EN 14450:2005

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Varnostne shranjevalne enote - Klasifikacija in metode preskušanja protivlomne odpornosti - Varnostne omareWertbehältnisse - Anforderungen, Klassifizierung und Methoden zur Prüfung des Widerstandes gegen Einbruchdiebstahl - SicherheitsschränkeUnités de stockage en lieu sur - Exigences, classification et méthodes d'essai de résistance a l'effraction - Coffres domestiquesSecure storage units - Requirements, classification and methods of test for resistance to burglary - Secure safe cabinets35.220.99Druge naprave za shranjevanje podatkovOther data storage devices13.310Varstvo pred kriminalomProtection against crimeICS:Ta slovenski standard je istoveten z:EN 14450:2005SIST EN 14450:2005en01-maj-2005SIST EN 14450:2005SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 14450March 2005ICS 13.310English versionSecure storage units - Requirements, classification and methodsof test for resistance to burglary - Secure safe cabinetsUnités de stockage en lieux sûrs - Prescriptions,classification et méthodes de test pour la resistance àl'effraction - Compartiment de sécuritéWertbehältnisse - Anforderungen, Klassifizierung undMethoden zur Prüfung des Widerstandes gegenEinbruchdiebstahl - SicherheitsschränkeThis European Standard was approved by CEN on 23 September 2004.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2005 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 14450:2005: ESIST EN 14450:2005

EN 1300, Secure storage units — Classification for high security locks according to their resistance to unauthorised opening 3 Terms and definitions For the purpose of this document, the following terms and definitions apply.
3.1 secure safe cabinet storage unit which protects its content against burglary and when closed has at least one internal side ≤ 1 m length. The interior of a secure safe cabinet is accessed through a lockable door or lid 3.2 free-standing unit secure safe cabinet whose protection against burglary depends only upon the materials and construction of its primary manufacture and not upon materials added or attached during installation 3.3 wall unit secure safe cabinet for installation into a wall and whose protection against burglary is partly dependent upon the wall(s) and the materials added during installation 3.4 floor unit secure safe cabinet for installation into a floor and whose protection against burglary is partly dependent upon materials added during installation 3.5 working time time spent during testing during which one or more tools are used to create a change in the test specimen 3.6 gross time time from when a test is started to when the test is complete or abandoned 3.7 encasement material added at installation to protect and anchor wall units and floor units 3.8 tool point, TP numerical value assigned to test tool 3.9 security units, SU numerical value expressing resistance against burglary attack SIST EN 14450:2005

S1S2 Minimum resistance for access2,00SU5,00SU to the interior Limit to number and type of 40 TP60 TP tools used for testing
Minimum strength 20 kN30 kN per anchoring hole
Minimum locking One lock toOne lock to
EN 1300 EN 1300
Gross attack time is limited as described in 7.2.4b. 4.2 Requirements 4.2.1 There shall be no holes through the protection material other than those for locks, cables or anchoring. One cable hole is allowed, this shall not exceed 100 mm2. 4.2.2 A free-standing unit with a mass less than 1000 kg shall have at least two holes by which it can be anchored. These holes shall both be in the face through which it is to be anchored. The anchoring assembly for each anchoring hole shall sustain the minimum anchoring strength given in Table 1. 4.2.3 Secure safe cabinets shall be provided with operating and installation instructions, including instructions in respect of the locks and anchoring. SIST EN 14450:2005

