ASTM F2205-22

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: F2205 − 19 F2205 − 22
Standard Guide for
Ecological Considerations for the Use of Chemical
Dispersants in Oil Spill Response: Tropical Environments
This standard is issued under the fixed designation F2205; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope
1.1 This guide covers recommendations for use of chemical dispersants to assist in the control of oil spills and is written with the
goal of minimizing the environmental impacts of oil spills. Aesthetic and socioeconomic factors are not considered; although, these
and other factors are often important in spill response.
1.2 Each on-scene commander has available several means of control or cleanup of spilled oil. In this guide, use of chemical
dispersants should not be considered as a last resort after other methods have failed. Chemical dispersants should be given equal
consideration with other spill countermeasures.
1.3 This guide presents general guidelines only. The oil is assumed to be dispersible and the dispersant to be effective, available,
applied correctly, and dispersibility of the oil with the chosen dispersant should be evaluated in compliance with relevant
government regulations. Oil, as used in this guide, includes crude oils and fuel oils. Differences between individual dispersants and
to a certain degree, differences between different oils are not considered.
1.4 This guide is one of several related to dispersant considerations in different environments. The other standards are listed in
Section 2.
1.5 This guide applies to marine and estuarine environments but not to freshwater environments.
1.6 In making dispersant use decisions, appropriate government authorities should be consulted as required by law.
1.7 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use.
1.8 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
This guide is under the jurisdiction of ASTM Committee F20 on Hazardous Substances and Oil Spill Response and is the direct responsibility of Subcommittee F20.13
on Treatment.
Current edition approved Feb. 1, 2019Sept. 1, 2022. Published February 2019September 2022. Originally approved in 2002. Last previous edition approved in 20132019
as F2205 – 07F2205 – 19.(2013). DOI: 10.1520/F2205-19.10.1520/F2205-22.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
F2205 − 22
2. Referenced Documents
2.1 ASTM Standards:
F2532 Guide for Determining Net Environmental Benefit of Dispersant Use
3. Significance and Use
3.1 This guide is meant to aid local and regional spill response teams who may apply it during response planning and spill events.
3.2 This guide presents data on the effects of surface oil, dissolved oil and dispersed oil on components of tropical environments.
These data can aid in decision-making related to the use of dispersants to minimize environmental damage from oil spills.
4. General Considerations for Making Dispersant-Use Decisions
4.1 The decision of whether to use or not to use dispersants in a given spill situation involves trade-offs. Dispersing a slick at one
site temporarily introduces more oil into the water column at that site than would be there if a surface slick floated over it.
Therefore, adverse effects on water column organisms may be increased at that site so that adverse effects can be decreased at other
sites.
4.2 Dispersant use is primarily a spill controlmitigation method, not a cleanup method. Such use can give spill response personnel
some control over where the impacts of a spill will occur whatever types of impacts they may be. Since some environments are
known to be more vulnerable to the longer-lasting impacts of spilled oil, an acceptable trade-off may be to protect those
environments by dispersing an oil slick in a less sensitive or less productive environment. In general, the net environmental benefit
of dispersant use versus non-use should be evaluated (see Guide F2532). The net environmental benefit of a particular
countermeasure involves evaluating benefits and disadvantages of the particular technology being evaluated, versus other cleanup
methods or no action, on the habitat or ecosystems involved in the area. Environmental benefit analysis is best conducted before
the spill.
4.3 In this guide, environments that are most vulnerable to the longer-term impacts of oil contamination are identified. Protection
of these environments is recommended as a high priority, by means of dispersants or other methods.
5. The Tropical Environment
5.1 Tropical environments encompass many different habitats. This guide will cover those habitats that are important in terms of
decisions to use dispersants. The applications of dispersant to open waters and waters of depth greater than about 10 metres will
not be covered here and is covered by other guides listed in Section 2. Shallow waters and habitats associated with mangroves,
seagrasses and coral reefs are important considerations. Habitats other than those such as sand beaches, mudflats, cobble beaches
and rocky shores may be common in certain localities but are generally less-sensitive.
5.2 Mangrove ecosystems are intertidal forests dominated by various species of woody halophytes that are commonly called
mangroves. There are many families and species of mangroves (1-4) . Mangrove ecosystems occur in tropical low-energy
depositional areas. Mangroves tend to further promote the deposition and recycling of organic and mineral matter. Their extensive
root systems are very important in stabilizing intertidal sediments (34). Adult mangroves form the structural basis for the mangrove
community in that they provide attachment sites for many species of animals and shelter for many others.
