INTERNATIONAL STANDARD ISO 24213:2017(E)
Metallic materials — Sheet and strip — Method for
springback evaluation in stretch bending
1 Scope
This document specifies a method for evaluating the amount of springback of sheets of metallic
materials known to exhibit large amounts of springback subjected to plane-strain stretch bending,
which is a typical deformation mode generated in press-formed panels. By using this method, the
[1][2]
amount of springback under stretch bending is evaluated accurately and quantitatively .
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 80000-1, Quantities and units — Part 1: General
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at http:// www .electropedia .org/
— ISO Online browsing platform: available at http:// www .iso .org/ obp
3.1
curvature
κ
reciprocal of the radius of curvature, r, determined at the centre of a stretch-bent specimen on the inner
surface in the longitudinal direction
1
κ =
r
3.2
amount of springback
η
relative change in curvature of a test piece under force and after removal of the force shown in Figure 1
′
κκ−
′
rr−
η = =
κ r′
© ISO 2017 – All rights reserved 1

---------------------- Page: 6 ----------------------
ISO 24213:2017(E)

a)  Under force b)  After removal of the force
Figure 1 — Radius of curvature of a test piece under force and after removal of the force
3.3
stretch bending
method of bending a test piece under tension
3.4
blank holding pressure
force applied on the test piece in the direction of its thickness, divided by the surface area of the test
piece contacting the die
3.5
nominal tensile stress
tensile force per unit cross-sectional area of the test piece
2 © ISO 2017 – All rights reserved

---------------------- Page: 7 ----------------------
ISO 24213:2017(E)

4 Symbols and designations
The symbols used in this document and the corresponding designations are given
...
