ASTM B101-22

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: B101 − 12 (Reapproved 2019) B101 − 22
Standard Specification for
Lead-Coated Copper Sheet and Strip for Building
Construction
This standard is issued under the fixed designation B101; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
This standard has been approved for use by agencies of the U.S. Department of Defense.
1. Scope*
1.1 This specification establishes the requirements for lead-coated copper sheet and strip in flat lengths (or in coils) in
ounce-weight thicknesses for roofing, flashing, gutters, downspouts, and for the general sheet metalwork in for outside building
construction. The lead coating is applied by hot dipping.
1.1.1 Products produced to this specification are not intended for electrical applications.
1.1.2 This product is not designed to be used for decorative, ornamental, or wall panel applications.
1.2 Products produced to this specification are not intended for electrical applications.
1.2 Units—The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical
conversions to SI units that are provided for information only and are not considered standard.
NOTE 1—A companion specification for copper sheet and strip for building construction is Specification B370.
1.3 The following hazard caveat pertains to the test method portion, Section 17, of this specification. This standard does not
purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to
establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior
to use.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
B248 Specification for General Requirements for Wrought Copper and Copper-Alloy Plate, Sheet, Strip, and Rolled Bar
B370 Specification for Copper Sheet and Strip for Building Construction
B846 Terminology for Copper and Copper Alloys
This specification is under the jurisdiction of Committee B05 on Copper and Copper Alloys and is the direct responsibility of Subcommittee B05.01 on Plate, Sheet, and
Strip.
Current edition approved Oct. 1, 2019May 1, 2022. Published October 2019May 2022. Originally approved in 1935. Last previous edition approved in 20122019 as
B101–12. –12 (2019). DOI: 10.1520/B0101–12R19.10.1520/B0101-22.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
B101 − 22
B950 Guide for Editorial Procedures and Form of Product Specifications for Copper and Copper Alloys
E8/E8M Test Methods for Tension Testing of Metallic Materials
E29 Practice for Using Significant Digits in Test Data to Determine Conformance with Specifications
E37 Test Methods for Chemical Analysis of Pig Lead (Withdrawn 2020)
E46 Test Methods for Chemical Analysis of Lead- and Tin-Base Solder (Withdrawn 1994)
E62 Test Methods for Chemical Analysis of Copper and Copper Alloys (Photometric Methods) (Withdrawn 2010)
E112 Test Methods for Determining Average Grain Size
E478 Test Methods for Chemical Analysis of Copper Alloys
3. General Requirements
3.1 The following sections of Specification B248 constitute a part of this specification:
3.1.1 Significance of numerical limits,
3.1.2 Inspection,
3.1.3 Rejection and rehearing,
3.1.4 Certification,
3.1.5 Mill test Test reports, and
3.1.6 Packaging and package marking.
3.2 In addition, when a section with a title identical to that referenced in 3.1, above, appears in this specification, it contains
additional requirements that supplement those appearing in Specification B248.
4. Terminology
4.1 For definitions of terms related to copper and copper alloys, refer to Terminology B846.
TABLE 12 Mechanical Properties of Uncoated Sheet
B
Yield Strength, at Approximate Rockwell Hardness
A
Temper Designation Tensile Strength, ksi (MPa)
(for Information Only)
0.5 % Extension
F Scale Superficial 30 T
Under Load, min,
Standard Former Min Max
ksi (MPa) Min Max Min Max
O60 soft 30 (205) 38 (260) . . 65 . 31
H00 cold-rolled 32 (220) 40 (275) 20 (140) 54 82 15 49
H01 cold-rolled (high yield) 34 (235) 42 (290) 28 (195) 60 84 18 51
A
ksi = 100 psi.
B
Rockwell hardness values apply as follows: The F scale applies to metal 0.020 in. (0.508 mm) and over in thickness; the superficial 30T scale applies to metal 0.012
in. (0.305 mm) to 0.020 in. (0.508 mm) in thickness.
The last approved version of this historical standard is referenced on www.astm.org.
B101 − 22
4.2 Definitions of Terms Specific to This Standard:
4.2.1 coil—a length of the product wound into a series of connected turns.
4.2.1.1 Discussion—
The unqualified term “coil” as applied to “flat product” usually refers to a coil in which the product is spirally wound, with the
successive layers on top of one another. (Sometimes called a “roll.”)
4.2.2 flashing, n—an impervious lead-coated copper sheet or strip used in a building envelope to create a barrier to prevent water
penetration or direct the flow of moisture.
4.2.2.1 Discussion—
This can include, but is not limited to, the heads of windows and doors, the edge components of roof systems, changes in building
planes, around chimneys, roof vents, skylights, decks and other penetrations, and other conditions requiring a watertight or
water-shedding solution.
4.2.3 lead-coated copper sheet (for building construction), n—a rolled flat product over 24 in. (610 mm) in width and of
ounce-weight thickness from 8 oz (227 g) to 48 oz (1361 g).
4.2.4 lead-coated strip (for building construction), n—a rolled flat product up to and including 24 in. (610 mm) in width and of
ounce-weight thickness from 8 oz (227 g) to 48 oz (1361 g).
4.2.5 lengths, mill, n—straight lengths, including ends, that are conveniently manufactured in the mills.
