SIST EN 300 175-7 V2.5.1:2013 defines the security features of the Digital Enhanced Cordless Telecommunications (DECT) Common Interface (CI). It specifies the security architecture, the types of cryptographic algorithms required, how algorithms are to be used, cryptographic parameters, keying material and processes, and how these features are integrated into the CI at the Network (NWK) and Medium Access Control (MAC) layers. The document covers management and operational relationships with DECT fixed systems and local network configurations and includes provisions for New Generation DECT and DECT Ultra Low Energy (ULE).
Key topics and technical requirements
- Security architecture and services: Authentication (PT/FT/user), mutual authentication, data confidentiality and key management at the CI.
- Algorithm-independent design: The architecture supports standard DECT algorithms, proprietary algorithms, or combinations - with guidance on usage and interworking limitations (e.g., roaming).
- Cryptographic building blocks:
- Authentication algorithms (DSAA, DSAA2)
- Key stream generators for MAC-layer encryption (DSC, DSC2)
- CCM authenticated encryption (AES-based) for combined confidentiality and integrity
- Stronger algorithm options: DSAA2, DSC2 and CCM (all AES-based) introduced to provide enhanced protection compared to legacy DSAA/DSC.
- Key types and derivation: Definitions and processes for Authentication Key (K), session keys (KS, KS'), Cipher Key (CK), Derived Cipher Key (DCK), Static Cipher Key (SCK), Default Cipher Key (DefCK), and related derivation/re-key procedures.
- Integration into CI protocols:
- NWK layer procedures for key association, transfer and re-keying
- MAC layer procedures for encryption, initialization vectors (IV), key stream synchronization, mode switching, and handover with uninterrupted ciphering
- Management and operational notes: Where authentication and ciphering functions may reside (network elements, detachable modules, PP devices) and the impact of proprietary algorithms on interoperability.
- Scope exclusions: The standard does not prescribe implementation choices (e.g., whether certain algorithms are embedded in hardware or detachable modules).
Practical applications and who uses this standard
- Device manufacturers (DECT handsets, base stations, PPs) - to implement CI-compliant security features.
- Firmware and protocol developers - to integrate NWK and MAC level encryption, authentication and CCM authenticated encryption.
- Network operators and service providers - to design secure DECT deployments, roaming policies and key management procedures.
- IoT/M2M solution designers - especially for ULE-based low-power applications requiring lightweight secure links.
- Security architects and integrators - for assessing interoperability, algorithm choices and operational security posture.
- Test labs and compliance bodies - for evaluating conformance to DECT CI security requirements.
Related standards and keywords
- Related: other parts of the EN 300 175 DECT Common Interface series and DECT system specifications.
- Keywords: DECT security, Common Interface (CI), authentication, encryption, CCM, DSAA2, DSC2, AES, key management, MAC layer, NWK layer, New Generation DECT, DECT ULE, M2M, IoT.
ETSI EN 300 175-7 V2.5.0 (2013-04) - Digital Enhanced Cordless Telecommunications (DECT); Common Interface (CI); Part 7: Security features
ETSI EN 300 175-7 V2.5.1 (2013-08) - Digital Enhanced Cordless Telecommunications (DECT); Common Interface (CI); Part 7: Security features
Frequently Asked Questions
SIST EN 300 175-7 V2.5.1:2013 is a standard published by the Slovenian Institute for Standardization (SIST). Its full title is "Digital Enhanced Cordless Telecommunications (DECT) - Common Interface (CI) - Part 7: Security features". This standard covers: The present document is one of the parts of the specification of the Digital Enhanced Cordless Telecommunications (DECT) Common Interface (CI). The present document specifies the security architecture, the types of cryptographic algorithms required, the way in which they are to be used, and the requirements for integrating the security features provided by the architecture into the DECT CI. It also describes how the features can be managed and how they relate to certain DECT fixed systems and local network configurations. The security architecture is defined in terms of the security services which are to be supported at the CI, the mechanisms which are to be used to provide the services, and the cryptographic parameters, keys and processes which are associated with these mechanisms. The security processes specified in the present document are each based on one of three cryptographic algorithms: - an authentication algorithm; - a key stream generator for MAC layer encryption; and - a key stream generator plus a Message Authentication Code generator for CCM authenticated encryption. The architecture is, however, algorithm independent, and either the DECT standard algorithms, or appropriate proprietary algorithms, or indeed a combination of both can, in