INTERNATIONAL STANDARD ISO 19426-3:2018(E)
Structures for mine shafts —
Part 3:
Sinking stages
1 Scope
This document specifies the design loads and the design procedures for the structural design of stages
and components of stages.
The loads specified in this document are not applicable for the design of stage ropes or sheaves. Rope
sizes are determined in accordance with other standards.
This document does not cover matters of operational safety, or layout of the sinking stage.
This document adopts a limit states design philosophy.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 10721-1, Steel structures — Part 1: Materials and design
ISO 10721-2, Steel structures — Part 2: Fabrication and erection
ISO 19426-1, Structures for mine shafts — Part 1: Vocabulary
ISO 22111, Bases for design of structures — General requirements
ISO 2394, General principles on reliability for structures
EN 1999-1-1, Eurocode 9 — Part 1: Design of aluminium structures — Part 1: General structural rules
EN 1999-1-3, Eurocode 9 — Part 1: Design of aluminium structures — Part 3: Structures susceptible to fatigue
EN 1999-1-4, Eurocode 9 — Par 1: Design of aluminium structures — Part 4: Cold-formed structural
sheeting
CEN/TS 13001-3-1, Cranes — General design — Part 3-1: Limit states and proof competence of steel
structures
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 19426-1 apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at http: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org
© ISO 2018 – All rights reserved 1

---------------------- Page: 6 ----------------------
ISO 19426-3:2018(E)

4 Symbols
3
C lashing unit grab capacity (m )
E emergency load, or load effect (N, Nm)
e stage load eccentricity factor
G
E emergency impact load (N)
a
E emergency impact load on a protective platform (N)
p
E emergency rope load (N)
R
F design load, or load effect (N, Nm)
G permanent load, or load effect (N, Nm)
G jumbo unit self-weight (N)
D
G lashing unit self-weight (N)
L
K weight of the kibble and full load (N)
L span of an element or floor beam (m)
L lashing unit lever arm or the VSM lashing unit grab lever arm (m)
1
L stage jack lever arm horizontal (m)
2
L stage jack lever arm vertical (m)
3
jumbo unit centre of gravity lever arm or the VSM lashing unit centre of gravity
L
4
lever arm (m)
L hydraulic cylinder horizontal lever arm to the boom pivot point (m)
5i
L hydraulic cylinder vertical lever arm to the boom pivot point (m)
6i
M jumbo unit moment about the boom pivot point (Nm)
D
M lashing unit moment about the boom pivot point (Nm)
L
N total number of lashing unit cycles
L
P payload used during doubling-down (N)
2
p uniformly distributed load on stage decks (N/m )
D
P canopy load (N)
A
P blast load (N)
B
P concentrated load on stage decks (N)
C
P total uniformly distributed imposed load on stage decks (N)
D
P stage skid load (N)
G
P kibble cross-head support load (N)
H
2 © ISO 2018 – All rights reserved

---------------------- Page: 7 ----------------------
ISO 19426-3:2018(E)

P stage jack load (N)
J
P stage jack axial load (N)
JA
P stage jack transverse load (N)
JT
P kibble guide load (N)
K
P jumbo unit horizontal load (N)
DH
P jumbo unit vertical load (N)
DV
P horizontal lashing unit load (N)
LH
P vertical lashing unit load (N)
LV
P special load (N)
P
P hand railing load (N/m)
R
P temporary stage support load (N)
T
P winch load (N)
W
Q predominant imposed load, or load effect (N, Nm)
1
Q to Q additional independent imposed loads, or load effects (N, Nm)
3 n
V predominant imposed load, or load effect (N, Nm)
E
W weight of the kibble cross-head (N)
C
W horizontal hydraulic cylinder loads at maximum capacity (N)
CHi
W vertical hydraulic cylinder load (N)
CVi
W weight of the cactus grab including the grab crosshead (N)
G
W weight of rock in the lashing unit grab (N)
PL
W jumbo drilling load (N)
DL
W weight of kibble and full load (N)
K
W rated shutter winch load (N)
R
W weight of the shutter (N)
S
W grab winch safe working load (N)
W
α bellmouth impact factor
B
α impact factor for kibble cross-head support
C
α jumbo unit impact factor
D
α impact factor for emergency rope load
E
α hydraulic cylinder impact factor
H
α kibble guide impact factor
K
© ISO 2018 – All rights reserved 3

