SIST EN 62391-1:2016/AC:2019

(Corrigendum)

Fixed electric double-layer capacitors for use in electric and electronic equipment - Part 1: Generic specification (IEC 62391-1:2015/COR2:2019)

Fixed electric double-layer capacitors for use in electric and electronic equipment - Part 1: Generic specification (IEC 62391-1:2015/COR2:2019)

IEC 62391-1:2015(E) is available as IEC 62391-1:2015 RLV which contains the International Standard and its Redline version, showing all changes of the technical content compared to the previous edition.
IEC 62391-1:2015(E) applies to fixed electric double-layer capacitors (hereafter referred to as capacitor(s)) mainly used in d.c. circuits of electric and electronic equipment. This part of IEC 62391 establishes standard terms, inspection procedures and methods of test for use in sectional and detail specifications of electronic components for quality assessment or any other purpose. This edition includes the following significant technical changes with respect to the previous edition:
a) enhancement of the scope to include electric (high power) application;
b) implementation of Annex Q, replacing Clause 3 in the first edition;
c) in addition, minor revisions related to tables, figures and references.

Elektrische Doppelschichtkondensatoren zur Verwendung in elektrischen und elektronischen Geräten - Teil 1: Fachgrundspezifikation (IEC 62391-1:2015/COR2:2019)

Condensateurs électriques fixes à double couche utilisés dans les équipements électriques et électroniques - Partie 1: Spécification générique (IEC 62391-1:2015/COR2:2019)


   L'IEC 62391-1:2015 s'applique aux condensateurs électriques fixes à double couche (appelés ci-après condensateurs) principalement utilisés dans des circuits à courant continu d'équipements électriques et électroniques. La présente partie de l'IEC 62391 définit les termes normalisés, les procédures de contrôle et les méthodes d’essai utilisés dans les spécifications intermédiaires et particulières des composants électroniques dans le cadre de l’assurance de la qualité, ainsi qu’à d’autres fins.
   La présente édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
   a)   renforcement du domaine d'application pour inclure des applications électriques (haute puissance);
   b)   mise en œuvre de l’Annexe Qqui remplace l’Article 3 de la première édition;
   c)   en plus, des révisions mineures des tableaux, valeurs et références.

Nespremenljivi električni dvoplastni kondenzatorji za električno in elektronsko opremo - 1. del: Rodovna specifikacija - Popravek AC (IEC 62391-1:2015/COR2:2019)

General Information

Status
Published
Publication Date
03-Sep-2019
ICS
31.060.10 - Fixed capacitors
Technical Committee
I11 - Imaginarni 11
Current Stage
6060 - National Implementation/Publication (Adopted Project)
Start Date
21-Aug-2019
Due Date
26-Oct-2019
Completion Date
04-Sep-2019
Ref Project
EN 62391-1:2016/AC:2019-08 - Fixed electric double-layer capacitors for use in electric and electronic equipment - Part 1: Generic specification

Relations

Replaced By
SIST EN IEC 62391-1:2023 - Fixed electric double-layer capacitors for use in electric and electronic equipment - Part 1: Generic specification (IEC 62391-1:2022)
Effective Date
29-Nov-2022
Corrects
SIST EN 62391-1:2016 - Fixed electric double-layer capacitors for use in elecric and electronic equipment - Part 1: Generic specification
Effective Date
02-Jul-2019
Revised
SIST EN IEC 62391-1:2023 - Fixed electric double-layer capacitors for use in electric and electronic equipment - Part 1: Generic specification (IEC 62391-1:2022)
Effective Date
27-Apr-2021

Buy Standard

EN 62391-1:2016/AC:2019EN 62391-1:2016/AC:2019
PreviousNext
Corrigendum
EN 62391-1:2016/AC:2019
English and French language
3 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)

SLOVENSKI STANDARD
SIST EN 62391-1:2016/AC:2019
01-oktober-2019
Nespremenljivi električni dvoplastni kondenzatorji za električno in elektronsko
opremo - 1. del: Rodovna specifikacija - Popravek AC (IEC 62391-
1:2015/COR2:2019)
Fixed electric double-layer capacitors for use in electric and electronic equipment - Part
1: Generic specification (IEC 62391-1:2015/COR2:2019)
Elektrische Doppelschichtkondensatoren zur Verwendung in elektrischen und
elektronischen Geräten - Teil 1: Fachgrundspezifikation (IEC 62391-1:2015/COR2:2019)
Condensateurs électriques fixes à double couche utilisés dans les équipements
électriques et électroniques - Partie 1: Spécification générique (IEC 62391-
1:2015/COR2:2019)
Ta slovenski standard je istoveten z: EN 62391-1:2016/AC:2019-08
ICS:
31.060.10 Fiksni kondenzatorji Fixed capacitors
SIST EN 62391-1:2016/AC:2019 en,fr
