SIST EN 12058:2004

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Natural stone products - Slabs for floors and stairs - RequirementsProduits en pierre naturelle - Dalles de revetement de sols et d'escaliers - ExigencesNatursteinprodukte - Bodenplatten und Stufenbeläge - AnforderungenTa slovenski standard je istoveten z:EN 12058:2004SIST EN 12058:2004en91.100.15ICS:SLOVENSKI
STANDARDSIST EN 12058:200401-december-2004

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 12058October 2004ICS 91.100.15English versionNatural stone products - Slabs for floors and stairs -RequirementsProduits en pierre naturelle - Dalles de revêtement de solset d'escaliers - ExigencesNatursteinprodukte - Bodenplatten und Stufenbeläge -AnforderungenThis European Standard was approved by CEN on 9 July 2004.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2004 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 12058:2004: E

Sampling.19 A.1 General.19 A.2 Principles of sampling.19 A.3 Taking bulk samples.19 A.4 Preparing a sampling plan.19 A.5 Sampling apparatus.20 A.6 Sampling methods.20 A.6.1 General.20 A.6.2 Sampling from quarries.20 A.6.3 Sampling from plants.21 A.6.4 Sampling from buildings.21 A.7 Marking, packaging and dispatch of the samples.21 A.8 Sampling report.21

Clauses of this European Standard addressing the provisions of the EU Construction Products Directive.23 ZA.1 Scope and relevant characteristics.23 ZA.2 Procedures for the attestation of conformity.26 ZA.3 CE marking and labelling.27 ZA.3.1 CE marking.27 ZA.3.2 Reference model for marking and labelling.27 ZA.4 EC Declaration of conformity.29 Bibliography.30

2006. This document has been prepared under a mandate given to CEN by the European Commission and the European Free Trade Association, and supports essential requirements of EU Directive(s). For relationship with EU Directive(s), see informative Annex ZA, which is an integral part of this document. This document is one of a series of standards for specifications of natural stone products which includes the following: EN 1467, Natural stone - Rough blocks - Requirements EN 1468, Natural stone - Rough slabs - Requirements prEN 1469, Natural stone products – Slabs for cladding - Requirements EN 12057, Natural stone products - Modular tiles - Requirements. EN 12058, Natural stone products - Slabs for floors and stairs - Requirements. prEN 12059, Natural stone products - Dimensional stone work - Requirements. Other standards on natural stone are produced by: CEN/TC 178 Paving units and kerbs EN 1341, Slabs of natural stone for external paving - Requirements and test methods. EN 1342, Setts of natural stone for external paving - Requirements and test methods. EN 1343, Kerbs of natural stone for external paving - Requirements and test methods. CEN/TC 128 Roof covering products for discontinuous laying and products for wall cladding EN 12326-2, Slate and stone products for discontinuous roofing and cladding - Part 2: Methods of test. EN 12326-1, Slate and stone products for discontinuous roofing and cladding - Part 1: Product specification. CEN/TC 125 Masonry EN 771-6, Specification for masonry units - Part 6: Natural stone masonry units. Other standards are relevant to aggregates for concrete, roads, railways and armourstone (under study within CEN/TC 154). According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.

1 Scope This document specifies requirements for flat natural stone slabs fabricated for use as floor and stair coverings. It does not cover mineral aggregates and artificial agglomerated stone material and does not cover installation. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 1925, Natural stone test methods - Determination of water absorption coefficient by capillarity. EN 1936, Natural stone test methods - Determination of real density and apparent density and of total and open porosity. EN 12371, Natural stone test methods - Determination of frost resistance. EN 12372, Natural stone test methods - Determination of flexural strength under concentrated load. EN 12407, Natural stone test methods - Petrographic examination. EN 12440, Natural stone - Denomination criteria. EN 12524, Building materials and products - Hygrothermal properties - Tabulated design values. EN 12670:2001, Natural stone - Terminology. EN 13161, Natural stone test methods - Determination of flexural strength under constant moment. EN 13373, Natural stone test methods - Determination of geometric characteristics on units. EN 13501-1, Fire classification of construction products and building elements - Part 1: Classification using test data from reaction to fire tests. EN 13755, Natural stone test methods - Determination of water absorption at atmospheric pressure. EN 14157, Natural stone test methods - Determination of the abrasion resistance. EN 14066, Natural stone test methods - Determination of resistance to ageing by thermal shock. EN 14231, Natural stone test methods - Determination of the slip resistance by means of the pendulum tester. EN ISO 12572, Hygrothermal performance of building materials and products - Determination of water vapour transmission properties (ISO 12572:2001). NOTE Besides the documents for test methods mentioned in this Clause, there exist further documents which can be used for scientific examinations, but which are not relevant for the application in practice according to this document.

