and assemblies for the conveyance of fluids  Determination of the resistance to internal pressure  Part 1: General method (ISO 1167-1:2006) EN ISO 1167-2, Thermoplastics pipes, fittings and assemblies for the conveyance of fluids  Determination of the resistance to internal pressure  Part 2: Preparation of pipe test pieces (ISO 1167-2:2006) EN ISO 1183-1, Plastics  Methods for determining the density of non-cellular plastics  Part 1: Immersion method, liquid pyknometer and titration method (ISO 1183-1:2004). EN ISO 3126, Plastics piping systems - Plastics piping components - Determination of dimensions (ISO 3126:2005) EN ISO 3451-1, Plastics  Determination of ash  Part 1: General methods (ISO 3451-1:1997). EN ISO 9967,
Plastics pipes  Determination of creep ratio (ISO 9967:1994) EN ISO 9969, Thermoplastics pipes  Determination of ring stiffness (ISO 9969:1994) ISO 12091, Structured-wall thermoplastics pipes – Oven test ISO 13967, Thermoplastics fittings  Determination of ring stiffness. 3 Terms, Definitions, symbols and abbreviations
3.1 Definitions For the purposes of this document, the terms and definitions given in EN 13476-1:2007 apply. 3.2 Symbols A length of engagement, or maximum pull-out whilst maintaining tightness C length of the sealing zone de outside diameter dem mean outside diameter dim mean inside diameter dn nominal diameter dsm,min minimum mean inside diameter of socket

e2 wall thickness at any point of the cylindrical part of a socket e3 wall thickness at any point of a sealing ring groove of a socket e4 wall thickness of the inside layer (waterway wall thickness) e5 wall thickness of the inside layer under a hollow section F distance from the end of a spigot to the effective sealing point l effective length of a pipe L1,min minimum length of a spigot
Sso actual stiffness of the cylindrical part of the socket Ssp actual stiffness of the spigot IMP 23C impact resistance determined at +23 °C 7 impact resistance determined at −10 °C 3.3 Abbreviations CaCO3 calcium carbonate CT close tolerance DN nominal size DN/ID nominal size related to inside diameter DN/OD nominal size related to outside diameter H50 value for impact resistance of a pipe MgCO3 magnesium carbonate MFR melt mass-flow rate Mg3Si4O10(OH)2 magnesiumsilicate, talcum OIT oxidation induction time PE polyethylene PP polypropylene PP-MD mineral modified PP
PVC-U unplasticized poly(vinyl chloride) RF ring flexibility performance

pressure a, b
No failure during the test period End caps Orientation Number of test pieces Test temperature Circumferential stress
- pipe material
- fitting material Conditioning period
Type of test Test period Type A or Type B
Free 3 60 °C
10 MPa
6,3 MPa
Shall conform to
EN ISO 1167-1 Water-in-water 1 000 h EN ISO 1167-1 and EN ISO 1167-2 a For extrusion compounds this test shall be carried out in the form of a solid wall pipe made from the relevant extrusion material.
b For injection-moulding compounds this test shall be carried out in the form of an injection-moulded or extruded sample in solid wall pipe form made from the relevant material.
4.2.3 Utilisation of non-virgin materials For the utilisation of non-virgin PVC-U materials conditions and requirements are given in Annex B. NOTE Annex J gives a survey of the possible use of reprocessable and recyclable materials. 4.3 Polypropylene (PP) 4.3.1 General The compound for pipes and fittings shall be PP base material to which are added those additives that are needed to facilitate the manufacture of components conforming to the requirements of this standard. See also Annex C. NOTE Additional information of the characteristics of PP material or components made thereof is given in Annex A of EN 13476-1:2007. 4.3.2 Pipe and fitting material characteristics When tested in accordance with the test methods as specified in Table 2, using the indicated parameters, the material shall have characteristics conforming to the requirements given in Table 2.