4.2.5.1 Discussion—
Full length pieces are usually 8, 10, or 12 ft (2.44, 3.05, or 3.66 m) 8 ft, 10 ft, or 12 ft (2.44 m, 3.05 m, or 3.66 m) and subject
to established length tolerances.
4.2.6 ounce-weight—the weight of uncoated copper sheet or strip expressed in ounces per square foot.
4.2.7 thickness, ounce-weight, n—the metal thickness that corresponds to the ounce weight.
5. Ordering Information
5.1 Include the following specified choices when placing orders for product under this specification, as applicable:
5.1.1 ASTM designation and year of issue.
5.1.2 Temper (Section 8 and Table 1),Table 2),
5.1.3 How furnished: flat lengths or in coils,
5.1.4 Quantity: total weight or sheets of each size,
5.1.5 Ounce-weight or ounce-weight thickness of the uncoated copper sheet or strip ((TableTable 2), 3),
5.1.6 Dimensions: width and length (Section 12),
TABLE 23 Sheet Weights
Minimum Weight of
Nominal Weights and Thickness
Lead–Coated
of Bare Copper Sheets
Copper Sheet
Ounce-Weight, Ounce-Weight
2 2
oz/ft (g ⁄m )
2 A
oz/ft Thickness, in. (mm)
24 0.0323 (0.820) 25.0 (7625)
20 0.0270 (0.686) 21.2 (6466)
16 0.0216 (0.549) 17.3 (5276)
12 0.0162 (0.411) 13.2 (4026)
A 3 3
Based upon a density of 0.322 lb/in. (8.91 g/cm ).
B101 − 22
5.1.7 Certification, where required (see 5.1.4),
5.1.8 Mill test report, where required (see 5.1.5), and
5.1.9 If the material being purchased is intended for use by agencies of the U.S. Government, refer to Section 11.
5.1.10 Other variations in coating or texture shall be furnished by agreement in writing between the purchaser and the
manufacturer or supplier.
5.2 The following options are available and, when required, shall be specified at the time of placing of the order:
5.2.1 Heat identification or traceability details.
5.2.2 Certification, where required (see 5.1.4),
5.2.3 Test report, where required (see 5.1.5), and
5.2.4 If the material being purchased is intended for use by agencies of the U.S. government, refer to Section 11.
5.2.5 Other variations in coating or texture shall be furnished by agreement in writing between the purchaser and the manufacturer
or supplier.
6. Materials and Manufacture
6.1 Materials:
6.1.1 The material of manufacture shall be in the form of copper strip or sheet that conforms to the requirements of Specification
B370.
6.1.2 The lead coating shall conform to the chemical requirements of Table 31.
NOTE 2—Due to the discontinuous nature of the processing of castings into wrought products, it is not always practical to identify a specific casting
analysis with a specific quantity of finished material.
6.1.2 The copper sheet or strip to be lead coated shall be manufactured by any process that provides a finished product that
conforms to the requirements of Specification B370.
6.2 Manufacture:
6.2.1 The lead coating product shall be applied to manufactured by hot dipping the copper sheet or strip by hot dipping in a bath
of molten lead.lead to produce the finished product.
6.2.2 Unless otherwise specified, the lead coating shall be applied to the copper sheet or strip after slitting and cutting to the
specified length.
TABLE 31 Chemical Requirements for Lead
Used to Coat Copper Sheet
Composition, %
Element (Maximum unless shown
as range or remainder)
Silver 0.02
Copper 0.08
Arsenic plus antimony 0.10
Zinc 0.005
Iron 0.01
Bismuth 0.08
Lead remainder
Tin 3.0-4.0
Phosphorus 0.03
B101 − 22
6.2.3 Unless otherwise specified, the lead coating shall be applied to the copper strip before slitting.
7. Chemical Composition
7.1 The copper sheet or strip shall have a minimum copper, including silver, content of 99.5 %.
7.2 Any copper that complies with 7.1 shall be acceptable.
7.3 If limits for unnamed elements are required, they shall be established and analysis required by agreement between the
manufacturer or supplier and purchaser.
7.4 The lead coating shall conform to the chemical requirements of Table 31.
8. Temper
8.1 The standard tempers of the uncoated copper sheet and strip described in this specification are given in Table 12.
8.1.1 Annealed Temper O60.
8.1.2 Cold rolled tempers H00 (eighth hard, cold-rolled); and H01 (quarter hard, cold-rolled high yield).
9. Physical Property Requirements Grain Size for Annealed Temper
9.1 Although no minimum grain size is specified for soft-temper material, it shall be fully recrystallized.Grain Size Requirement:
9.1.1 The soft annealed temper uncoated product furnished under this specification shall have a minimum grain size of 0.010 mm
when tested to Test Methods E112.
9.1.2 Acceptance or rejection for the soft temper based upon the physical properties shall depend on the grain size.
10. Mechanical Property Requirements
10.1 Tensile and Yield Strength Requirements:
10.1.1 The uncoated product furnished under this specification shall conform to the tensile and yield strength requirements
prescribed in Table 12 when tested in accordance with Test Methods E8/E8M. Tension test specimens shall be taken so that the
longitudinal axis of such specimens is parallel to the direction of rolling.
10.1.2 Acceptance or rejection based upon mechanical propert
...