5.2.1 Mangrove ecosystems contribute to the productivity of tropical marine ecosystems where they play the same but more
important roles as do salt marshes in temperate climates. Mangroves are important as nursery areas as well as for the detritus that
they supply to the surrounding communities (3). Much of the world’s fish populations depend on detritus and remineralized
nutrients exported from mangrove areas (5).
5.2.2 Mangrove forests dominate much of the world’s tropical shoreline; many are adjacent to tanker routes, oil fields and
refineries. The low energy characteristic of mangrove forests leads to the entry and retention of oil in these environments.envi-
ronments(4).
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
The boldface numbers in parentheses refer to a list of references at the end of this guide.
F2205 − 22
5.3 Coral Reefs—Coral reefs are structures created and maintained by the establishment and growth of hard corals and coralline
algae. algae (6). They may be comprised of emergent or submergent reefal zones, or a combination of both. Geomorphically,
Geomorphology, barrier and fringing reefs protect the insular and continental coastlines which they border from erosion. Typically,
the coral reef provides habitat for a large variety of attached plants and epifauna, infauna, mobile invertebrates, and fishes. The
large number of economically important species they support make reefs locally important in commercial and sport fisheries. The
resultant high diversity and abundance of reef associates and the functional and spatial dominance of corals and coralline algae
are the essential characteristics of coral reefs.
5.3.1 Coral reefs are circumglobal in the tropics and subtropics between the northern and southern hemispheric 18.5°C18.5 °C
climatic isotherms. isotherms (6). A majority of coral species and the most diverse reefs occur in Indo-West Pacific seas. Tropical
West Atlantic and Eastern Pacific reefs are generally less diverse in terms of corals and reef associates.
5.4 Seagrasses—Seagrasses can be found in shallow marine environments from the tropics to Polar regions. This guide focuses
on those located in tropical waters. Seagrass beds form a discrete ecosystem that traps detritus derived from terrestrial and marine
sources, and then exports large quantities of plant and animal materials, including leaf and root fragments, dissolved organic matter,
and detritus, to the open sea. sea (5). The presence of an extensive network of roots and rhizomes facilitates the sediment-binding
ability of the grass beds; the seagrass leaves effectively retard currents, thus promoting sedimentations of organic and inorganic
materials around the plants.
5.4.1 Seagrass communities are among the most productive of natural ecosystems. ecosystems (5). Seagrass leaf blades support
large numbers of epiphytes which can equal the biomass of the grass itself. Major food chains are based upon a variety of epiphytes
and associated organisms. Active sulfur, nitrogen, phosphorus, and carbon cycles are maintained through the sediment-plant-water
interfaces, and the dense interlacing mat of vegetation provides ideal cover for foraging marine fauna as well as shelter and
protection for larval and juvenile forms.
5.5 Seagrass and coral environments may also occur in sub-tropical ecosystems.
6. Effects of Oil and Dispersed Oil on Tropical Biota
6.1 Mangroves—Mangroves are primarily impacted by oil by three different routes; through the oiling of the pneumatophores, or
breathing pores typically located on special aerial roots or stems, through oil absorption from the water column and through oil
absorption through the roots from contaminated soil/sediment and ground water (6-7-12). Mangroves with oil on pneumatophores
may die within about 5 to 7 days, depending on oxygenation conditions at the site (13-15). Mangroves may die from high
concentrations of oil in the water column (16-18). The third route of oil impact on mangroves, through oil absorption from the soil,
is also well documented (19-22). Oil in mangrove-dominated sediments can cause long-lasting effects and degrades only very
slowly (23-27). Sublethal effects including leaf loss, deformations, and low growth can persist for five years after the spill event
(8, 9, 28). Replanting mangroves, a primary restoration method is successful in soils with reduced hydrocarbon content (29-33).
Natural regrowth occurs, but occurs slowly (34-36). Countermeasures which reduce the amount of oil arriving into the mangrove
area are suggested (37-40).
6.1.1 Low levels of oil from either dissolved/dispersed oil in the water column or in the sediments cause a variety of sub-lethal
effects on mangroves, including leaf loss, reduced growth of adventitious roots, abnormal pneumatophores and mineral imbalance,
and slow growth rates (41-44). Studies show that these effects will persist from 1 year up to 7 depending on amount of oil and
environmental conditions.