principle, be employed. The use of the employed algorithm is specified in the present document. Integration of the security features is specified in terms of the protocol elements and processes required at the Network (NWK) and Medium Access Control (MAC) layers of the CI. The relationship between the security features and various network elements is described in terms of where the security processes and management functions may be provided. The present document does not address implementation issues. For instance, no attempt is made to specify whether the DSAA or DSAA2 should be implemented in the PP at manufacture, or whether the DSAA, DSAA2 or a proprietary authentication algorithm should be implemented in a detachable module. Similarly, the present document does not specify whether the DSC or DSC2 should be implemented in hardware in all PPs at manufacture, or whether special PPs should be manufactured with the DSC, DSC2 or proprietary ciphers built into them. The security architecture supports all these options, although the use of proprietary algorithms may limit roaming and the concurrent use of PPs in different environments. Within the standard authentication algorithms, DSAA2, DSC2 and CCM are stronger than DSAA and DSC and provide superior protection. DSAA2 and DSC2 are based on AES [10] and were created in 2011. CCM is also based on AES [10] and was added to the standard in 2012. The present document includes New Generation DECT, a further development of the DECT standard introducing wideband speech, improved data services, new slot types and other technical enhancements. The present document also includes DECT Ultra Low Energy (ULE), a low rate data technology based on DECT intended for M2M applications with ultra low power consumption.
The present document is one of the parts of the specification of the Digital Enhanced Cordless Telecommunications (DECT) Common Interface (CI). The present document specifies the security architecture, the types of cryptographic algorithms required, the way in which they are to be used, and the requirements for integrating the security features provided by the architecture into the DECT CI. It also describes how the features can be managed and how they relate to certain DECT fixed systems and local network configurations. The security architecture is defined in terms of the security services which are to be supported at the CI, the mechanisms which are to be used to provide the services, and the cryptographic parameters, keys and processes which are associated with these mechanisms. The security processes specified in the present document are each based on one of three cryptographic algorithms: - an authentication algorithm; - a key stream generator for MAC layer encryption; and - a key stream generator plus a Message Authentication Code generator for CCM authenticated encryption. The architecture is, however, algorithm independent, and either the DECT standard algorithms, or appropriate proprietary algorithms, or indeed a combination of both can, in principle, be employed. The use of the employed algorithm is specified in the present document. Integration of the security features is specified in terms of the protocol elements and processes required at the Network (NWK) and Medium Access Control (MAC) layers of the CI. The relationship between the security features and various network elements is described in terms of where the security processes and management functions may be provided. The present document does not address implementation issues. For instance, no attempt is made to specify whether the DSAA or DSAA2 should be implemented in the PP at manufacture, or whether the DSAA, DSAA2 or a proprietary authentication algorithm should be implemented in a detachable module. Similarly, the present document does not specify whether the DSC or DSC2 should be implemented in hardware in all PPs at manufacture, or whether special PPs should be manufactured with the DSC, DSC2 or proprietary ciphers built into them. The security architecture supports all these options, although the use of proprietary algorithms may limit roaming and the concurrent use of PPs in different environments. Within the standard authentication algorithms, DSAA2, DSC2 and CCM are stronger than DSAA and DSC and provide superior protection. DSAA2 and DSC2 are based on AES [10] and were created in 2011. CCM is also based on AES [10] and was added to the standard in 2012. The present document includes New Generation DECT, a further development of the DECT standard introducing wideband speech, improved data services, new slot types and other technical enhancements. The present document also includes DECT Ultra Low Energy (ULE), a low rate data technology based on DECT intended for M2M applications with ultra low power consumption.
SIST EN 300 175-7 V2.5.1:2013 is classified under the following ICS (International Classification for Standards) categories: 33.070.30 - Digital Enhanced Cordless Telecommunications (DECT). The ICS classification helps identify the subject area and facilitates finding related standards.
