ASTM A794/A794M-18

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: A794/A794M − 12 (Reapproved 2017) A794/A794M − 18
Standard Specification for
Commercial Steel (CS), Sheet, Carbon (0.16 % Maximum to
0.25 % Maximum), Cold-Rolled
This standard is issued under the fixed designation A794/A794M; the number immediately following the designation indicates the year
of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval.
A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
This standard has been approved for use by agencies of the U.S. Department of Defense.
1. Scope*
1.1 This specification covers cold-rolled commercial steel (CS) sheet in coils and cut lengths, in which the maximum of the
specified carbon range is over 0.15 and not over 0.25 %, and the maximum of the specified manganese range is not over 0.90 %.
This material is ordered to chemical composition.
1.2 This specification is not applicable to the steels covered in Specifications A109/A109M and A1008/A1008M.
1.3 The values stated in either SI units or inch-pound units are to be regarded separately as standard. The values stated in each
system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the
two systems may result in non-conformance with the standard.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
A109/A109M Specification for Steel, Strip, Carbon (0.25 Maximum Percent), Cold-Rolled
A568/A568M Specification for Steel, Sheet, Carbon, Structural, and High-Strength, Low-Alloy, Hot-Rolled and Cold-Rolled,
General Requirements for
A749/A749M Specification for Steel, Strip, Carbon and High-Strength, Low-Alloy, Hot-Rolled, General Requirements for
A1008/A1008M Specification for Steel, Sheet, Cold-Rolled, Carbon, Structural, High-Strength Low-Alloy, High-Strength
Low-Alloy with Improved Formability, Solution Hardened, and Bake Hardenable
E527 Practice for Numbering Metals and Alloys in the Unified Numbering System (UNS)
2.2 Society of Automotive Engineers Standard:
J 1086 Numbering Metals and Alloys
3. Ordering Information
3.1 It is the purchaser’s responsibility to specify in the purchase order all ordering information necessary to purchase the needed
material. Examples of such information, include but are not limited to, the following:
3.1.1 ASTM specification number and year of issue,
3.1.2 Name of material (cold-rolled commercial steel (CS) sheet),
3.1.3 Grade designation or chemical composition or both,
3.1.4 Copper-bearing steel (if required),
3.1.5 Finish; indicate unexposed with matte (dull) finish, or exposed with either matte (dull), commercial bright or luster finish,
as required,
3.1.6 Specify oiled or not oiled, as required,
This specification is under the jurisdiction of ASTM Committee A01 on Steel, Stainless Steel and Related Alloysand is the direct responsibility of Subcommittee A01.19
on Steel Sheet and Strip.
Current edition approved Sept. 1, 2017Sept. 1, 2018. Published September 2017September 2018. Originally approved in 1982. Last previous edition approved in 20122017
as A794/A794M – 12.A794/A794M – 12 (2017). DOI: 10.1520/A0794_A0794M-12R17.10.1520/A0794_A0794M-18.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
Available from Society of Automotive Engineers (SAE), 400 Commonwealth Dr., Warrendale, PA 15096-0001, http://www.sae.org.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
A794/A794M − 18
3.1.7 Dimensions (thickness, width, and whether cut lengths or coils),
NOTE 1—Not all producers are capable of meeting all the limitations of the thickness tolerance tables in Specification A568/A568M. The purchaser
should contact the producer regarding possible limitations prior to placing an order.
3.1.8 Coil size (must include inside diameter, outside diameter, and maximum mass),
3.1.9 Quantity,
3.1.10 Application (show part identification and description),
3.1.11 Cast or heat analysis report (request, if required), and
3.1.12 Special requirements (if any).
3.1.12.1 When the purchaser requires thickness tolerances for ⁄8 in. [10 mm] minimum edge distance (see Supplementary
Requirement in Specification A568/A568M), this requirement shall be specified in the purchase order or contract.
NOTE 2—A typical ordering description is as follows: ASTM A794-XX, Cold-Rolled Commercial Steel (CS), Grade 1018, Exposed, Matte Finish,
Oiled, 0.030 by 36 by 96 in., 100 000 lb., for Part No. 5226 Steel Shelving, or, ASTM A794M-XX, Cold-Rolled Commercial Steel (CS), Grade 1018,
Exposed, Matte Finish, Oiled 0.75 by 915 by 2438 mm, 45,000 kg, for Part N. 5226 Steel Shelving.
4. Manufacture
4.1 Condition—The material shall be furnished in the annealed and temper-rolled condition but may be supplied full hard if
specified.
5. Chemical Composition
5.1 The cast or heat (formerly ladle) analysis of the steel shall conform to the chemical requirements shown in Table 1, or
chemical compositi
...