6.2 Biota Associated with Mangrove Forests—Mangrove forests provide shelter and support for an extensive system of biota
including algae, crustaceans, and molluscs. Dissolved and dispersed oil can cause lethality to mangrove biota at levels as low as
20 ppm and naphthalene as low as 0.4 ppm on prolonged contact (43-52). Studies have shown that the abundances of species
inversely correlated with the apparent oil damage (53). Other studies have shown that the specific numbers of a given species did
not necessarily correlate with oil content (54, 55).
6.3 Coral Reefs—Corals can be exposed to oil by two modes, direct oiling and through the uptake of dissolved or dispersed oil.
Direct oiling occurs rarely but can result in extensive mortality. The uptake of dissolved and dispersed oil can result in severe
mortality at levels as low as 12 μL/L for prolonged exposures (56). Corals are not usually subject to harmful concentrations of
water-borne hydrocarbons by the passage of a slick overhead and are typically unaffected (57-60). Similarly, corals have been
shown to reject particles of oil larger (>60 μm) than dispersed droplets (61). Corals are, however, particularly susceptible to high
F2205 − 22
concentrations of dissolved and dispersed oil and this may lead to long lasting effects or mortality (43, 44, 48, 62-65 ). Because
dispersants move oil into the water column, they may increase the effect of the oils on corals (5, 66, 67). Exposure of corals to
about 20 to 50 ppm of dissolved or dispersed oil showed that behavioral reflexes were induced in corals, however depuration was
noted within a week and recovery within a few weeks (68-70). Some long-lasting effects of low-level exposure were observed,
including reduced growth and deformation.
6.4 Biota Associated with Coral Reefs—Coral reefs provide shelter and support for an extensive system of biota. Prolonged
exposure to dissolved and dispersed oil can cause lethality to reef biota at levels as low as 20 ppm (12, 43-48, 51, 52, 71-73 ).
Studies have shown that the abundances of species inversely correlated with apparent oil damage (74). Increasing amounts of oil
availability, such as through the use of dispersants, increases the exposure of organisms to oil (75 and 76).
6.5 Seagrasses—Seagrasses can be exposed to oil by two methods, direct oiling and through the uptake of dissolved or dispersed
oil. Direct oiling occurs rarely but can result in extensive mortality (17). The uptake of dissolved and dispersed oil can result in
severe mortality at levels as low as 100 μg/L (77). Seagrasses are not usually subject to harmful concentrations of water-borne
hydrocarbons by the passage of a slick overhead and are typically unaffected (78-80). Seagrasses are, however, particularly
susceptible to high concentrations of dissolved and dispersed oil and this may lead to long lasting effects or mortality. The lethal
toxicity to seagrasses varies very much with species, and is between 75 to 125 ppm in 100 h (81, 82). Use of dispersants may
increase the exposure of seagrasses to oil (83, 84).
6.6 Biota Associated with Seagrasses—Seagrasses provide shelter and nutrients for an extensive system of biota (85, 86).
Dissolved and dispersed oil can cause lethality to these biota at levels as low as 20 ppm (12, 43-48, 51, 52, 71-73 ). Increasing
amounts of oil availability, such as through the use of dispersants, increases the exposure to organisms (75).
7. Recommendations
7.1 Dispersant use decisions must be based on the net environmental benefit analysis of use versus non-use of dispersants.
7.2 Dispersant use decisions should include consideration of the proximity of the dispersant application to sensitive marine
environments including mangrove forests, seagrasses and corals.
7.3 An important consideration is the flushing rate of water in the mangrove, seagrass and coral areas. If the flushing rate is rapid,
dissolved and dispersed oil will have minimal effects.
7.4 In many jurisdictions there are regulatory limitations in water depth (3 to 30 m) that dispersants can be applied. These
limitations shall be followed.
7.5 Dispersants are best applied in deep waters and not in direct proximity to mangroves, seagrasses and corals.
7.6 Chemical dispersion should be considered a viable option even if dispersed oil might enter the mangrove forest. Dispersants
should not be used to remove oil adhered to mangroves or shorelines. Shoreline cleaners or surface washing agents can be
considered for removing adhered oil.
7.7 Application of dispersants to prevent oil from entering the sensitive habitats of tropical environments should be considered
to minimize environmental impact.