a, b
No failure during the test period End caps Test temperature
Orientation Number of test pieces Circumferential stress Conditioning period
Type of test Test period Type A or Type B 80 °C
Free 3 4,2 MPa Shall conform to
EN ISO 1167-1 Water-in-water 140 h EN ISO 1167-1 and EN ISO 1167-2 Resistance to internal pressure 1 000 h a, b
No failure during the test period End caps Test temperature
Orientation Number of test pieces Circumferential stress Conditioning period
Type of test Test period Type a or b
95 °C
Free 3 2,5 MPa Shall conform to
EN ISO 1167-1 Water-in-water 1000 h EN ISO 1167-1 and EN ISO 1167-2 Melt mass-flow rate ≤ 1,5 g/10 min Temperature Loading mass 230 °C 2,16 kg EN ISO 1133:2005 condition M Thermal stability, OIT c ≥ 8 min Temperature 200 °C EN 728 a For extrusion compounds this test shall be carried out in the form of a solid wall pipe made from the relevant extrusion material.
b For injection-moulding compounds this test shall be carried out in the form of an injection-moulded, or extruded sample in solid wall pipe form made from the relevant material.
c This requirement is only valid for pipes and fittings intended to be jointed in field by fusing or welding.
4.3.3 Melt mass-flow rate classification Materials for pipes and fittings intended for jointing in field by fusion or welding shall be designated by the following MFR classes: — Class A: MFR ≤ 0,3 g/10 min; — Class B: 0,3 g/10 min < MFR ≤ 0,6 g/10 min; — Class C: 0,6 g/10 min < MFR ≤ 0,9 g/10 min; — Class D: 0,9 g/10 min < MFR ≤ 1,5 g/10 min. In the case where a raw material because of its MFR tolerance arbitrarily fall in one of two adjacent classes the manufacturer of the components may mark the MFR class on the product as follows: — MFR value across the border between A and B it is permitted to classify as class A; — MFR value across the border between B and C it is permitted to classify as class C; — MFR value across the border between C and D it is permitted to classify as class D. 4.3.4 Utilisation of non-virgin materials For the utilisation of non-virgin PP materials conditions and requirements are given in Annex D. NOTE Annex J gives a survey of the possible use of reprocessable and recyclable materials.

No failure during the test period End caps Test temperature
Orientation Number of test pieces Circumferential stress Conditioning period
Type of test Test period Type A or Type B
80 °C
Free 3 4,0 MPa Shall conform to
EN ISO 1167-1 Water-in-water 165 h EN ISO 1167-1 and EN ISO 1167-2 Resistance to internal pressure 1000 h a, b
No failure during the test period End caps Test temperature
Orientation Number of test pieces Circumferential stress Conditioning period
Type of test Test period Type a or b
80 °C
Free 3 2,8 MPa Shall conform to
EN ISO 1167-1 Water-in-water 1 000 h EN ISO 1167-1 and EN ISO 1167-2 Melt mass-flow rate ≤ 1,6 g/10 min Temperature Loading mass 190 °C 5 kg EN ISO 1133:2005condition T Thermal stability, OIT c ≥ 20 min Temperature 200 °C EN 728 Reference density
≥ 930 kg/m3 Shall conform to ISO 1183-1 EN ISO 1183-1 a This test shall be carried out in the form of a solid wall pipe made from the relevant extrusion material. b For injection-moulding compounds this test shall be carried out in the form of an injection-moulded, or extruded sample in pipe form made from the relevant material. c This requirement is only valid for pipes and fittings intended to be jointed in field by fusing or welding.
4.4.3 Material characteristics of rotational-moulded fittings When tested in accordance with the test methods as specified in Table 4, using the indicated parameters, the material shall have characteristics conforming to the requirements given in Table 4.

