(Main)Aerospace series - Pipe coupling 8°30' in titanium alloy - Elbows 90° welded ends
Aerospace series - Pipe coupling 8°30' in titanium alloy - Elbows 90° welded ends
This standard specifies the characteristics of elbows 90 , welded ends, for pipe couplings 8 30', in titanium alloy, for
aerospace applications.
Nominal pressure: up to 28 000 kPa
Temperature range: 55 C to 135 C
Luft- und Raumfahrt - Rohrverschraubung 8°30' aus Titanlegierung - Winkelverschraubungen 90° mit Anschweißenden
Diese Norm legt die Eigenschaften von Winkelverschraubungen 90° mit Anschweißenden, für Rohrverschraubungen 8°30',
aus Titanlegierung, zur Verwendung in der Luft- und Raumfahrt fest.
Nenndruck: bis 28 000 kPa
Temperaturbereich: 55 °C bis 135 °C
Série aérospatiale - Systeme de raccordement 8°30' en alliage de titane - Raccords coudés a 90° doubles, a souder
La présente norme spécifie les caractéristiques des raccords coudés à 90° à souder, doubles, pour les systèmes de
raccordement 8°30', en alliage de titane, pour applications aérospatiales.
Pression nominale: jusqu'à 28 000 kPa
Plage de température: 55 °C à 135 °C
Aerospace series - Pipe coupling 8°30' in titanium alloy - Elbows 90° welded ends
General Information
- Status
- Published
- Publication Date
- 30-Apr-2004
- Technical Committee
- I08 - Imaginarni 08
- Current Stage
- 6060 - National Implementation/Publication (Adopted Project)
- Start Date
- 01-May-2004
- Due Date
- 01-May-2004
- Completion Date
- 01-May-2004
Relations
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Refers
SIST EN 3312:2012 - Aerospace series - Titanium alloy Ti-6Al-4V - Annealed - Forgings De ≤ 150 mm - Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Overview
SIST EN 4183:2004 is a European standard that defines the technical characteristics for 90° elbows with welded ends, specifically designed for 8°30' pipe couplings made from titanium alloy. This standard is part of the aerospace series, focusing on fluid systems and components operating under demanding conditions. The standard covers configurations intended for aerospace applications, addressing nominal pressures up to 28,000 kPa and service temperatures ranging from -55 °C to 135 °C.
This document ensures high performance, reliability, and compatibility of titanium pipe couplings used in critical aerospace fluid delivery systems.
Key Topics
- Elbow Design: Specifies details for 90° elbows with welded ends corresponding to 8°30' pipe coupling requirements.
- Titanium Alloy Requirements: Covers materials, including requirements for various forms and treatments of titanium alloys per referenced standards.
- Dimensional Specifications: Sets out configuration, dimensions, and allowable tolerances, ensuring interchangeability and secure system integration.
- Surface Finish and Deburring: Details finishing requirements, including surface roughness and internal radiusing, with a strict prohibition on hand deburring to maintain performance and prevent contamination.
- Pressure and Temperature Ratings: Establishes suitability for high operating pressures (up to 28,000 kPa) and wide temperature ranges, as required in aerospace hydraulic and pneumatic systems.
- Marking and Traceability: Requires standard marking practices for easy identification and traceability in aerospace inventories.
Applications
SIST EN 4183:2004 is most relevant for manufacturers, suppliers, system integrators, and maintenance organizations within the aerospace industry. Typical applications include:
- Aerospace Hydraulic Systems: Ensures fluid-tight, high-strength coupling for hydraulic circuits in aircraft.
- Fuel and Pneumatic Lines: Provides reliable connections for fuel, lubrication, and air systems where pressure and temperature performance is critical.
- Spacecraft and Satellite Fluid Systems: Supports stringent material and assembly requirements for space applications.
- Maintenance and Repair Operations (MRO): Facilitates procurement of standard, interchangeable elbow fittings, streamlining maintenance workflows and spare parts management.
These certified elbows help guarantee system safety, weight savings, and corrosion resistance suited for severe aerospace environments.
Related Standards
To ensure full compliance, SIST EN 4183:2004 refers to several related European standards for aerospace pipes, couplings, and materials. Key related documents include:
- EN 2424: Aerospace series - Marking of aerospace products
- EN 2656: Pipe coupling - Coupling ends, welded - Geometric configuration
- EN 3275: Pipe coupling 8°30' up to 28,000 kPa - Dynamic beam seal - Metric series - Technical specification
- EN 3311/EN 3314: Titanium alloy TI-P64001 - Material specifications for bars used in machining
- EN 3312/EN 3315: Titanium alloy TI-P64001 - Specifications for forgings
Referencing these standards ensures harmonized quality and performance across interchangeable parts and assemblies throughout European and global aerospace sectors.
Keywords: SIST EN 4183:2004, aerospace pipe coupling, titanium alloy elbows, welded ends, 90 degree elbow, high pressure fittings, aerospace standards, European standard, aerospace fluid systems, titanium pipe fittings
For enhanced system integrity and regulatory compliance, adoption of SIST EN 4183:2004 streamlines the design, production, and maintenance of critical aerospace piping systems using titanium alloy elbows with welded ends.
