EN 4114:2009
(Main)Aerospace series - Clamps, loop (''P'' type) in aluminium alloy with rubber cushioning - Dimensions, masses
Aerospace series - Clamps, loop (''P'' type) in aluminium alloy with rubber cushioning - Dimensions, masses
This European Standard specifies the required characteristics of loop style clamps (“P” type) in aluminium alloy with various cushion materials.
These clamps are used for supporting aerospace pipe assemblies and electrical cable bundles.
They are used up to 80 C max.
Usage at a higher temperature is at the option of the user.
For temperature range and environmental considerations, see the various cushion material standards.
Luft- und Raumfahrt - Schellen in Schlaufenform (P-Form) aus Aluminiumlegierung mit Profilgummi - Maße, Massen
Diese Norm legt die Anforderungen an Schellen in Schlaufenform (P-Form) aus Aluminiumlegierung mit
verschiedenen Profilgummi-Werkstoffen fest.
Diese Schellen werden zur Halterung von Rohrleitungen und elektrischen Leitungsbündeln in der Luft- und
Raumfahrt verwendet.
Sie werden bis zu einer Temperatur von höchstens 80 °C verwendet.
Die Verwendung bei höherer Temperatur erfolgt nach Wahl des Anwenders.
Temperaturbereich und Umweltbedingungen entsprechen den Angaben in den jeweiligen Werkstoffnormen
für Profilgummi.
Série aérospatiale - Colliers en ''P'' en alliage d'aluminium avec profilé en élastomère - Dimensions, masses
Aeronavtika - Objemke v obliki zanke (P-oblika) iz aluminijeve zlitine z zaščitno prevleko iz gume - Mere, mase
Ta evropski standard opredeljuje zahtevane značilnosti objemk v obliki zanke (P-oblika) iz aluminijeve zlitine, z različnimi zaščitnimi prevlekami. Te objemke se uporabljajo za podporo cevnih spojev v aeronavtiki in svežnje električnih kablov. Uporabljajo se največ do 80°C. Uporaba pri višji temperaturi je po izbiri uporabnika. Za temperaturni razpon in okoljske vidike glejte standarde za različne materiale za zaščitno prevleko.