Resistance to internal pressure 165 h a No failure during the test period End caps Orientation Number of test pieces Temperature Circumferential
stressConditioning period
Type of test Test period Type A or Type B Free 3 60 °C 3,9 MPa Shall conform to
EN ISO 1167-1 Water-in-water 165 h EN ISO 1167-1 and EN ISO 1167-2 Resistance to internal pressure 1000 h a No failure during the test period End caps Orientation Number of test pieces Temperature Circumferential
stressConditioning period
Type of test Test period Type A or Type B Free 3 60 °C 3,2 MPa Shall conform to
EN ISO 1167-1 Water-in-water 1000 h EN ISO 1167-1 and EN ISO 1167-2 Melt mass-flow rate 3 g/10 min ≤ MFR
≤ 16 g/10 min Temperature Loading mass 190 °C 5 Kg EN ISO 1133:2005 Condition T Thermal stability ≥ 10 min Temperature 200 °C EN 728 Density ≥ 925 kg/m3 Temperature (23 ± 2) °C EN ISO 1183 1 a This test shall be carried out in the form of an injection-moulded, or extruded sample in solid wall pipe form made from the relevant material.
4.4.4 Utilisation of non-virgin materials For the utilisation of non-virgin PE materials conditions and requirements are given in Annex F. NOTE Annex J gives a survey of the possible use of reprocessable and recyclable materials. 4.4.5 Sealing ring retaining components It is permitted that sealing rings are retained using components made from any polymer. 4.5 Sealing rings The sealing ring material shall conform to EN 681-1, EN 681-2 or EN 681-4, as applicable. The sealing ring shall have no detrimental effects on the properties of the components and shall not cause the test assembly to fail the performance requirements given in clause 10. 4.6 Fused or welded joints The design of fused or welded joints together with the manufacturer's instructions for the jointing process shall not cause the test assembly to fail the performance requirements given in clause 10. 4.7 Adhesives for PVC-U The adhesive for jointing of PVC-U shall be solvent cement and shall be as specified by the manufacturer of the pipes or fittings where appropriate.

Key
1 supporting profile Figure 1  Typical examples of wall construction type B
5.1.2 Typical jointing methods for structured-wall type B Relevant jointing dimensions for typical Type B joint constructions are shown in Figure 2 and Figure 3.

NOTE The position of the sealing ring on the spigot should be as specified by the manufacturer Figure 2  Typical examples of elastomeric sealing ring joints with the sealing
ring located on the spigot, Type B
Figure 3  Typical example of an elastomeric sealing ring joint with sealing ring located in the socket, Type B 5.2 Designation and design of joints Pipes and fittings may be designed with spigot ends and sockets of another construction than the pipe or fitting body. Such constructions may be Type A1, Type A2, Type B or solid plain. For definitions and specifications for Type A1 and Type A2 pipes, see EN 13476-2. NOTE Joints with elastomeric sealing rings are designed either with the sealing ring positioned on the spigot (see Figure 2), or in the socket, see Figure 3. 6 Appearance and colour The appearance and colour of the components shall conform to EN 13476-1.

7.1 General All dimensions shall be measured in accordance with EN ISO 3126. 7.2 Dimensions 7.2.1 Designation Pipes and fittings are sized either according to their outside diameter (DN/OD-series) and/or according to their inside diameter (DN/ID-series). DN/OD pipes and fittings Type B with plain spigot jointing dimensions conforming to EN 1401-1, EN 1852-1, EN 14758-1 or EN 12666-1 for PVC-U, PP, PP-MD and PE, and with larger de than the spigot, may be designated by the spigot dimension. NOTE Because of the permitted variations in geometric details, conformity to this standard does not ensure inter- changeability of pipes, fittings and other components from different manufacturers and/or different designs other than for Type A1 and solid wall components that have jointing dimensions in accordance with EN 1401-1, EN 1852-1, EN 14758-1 or EN 12666-1. EN 1852-1, EN 12666-1 and EN 14758 includes two sets of tolerances on the outside diameters of spigots. 7.2.2 Lengths of pipe The effective length of pipe l, shall not be less than that specified by the manufacturer when measured as shown in Figure 2 and/or Figure 3. 7.2.3 Diameters 7.2.3.1 Diameters of Type B pipes and spigots of pipes or fittings 7.2.3.1.1 Nominal sizes Preferred nominal sizes and minimum mean inside diameters for DN/OD and DN/ID series are specified in Table 5. Other nominal sizes, greater than DN/ID 100 and DN/OD 110 and less than DN/OD 1 200 and DN/ID 1 200, than given in Table 5, are permitted. They should preferably be selected from the Renard R40 series or traditional national dimensions. In such cases the nominal size DN/ID of pipes and fittings shall be selected in such a way that the designed minimum mean inside diameter dim,min, conforms to the requirement to maximum limit deviations on internal diameters in EN 476.
For DN/ODs and DN/IDs not specified in Table 5, the minimum inside diameter dim,min, shall be linearly interpolated between the adjacent values specified in Table 5.

