EN 1514-1:1997
(Main)Flanges and their joints - Dimensions of gaskets for PN-designated flanges - Part 1: Non-metallic flat gaskets with or without inserts
Flanges and their joints - Dimensions of gaskets for PN-designated flanges - Part 1: Non-metallic flat gaskets with or without inserts
This standard specifies the dimensions and marking of non-metallic flat gaskets,with or without inserts, for use with flanges complying with EN 1092: Parts 1,22and 3, and pipes and fittings complying with EN 545 and EN 598 up to and including PN 63 and up to and including DN 4000.
Flansche und ihre Verbindungen - Maße für Dichtungen für Flansche mit PN-Bezeichnung - Teil 1: Flachdichtungen aus nichtmetallischem Werkstoff mit oder ohne Einlagen
Diese Norm legt die Maße und Kennzeichnung von Flachdichtungen aus nichtmetallischem Werkstoff mit oder ohne Einlagen für Flansche nach EN 1092 Teil 1, 2 und 3 sowie für Rohre und Formstücke nach EN 545 und EN 598 fest bis einschließlich PN 63 und bis einschließlich DN 4000.
Brides et leurs assemblages - Dimensions des joints pour les brides désignées PN - Partie 1: Joints plats non-métalliques avec ou sans insert
La présente norme prescrit les dimensions et le marquage des joints plats non métalliques, avec ou sans inserts, utilisés avec les brides conformes aux normesEN 1092: Parties 1, 2 et 3 et les tuyaux et raccords conformes à la norme EN 545et la norme EN 598 jusqu'à PN 63 inclus et jusqu'à DN 4000 inclus.
Prirobnice in prirobnični spoji - Mere tesnil za prirobnice z oznako PN - 1. del: Nekovinska ploščata tesnila z ojačitvijo ali brez nje
General Information
- Status
- Withdrawn
- Publication Date
- 22-Apr-1997
- Withdrawal Date
- 13-Apr-2025
- Technical Committee
- CEN/TC 74 - Flanges and their joints
- Drafting Committee
- CEN/TC 74/WG 8 - Gaskets
- Current Stage
- 9960 - Withdrawal effective - Withdrawal
- Start Date
- 28-Aug-2024
- Completion Date
- 14-Apr-2025
Relations
- Effective Date
- 18-Jan-2023
Frequently Asked Questions
EN 1514-1:1997 is a standard published by the European Committee for Standardization (CEN). Its full title is "Flanges and their joints - Dimensions of gaskets for PN-designated flanges - Part 1: Non-metallic flat gaskets with or without inserts". This standard covers: This standard specifies the dimensions and marking of non-metallic flat gaskets,with or without inserts, for use with flanges complying with EN 1092: Parts 1,22and 3, and pipes and fittings complying with EN 545 and EN 598 up to and including PN 63 and up to and including DN 4000.
This standard specifies the dimensions and marking of non-metallic flat gaskets,with or without inserts, for use with flanges complying with EN 1092: Parts 1,22and 3, and pipes and fittings complying with EN 545 and EN 598 up to and including PN 63 and up to and including DN 4000.
EN 1514-1:1997 is classified under the following ICS (International Classification for Standards) categories: 23.040.80 - Seals for pipe and hose assemblies. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 1514-1:1997 has the following relationships with other standards: It is inter standard links to EN 1514-1:2024. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN 1514-1:1997 is associated with the following European legislation: EU Directives/Regulations: 97/23/EC; Standardization Mandates: M/071. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.
You can purchase EN 1514-1:1997 directly from iTeh Standards. The document is available in PDF format and is delivered instantly after payment. Add the standard to your cart and complete the secure checkout process. iTeh Standards is an authorized distributor of CEN standards.