---------------------- Page: 8 ----------------------
ISO 19426-3:2018(E)

α lashing unit impact factor
L
α impact factor for stage jack load
J
α winch rated load impact factor
R
α formwork weight impact factor
S
α stage support impact factor
T
η efficiency factor
γ partial load factor for emergency load
e
γ partial load factor for permanent load
fo
γ partial load factor for the predominant imposed load
f1
γ to γ partial load factors for imposed load
f2 fn
Ψ to Ψ load combination factors
2 n
5 Materials
5.1 Steel
5.1.1 Structural steel grades
The materials used for structural steel members should comply with the requirements of EN 10025-1
and EN 10025-2.
5.1.2 High strength steel grades
The materials for high strength steel members should conform to the requirements of EN 10025-6,
EN 10149-1, EN 10149-2, or EN 10149-3.
5.2 Aluminium alloys
The materials used for aluminium alloy members should conform to the requirements of EN 573-3, EN
485-1 to EN 485-4 and EN 755-1 to EN 755-9.
NOTE The preferred alloys include 5083 H32 for 4 mm, 6 mm and 8 mm thick plates or 6082 T651 or 6061
T651 for 10 mm, 12 mm and 15 mm thick plates and 6061 T6 or 6082 T6 for extrusions.
6 Nominal loads
6.1 Permanent load
The permanent load, G, shall be as given in ISO 22111 and shall include the stage and all permanent
fixtures and equipment necessary for the sinking and lining of the shaft.
4 © ISO 2018 – All rights reserved

---------------------- Page: 9 ----------------------
ISO 19426-3:2018(E)

6.2 Imposed loads
6.2.1 Stage deck load
The imposed load, P or P , on stage decks shall be the most adverse of the following:
D C
2
a) a uniformly distributed load, P , of 3 000 N/m , which shall be taken to include concrete build-up
D
loads, unless it can be demonstrated that there will be no build-up of concrete in which case take
2
a uniformly distributed load, P , of 1 500 N/m . P is the total uniformly distributed load on stage
D D
decks which shall be calculated from the uniformly distributed load multiplied by the entire stage
deck area; or
b) a concentrated load, P , of 5 000 N, placed in the position that produces the most severe effects in
C
the member under consideration.
No area reduction factors shall be included when deck loads from one or more decks are being combined.
Due allowance shall be made for possible eccentric application of stage deck loads. Unless it can be
shown that procedures are in place to ensure concentric placement of all deck loads, it shall be assumed
that one half of each stage deck carries a load of 0,75 P , whilst the other half of the deck carries a load
D
of 0,25 P .
D
6.2.2 Shaft formwork winch load
The shaft formwork winch load, P (N), shall be the greater of:
W
P = α W , and (1)
W S S
P = α W (2)
W R R
where
W is the weight of the shaft formwork (N);
S
W is the rated shaft formwork winch load (N);
R
α is the formwork weight impact factor, which may be taken as 2,0;
S
α is the winch rated load impact factor, which may be taken as 1,5.
R
The shaft formwork winch load shall be appropriately distributed between the winches assuming that
any one winch can fail.
6.2.3 Kibble cross-head support load
The kibble cross-head support load, P (N), shall be obtained from the following:
H
P = α W (3)
H C C
where
α is the impact factor for the kibble cross-head support, which if no better information is availa-
C
ble may be taken as 2,0;
W is the weight of the kibble cross-head (N).
C
© ISO 2018 – All rights reserved 5

---------------------- Page: 10 ----------------------
ISO 19426-3:2018(E)

6.2.4 Jumbo unit load
The jumbo unit loads, P , P and M , shall be the greater of:
DH DV D
a) operating loads determined from the geometry and operation of the jumbo unit. The most critical
position of the boom shall be considered, and an impact factor of not less than 3,0 shall be applied;
b) maximum equipment loads determined from the geometry and maximum capacity of the jumbo
unit equipment. An impact factor of not less than 1,5 shall be applied.
Examples are provided in Annex B.
6.2.5 Lashing unit load
The lashing unit loads, P , P and M , shall be the greater of:
LH
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