Mortar as defined in EN 998-1. Adhesives as defined in EN 12004. 3.1.1 skirting flat piece of natural stone obtained by cutting or splitting at a nominal thickness > 12 mm. It is laid on each wall surrounding a flooring and in contact with it 3.2 slab for stairs flat piece of natural stone obtained by cutting or splitting at a nominal thickness >12 mm (except risers) to form the horizontal part of a stair step (tread) or the vertical part of a stair step (riser)
Figure 1 – Dimensions of slabs for floors
3.3 dimensions of slabs for floors and stairs
3.3.1 length l, width b and thickness d are the dimensions of a slab for floors. The dimensions are given in the stated sequence in millimetres (see Figure 1) 3.3.2 length l, width b and thickness d are the dimensions of a slab for stairs, separated for treads and risers. The dimensions are given in the stated sequence in millimetres (see Figure 2)

Key 1
Tread 2
Riser Figure 2 – Dimensions of slabs for stairs 4 Requirements 4.1 Requirements for geometric characteristics 4.1.1 General All measurements shall be carried out in accordance with EN 13373 and all measured values of individual units shall fall within the required tolerances. 4.1.2 Requirements for thickness The thickness shall not deviate from the nominal thickness by more than given in Table 1. Table 1 – Tolerances on the nominal thickness Nominal thickness
in mm Tolerance More than 12 Up to and including 15 ± 1,5 mm More than 15 Up to and including 30 ± 10 % More than 30 Up to and including 80 ± 3 mm More than 80 ± 5 mm
Stricter tolerances may be declared by the manufacturer.

Stricter tolerances may be declared by the manufacturer. 4.1.5 Requirements for angles and special shapes The permissible tolerance at any point shall be as stated in Table 2 (see Figure 3). Each slab angle shall be in accordance with the agreed geometry. Pieces of special or irregular shape shall be checked for compliance with the required shape by use of a suitable template, the permissible tolerance at any point shall be as stated in Table 2 (see Figure 3). Stricter tolerances may be declared by the manufacturer.

Key 1
Nominal size 2
The slab sides shall fall within the two dotted lines indicating the tolerances of length and width according to
Table 2 Figure 3 – Example of tolerances on angles 4.1.6 Commercial sizes of slabs for floors and stairs Commercial sizes shall be based on the area of the smallest possible circumscribed rectangle measured in square metres accurate to two decimal places. 4.1.7 Requirements for surface finish 4.1.7.1 General Surface finishes shall be carried out uniformly to the edges of the slabs for floors and stairs. The surface finishing of some types of stones may typically involve the use of patching, fillers or adhesives for natural holes, faults or cracks; this is to be considered as part of the normal processing. In such cases the type of treatment as well as the type and nature of additional materials shall be declared. 4.1.7.2 Requirements for surfaces after surface finishing Surfaces shall have a regular appearance as a function of the finishing process and shall be worked to meet the specified finish on all exposed surfaces (e.g. making reference to samples, see 4.2.3), agreed in accordance with samples submitted and agreed beforehand between the purchaser and supplier. NOTE 1 Surfaces obtained by grinding are, for example: – rough ground surfaces obtained, e.g. by means of a grinding disk of grain size F 60; – medium ground surfaces obtained, e.g. by means of a grinding disk of grain size F 120; – fine ground surfaces obtained, e.g. by means of a grinding disk of grain size F 220; – matt finished surfaces obtained, e.g. by means of a
grinding disk with grain size F 400; – highly polished surfaces obtained, e.g. by means of a polishing disk or felt. NOTE 2 Surfaces obtained by means of percussion tools are, for example: – bush hammered surfaces (see EN 12670:2001, 2.3.8)*;

Key 1
Reference sample 2
Production sample 3
Daylight Figure 4 — Comparison between production sample and reference sample 4.2.4 Flexural strength This characteristic shall always be declared. The flexural strength shall be determined using the test method in EN 12372 or EN 13161 and the mean value, lower expected value and document deviation shall be declared. NOTE An identification test as defined in EN 12372 or EN 13161 is normally carried out for the purpose of CE marking. However, where the surface finish of the delivered product is known, the test may be carried out with this finish, in accordance with the technological tests defined in EN 12372 or EN 13161. 4.2.5 Bond strength adhesion This characteristic is within the responsibility of the person in charge of the execution of the tiling. The value of the bond strength adhesion depends on the condition of the layer, the type of adhesive/mortar and the surface finish of the back face. The person responsible shall refer to existing national codes of practice.
...