thickness of inside layers and socket length Dimensions in millimetres Minimum mean inside diameters Minimum wall thickness Socket a DN/OD series DN/ID series
PVC-U b PP/ PE b, c
c
DN/OD dim,min dim,min DN/ID dim,min e4,min e5,min Amin 110 97 90 1 00 95 1,0 1,0 32 125 107 105
1,1 1,0 35
125 120 1,2 1,0 38 160 135 134
1,2 1,0 42
150 145 1,3 1,0 43 200 172 167
1,4 1,1 50
200 195 1,5 1,1 54 250 216 209 225 220 1,7 1,4 55
250 245 1,8 1,5 59 315 270 263
1,9 1,6 62
300 294 2,0 1,7 64 400 340 335
2,3 2,0 70
400 392 2,5 2,3 74 500 432 418
2,8 2,8 80
500 490 3,0 3,0 85 630 540 527
3,3 3,3 93
600 588 3,5 3,5 96 800 680 669
4,1 4,1 110
800 785 4,5 4,5 118 1 000 864 837
5,0 5,0 130
1 000 985 5,0 5,0 140 1 200 1 037 1 005
5,0 5,0 150
1 200 1 185 5,0 5,0 162 a For selection of the Amin requirements for a socket, refer to the pipe material and construction. For pipes longer than 6 m it is recommended to produce larger Amin than specified in this table.
b The actual inside diameter of a pipe depends on the material, construction and stiffness. It may be higher than the minimum specified in this table. For more information see the manufacturers documentation.
c The minimum mean inside diameter, dim,min, of a fitting shall not be less than 98 % of the specified minimum mean inside diameter of the pipe for which it is designed or conform to Table 5, whichever is the greater value.
7.2.3.1.2 Outside diameters of pipes and spigots Pipes and spigots DN/OD series intended to have jointing dimensions as pipes and/or fittings according to EN 1401-1, EN 1852-1, EN 14758-1 or EN 12666-1 for PVC, PP, PP-MD or PE respectively, shall conform to the relevant standards regarding the outside diameters and tolerances of the spigot. If such products are intended to meet the close tolerance requirements (see EN 13476-2:2007, Table 5), they shall be marked "CT".

(1) dem,max ≤ 1,003 × de
(2) where
de equals either the nominal size of a DN/OD pipe or the outside diameter as specified by the manufacturer of a DN/ID pipe. The results are to be rounded to the next highest 0,1 mm. Table 6
 Outside diameter tolerances and inside diameters of sockets Minimum mean outside diameter, dem,min Nominal Size DN/OD a
For pipes and fittings not intended to have jointing dimensions as pipes and/or fittings according to EN 1401-1, EN 1852-1, EN 14758-1 or EN 12666-1 Maximum mean outside diameter dem,max Minimum mean inside diameter of socket dsm,min 110 125 160 200 250 315 400 500 630 800 1 000 1 200 109,4 124,3 159,1 198,8 248,5 313,2 397,6 497,0 626,3 795,2 994,0 1 192,8 110,4 125,4 160,5 200,6 250,8 316,0 401,2 501,5 631,9 802,4 1 003,0 1 203,6 110,4 125,4 160,5 200,6 250,8 316,0 401,2 501,5 631,9 802,4 1 003,0 1 203,6 a For requirements to other nominal sizes and DN/ID series, use the equations in 7.2.3.1.2. 7.2.4 Diameters and jointing dimensions of sockets and spigots 7.2.4.1 Joints with the elastomeric sealing ring positioned in the socket 7.2.4.1.1 Combined with Type B pipes or fittings For Type B pipes, the requirements regarding the socket and spigot dimensions Amin, specified in Table 5 applies. In the case where nominal sizes other than those specified in Table 5 are selected for Type B pipes, see 7.2.3.1.2, the requirements regarding the socket dimension Amin, shall be linearly interpolated between the adjacent values specified in the Table. For Type B pipes greater than DN/OD 630 and DN/ID 600 when they are designed for a specific project, Amin may be shorter than specified in the table, however, it shall not be less that 85 mm. Such pipes shall be marked “SHORT SOCKET” after the EN number (see Table 18). The minimum mean inside diameter of sockets, dsm,min, for the preferred DN/OD are given in Table 6.

