EN 3304:1996
(Main)Aerospace series - Screws, 100° countersunk reduced head, offset cruciform recess, close tolerance normal shank, short thread, in titanium alloy, anodized, MoS2 lubricated - Classification: 1 100 MPa (at ambient temperature)/315 °C
Aerospace series - Screws, 100° countersunk reduced head, offset cruciform recess, close tolerance normal shank, short thread, in titanium alloy, anodized, MoS2 lubricated - Classification: 1 100 MPa (at ambient temperature)/315 °C
This standard specifies the characteristics of screws, 100° countersunk reduced head, offset cruciform recess, close tolerance normal shank, short thread, in titanium alloy, anodized, MoS2 lubricated. Classification: 1100 MPa / 315°C.
Luft- und Raumfahrt - 100° Senk-Paßschrauben mit kleinem Kopf, mit Flügelkreuzschlitz, kurzes Gewinde, aus Titanlegierung, anodisiert, MoS2-geschmiert - Klasse: 1 100 MPa (bei Raumtemperatur)/315 °C
Diese Norm legt die Eigenschaften von 100° Senk-Paßschrauben mit kleinem Kopf und Flügelkreuzschlitz, kurzes Gewinde, aus Titanlegierung, anodisiert, MoS2-geschmiert, fest. Klasse: 1100 MPa / 315°C.
Série aérospatiale - Vis à tête fraisée 100° réduite, à empreinte cruciforme déportée, tige normale à tolérance serrée, filetage court, en alliage de titane, anodisées, lubrifiées MoS2 - Classification: 1 100 MPa (à température ambiante)/315 °C
La présente norme spécifie les caractéristiques des vis à tête fraisée 100° réduite, à empreinte cruciforme déportée, tige normale à tolérance serrée, filetage court, en alliage de titane, anodisées, lubrifiées MoS2. Classification: 1100 MPa / 315°C.
Aerospace series - Screws, 100° countersunk reduced head, offset cruciform recess, close tolerance normal shank, short thread, in titanium alloy, anodized, MoS2 lubricated - Classification: 1 100 MPa (at ambient temperature)/315°C
General Information
- Status
- Published
- Publication Date
- 24-Sep-1996
- Withdrawal Date
- 30-Mar-1997
- Technical Committee
- ASD-STAN - Aerospace
- Drafting Committee
- ASD-STAN/D 3 - Mechanical
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 31-May-2017
- Completion Date
- 21-Jan-2026
Relations
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Overview
EN 3304:1996 (CEN) is an aerospace series standard that specifies the characteristics of a specific class of aerospace screws. It covers 100° countersunk reduced head screws with an offset cruciform recess, close-tolerance normal shank, and short thread, manufactured from titanium alloy, anodized, and MoS2 (molybdenum disulfide) lubricated. The standard includes a strength classification of 1100 MPa (at ambient temperature) / 315 °C. The Slovenian identical publication is SIST EN 3304:2001.
Key topics and requirements
- Fastener geometry: Defines the screw head form - 100° countersunk reduced head - and the offset cruciform recess type.
- Shank and thread form: Specifies a close-tolerance normal shank with a short thread length.
- Material and finish: Titanium alloy construction with anodized surface treatment.
- Lubrication: Requirement for MoS2 lubrication to control friction and assembly behavior.
- Mechanical classification: Designated as 1100 MPa / 315 °C, indicating the standard’s intended strength and temperature class.
- Scope boundaries: Targets a narrowly defined aerospace screw variant; users should consult the full standard for detailed dimensional, tolerance and marking requirements (as published by CEN/SIST).
Applications
- Aerospace manufacturing and repair: Selection and procurement of titanium countersunk screws for airframe, structure or cabin components where reduced head geometry and high-strength titanium fasteners are required.
- Design and assembly engineering: Engineers specifying fasteners that require tight shank tolerances, short thread engagement, and controlled friction (MoS2) for torque/ preload consistency.
- Procurement and quality assurance: Purchasing, inspection and acceptance criteria for suppliers and maintenance organizations working to CEN standards.
- Compatibility and safety: Used where consistent mechanical classification and surface treatment (anodizing + MoS2) are required for assembly performance and corrosion considerations in aerospace environments.
Related standards and references
- Organization: CEN (European Committee for Standardization).
- National identical publication: SIST EN 3304:2001 (Slovenia).
- Classification and ICS: Related to bolt and screw standards under ICS group 49.030.20 (Bolts, screws, studs).
Keywords: EN 3304:1996, aerospace screws, 100° countersunk reduced head, offset cruciform recess, titanium alloy screws, anodized, MoS2 lubricated, close tolerance shank, short thread, aerospace fasteners.