5 Technical Documentation 5.1 General The technical documentation shall contain the following information: 5.2 Date of issue and the name of the manufacturer (or the name and status of the applicant requesting testing) shall be on each page; 5.3 Statement of the type and model number of secure safe cabinet, e.g. free-standing unit, wall unit or floor unit;. 5.4 Drawings of the test specimen and documents giving the following: a) weight, outside and inside dimensions, and the manufacturing tolerances of the dimensions; b) horizontal and vertical cross-sections; c) the quantity, layout and features of locks, boltwork and relocking devices; d) the quantity, pitch and position of door bolts, their dimensions (e.g. cross-section), throw and engagement and their type (e.g. moving or fixed); e) the location and design of any local areas of special protection material; f) purpose, position and dimensions of any holes which pass through the protection material with details of any associated special protection; g) details of optional features, e.g. time locking and time delay locking; h) specification of the materials of construction. 5.5 Operating and installation instructions, including instructions in respect of the locks and anchoring 5.6 In addition to 5.2, 5.3 and 5.4, for wall units and floor units the following information shall be provided: a) details of the recommended procedure for installation; b) drawing showing the recommended plane of door or lid in relation to the surface of the wall or floor into the unit is to be installed; c) details of encasement materials (see 3.7); d) recommendation for the proportion of the body to be encased and the thickness of the encasement; identification of any areas of the body which are not protected by material added at installation;5.7 List of all locks that may be fitted, giving the manufacturer and model number; 5.8 Details of any materials or device(s) intended to generate gas, smoke, soot, etc., in the event of physical attack or which could generate harmful substances during testing. SIST EN 14450:2005

6.4 When a range of different size secure safe cabinets is submitted for testing, the testing laboratory shall specify which sizes are to be tested. More than one size may be tested. 7 Tool attack test 7.1 Tool attacks 7.1.1 Tool list SIST EN 14450:2005

Table 2 — Permitted tools, coefficients (SU/min) and tool points (TP) Tool Maximum overallCoefficient Tool Points size/amount/powerSU/min TPNon-tools
String, wire, adhesive tape 5 m 1 0Chalk, marking pens 2 pieces1 0Measuring tape 3 m 1 0Steel rule 300 mm1 0Self tapping screws 12 mm1 0Electric torch 1 torch1 0Hammer 0,2 kg300 mm length1 0
Small tools
Wedges made fof wood or plastic 200 mm by 80 mm by 40 mm1 10Cold chisel, flat or pointed 30 mm blade width, 250 mm length1 10Wood chisel 40 mm blade width, 350 mm length1 10Screwdriver 10 mm bit, 260 mm length1 10Pliers 200 mm length1 10Pinchers 240 mm length1 10Spanner 180 mm length1 10Allen key 120 mm length1 10Crowbar 300 mm length1 10Hacksaw
330 mm blade length1 10Punch 250 mm length1 10Knife 120 mm length1 10
Large tools
Hammer 1,5 kg head400 mm length 2 10Crowbar 710 mm length2 30Angle grinder ≤ 800 W input power,
wheel diameter 125 mm2 30 (1,6mm≤thickness ≤2,5 mm) Screwdriver 16 mm bit, 375 mm length2 30Electric drill without ≤ 500 W input power,
percussion action
HSS drill bit, diameter 10 mm2 30
250 mm length
Additional tool accessories
Additional hacksaw blade 330 mm blade length0 10Additional HSS drill bit 10 mm diameter, 250 mm length0 10Additional abrasive wheel or disc 125 mm diameter (no diamond disc) (1.6 mm≤thickness ≤2,5 mm)0 10 SIST EN 14450:2005

7.1.2 Tool attack procedure 7.1.2.1 Free-standing units shall be anchored according to the recommended procedure for installation (see 5.5). 7.1.2.2 Tool attack tests are timed and shall use only the tools listed in Table 2. The number and types of tool which can used in any one test is limited according to the tool unit values specified in Table 1, e.g. to a maximum of 40 TP for a level S 1 secure safe cabinet and to a maximum of 60 TP for a level S 2 secure safe cabinet. Table 2 gives the tool points for each permitted tool. 7.1.2.3 The tools and programme of attack used during testing shall be those most likely, in the opinion of the testing team, to result in the lowest security units.
7.1.2.4 The testing team shall comprise: a) a team leader responsible for the conduct of the test and whose function is to plan, direct and supervise testing; b) time keeper(s) responsible for both timekeeping and the compiling of a test record; c) testing operatives whose function is to carry out the tool attacks against the test specimen as directed by the test leader. NOTE 1 The team leader may be the timekeeper. NOTE 2 Testing should be carried out according to the current state of knowledge. To ensure maximum consistency of test results, testing laboratories shall have EN ISO/IEC 17 025
acc
...