(3) where
F is the distance from the end of the spigot to the effective sealing point (see Figure 2). NOTE The manufacturer should specify in which position the sealing ring should be placed if there is more than one possibility. The minimum mean inside diameter of sockets dsm,min, for the preferred DN/OD, are given in Table 6. For other DN/OD sizes and DN/ID series dsm,min shall be equal to de,max. 7.2.5 Wall thicknesses 7.2.5.1 General For easy tracking wall thickness requirements, the following information is given: Wall thickness of pipes and spigots are given in 7.2.5.2 sockets
7.2.5.3 injection moulded fittings
7.2.5.4 fabricated fittings
7.2.5.5 rotational moulded fittings
7.2.5.6 7.2.5.2 Wall thickness of pipes and spigots When the spigot has the actual pipe design the wall thickness of the inside layer, e4 and/or e5, as applicable, of pipes and spigots (see Figure 1, Figure 2 and Figure 3) shall conform to Table 5. For a solid plain spigot design, the wall thickness e, shall conform to Table 7. The values shall be calculated to the second decimal place and rounded to the next highest 0,1 mm.

but not less than 3,2 PVC-U de > 500 9,8
de ≤ 500 de/41
but not less than 3,4 PP de > 500 12,2
de ≤ 500 de/33
but not less than 4,2 PE de > 500 15,2
7.2.5.3 Wall thickness of sockets 7.2.5.3.1 General In addition to the minimum required wall thickness of sockets and spigots, as specified below, their ring stiffness when determined in accordance with EN ISO 9969, shall conform to the following Equation (4): Sso + Ssp ≥ [SN]pipe …(4) Where
Sso I
is the ring stiffness of the socket
Ssp
is the ring stiffness of the spigot
[SN]pipe is the nominal ring stiffness of the pipe. For the test it is permitted to use cut off straight socket and spigot parts even if they do not conform to the length requirements specified in EN ISO 9969. For dimensions greater than or equal to 500 mm, the stiffness may be calculated provided reliable information regarding the E-modulus is available. 7.2.5.3.2 Wall thickness of sockets conforming to EN 1401-1, EN 1852-1, EN 14758-1 or EN 12666-1 When a socket is to conform to one of the mentioned standards, it shall comply with the wall thickness requirements of the appropriate standard. 7.2.5.3.3 Wall thickness of sockets heat formed on the pipes after extrusion When a socket is heat formed on the pipe or pipe segment after extrusion, a maximum reduction of the wall thicknesses e, e2, e4 and e5 as applicable of 15 % and e3 25 % of the manufacturers specified corresponding wall thickness of the pipe is permitted. 7.2.5.3.4 Wall thickness of other sockets with stiffness ≥≥≥≥ 4 kN/m2 For structured wall designed sockets the wall thickness e4 and e5, shall comply to the requirements given in Table 5.

c) SDR 26 series in EN 12666-1; for PVC-U, PP and PE respectively. In the case of ID series fittings the calculation shall be based on the actual outside diameter of the corresponding pipe. The jointing design including socket and spigot dimensions shall conform to 7.2.4.1 and 7.2.4.2. 7.2.5.5 Wall thickness of fabricated fittings The wall thickness of the body of fittings fabricated from pipes shall conform to the requirements of the corresponding pipe. Wall thickness reductions due to the process are permitted provided the requirements in Table 16 are met. The jointing design including socket and spigot dimensions shall conform to 7.2.4.1 and 7.2.4.2. 7.2.5.6 Wall thickness of rotational moulded fittings The minimum wall thickness in the body of rotational-moulded fittings, e4,min, shall be 1,25 times the values specified for Injection moulded fittings, rounded to the next highest 0,1 mm. If a rotational moulded fitting have a solid plain spigot and or socket, the minimum required wall-thicknesses e, e2 and e3 as applicable, shall be 1,25 times the values derived from 7.2.5. The socket and spigot dimensions shall conform to 7.2.4.2. 7.3 Types of fittings
The types of fittings covered by this standard are given in EN 13476-1. 7.3.1 Design length of fittings The design length of fittings shall conform to 8.2 of EN 13476-1:2007.

Characteristic Requirements Test parameters Test
Vicat softening temperature (VST) a VST ≥ 79 °C Shall conform to EN 727 EN 727 Resistance to dichloromethane b No attack Test temperature Immersion time 15 °C 30 min EN 580 Resistance to heating - Oven test
The pipe shall show no delaminations cracks or bubbles Test temperature Immersion time c for: e
≤ 8 mm e > 8 mm (150 ± 2) °C
30 min 60 min ISO 12091 a If e4 is less than 1,8 mm the test shall be carried out on a profile extruded from the mat
...