7.8 The potential environmental impact of the dispersed oil plume trajectory should be considered.
F2205 − 22
REFERENCES
(1) Baker, J., Suryowinto, I. M., Brooks, P., and Rowland, S., “Tropical Marine Ecosystems and the Oil Industry: With a Description of a Post-Oil Spill
Survey in Indonesian Mangroves,” Proceedings of Petromar; Petroleum and the Marine Environment, Graham and Trotman, London, 1981, pp.
679-703.
(2) Chaw, L. H., Teas, H. J., Pannier, F., and Baker, J. M., “Biological Impacts of Oil Pollution,” Volume Four of IPIECA Report Series, International
Petroleum Industry Environmental Conservation Association, London, 1993.
(3) Field, C. D., “Rehabilitation of Mangrove Ecosystems: An Overview,” Marine Pollution Bulletin, Vol 37, Nos. 8-12, 1998, pp. 383-392.
(4) LewisDuke, R.N.C. Oil spill impacts on mangroves: Recommendations for operational planning and action based on a global reviewR., “Mangrove
Forests, Chapter 8,” , Creation and Restoration of a Coastal Plant CommunityMarine Pollution Bulletin, R.109 R.(2 Lewis, Ed., CRC Press, ), (
19822016,) pp. 153700-171.-715.
(5) Thorhaug, A., Anderson, M., Teas, H., Carby, B., et al., “Dispersant Use for Tropical Nearshore Waters: Jamaica,” Proceedings of the 1991
International Oil Spill Conference, American Petroleum Institute, Washington, D.C., 1991a, pp. 415-418.
(6) EvansHaapkylä, C. W., “The Effects andJ., Ramade, F., Salvat, B. Oil pollution on coral reefs: A review of the state of knowledge and management
needsImplications of Oil Pollution in Mangrove Forests,” , Proceedings of the 1985 International Oil Spill ConferenceVie et Milieu, American(2007
Petroleum Institute, Washington, D.C., ) 57 (1-2), 1985, pp. 36795-371.-111.
(7) Hoi-Chaw, L. and Meow-Chan, F., “Field and Laboratory Studies on the Toxicities of Oils to Mangroves,” Proceedings of the 1995 International
Oil Spill Conference, American Petroleum Institute, Washington, D.C., 1995, pp. 539-546.
(8) Levings, S. C., and Garrity, S. D., “Effects of Oil Spills on Fringing Red Mangroves (Rhizophora mangle): Losses of Mobile Species Associated with
Submerged Prop Roots,” Bulletin of Marine Science, Vol 54, 1994a, pp. 782-794.
(9) Levings, S. C., Garrity, S. D., and Burns, K. A., “The Galeta Oil Spill III. Chronic Reoiling, Long-Term Toxicity of Hydrocarbon Residues and Effects
on Epibiota in the Mangrove Fringe,” Estuarine Coast and Shelf Science, Vol 38, 1994b, pp. 365-395.
(10) Levings, S. C., Garrity, S. D., and Burns, K. A., “The 1986 Bahia Las Minas Oil Spill: Summary Results from the Red Mangrove (Rhizophora
mangle) Fringe,” Proceeding of the Symposium on Gulf of Mexico and Caribbean Oil Spills in Coastal Ecosystems: Assessing Effects, Natural
Recovery, and Progress in Remediation Research, MMS OCS Study, MMS 95-0063, 1994c , pp.80-98.
(11) Levings, S. C. and Garrity, S. D., “Oiling of Mangrove Keys in the 1993 Tampa Bay Oil Spill,” Proceedings of the Proceedings of the 1995
International Oil Spill Conference, American Petroleum Institute, Washington, D.C., 1994d, pp. 421-428.
(12) Thorhaug, A., “Oil Spills in the Tropics and Subtropics,” Pollution in Tropical Aquatic Systems, Chapter 4, D.W. Connell and D.W. Hawker, Editors,
CRC Press, Boca Raton, FL, 1991b, pp. 99-127.
(13) Dahlin, J. A. and Michel, J., NOAA HAZMAT, “Recovery of Mangrove Habitats at the Vista Bella Oil Spill Site,” Hazmat Report 95-3, NOAA
Hazmat, Seattle, WA, 1994.
(14) Dicks, B., “Oil and the Black Mangrove, Avicennia marina in the Northern Red Sea,” Marine Pollution Bulletin, Vol 17, No. 11, 1986, pp. 500-503.
(15) Teas, H. J., Lessard, R. R., Canevari, G. P., Brown, C. D., an
...
