INTERNATIONAL STANDARD ISO/IEC 25434:2007(E)

Information technology — Data interchange on 120 mm and
80 mm optical disk using +R DL format — Capacity: 8,55 Gbytes
and 2,66 Gbytes per side (recording speed up to 8x)
Section 1 - General
1 Scope
This International Standard specifies the mechanical, physical and optical characteristics of 120 mm
recordable optical disks with capacities of 8,55 Gbytes and 17,1 Gbytes. It specifies the quality of the recorded
and unrecorded signals, the format of the data and the recording method, thereby allowing for information
interchange by means of such disks. The data can be written once and read many times using a non-
reversible method. These disks are identified as +R DL.
This International Standard also specifies 80 mm disks with capacities of 2,66 Gbytes and 5,32 Gbytes. These
disks have the same characteristics as the 120 mm disks, except for some parameters related to the smaller
dimensions. All parameters unique for the 80 mm disks are specified in Annex A.
This International Standard specifies
⎯ two related but different Types of this disk (see Clause 7),
⎯ the conditions for conformance,
⎯ the environments in which the disk is to be tested, operated and stored,
⎯ the mechanical, physical and dimensional characteristics of the disk, so as to provide mechanical
interchange between data processing systems,
⎯ the format of the information on the disk, including the physical disposition of the tracks and sectors, the
error correcting codes and the coding method,
⎯ the characteristics of the signals recorded on the disk, thus enabling data processing systems to read the
data from the disk.
This International Standard provides for the interchange of disks between optical disk drives. Together with a
standard for volume and file structure, it provides for full data interchange between data processing systems.
2 Conformance
2.1 Optical disk
A claim of conformance with this International Standard shall specify the Type implemented. An optical disk
shall be in conformance with this International Standard if it meets all mandatory requirements specified for its
Type.
© ISO/IEC 2007 – All rights reserved 1

2.2 Generating system
A generating system shall be in conformance with this International Standard if the optical disk it generates is
in accordance with 2.1.
2.3 Receiving system
A receiving system shall be in conformance with this International Standard if it is able to handle both Types of
optical disk according to 2.1.
2.4 Compatibility statement
A claim of conformance by a Generating or Receiving system with this International Standard shall include a
statement listing any other standards supported. This statement shall specify the numbers of the standards,
the optical disk types supported (where appropriate) and whether support includes reading only or both
reading and writing.
3 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 4873:1991, Information technology — ISO 8-bit code for information interchange — Structure and rules
for implementation
ISO 16448:2002, Information technology — 120 mm DVD — Read-only disk
ISO 16449:2002, Information technology — 80 mm DVD — Read-only disk
ISO 17341:2006, Information technology — Data Interchange on 120 mm and 80 mm Optical Disk using +RW
Format — Capacity: 4,7 Gbytes and 1,46 Gbytes per Side (Recording speed up to 4X)
ISO 17344:2006, Information technology — Data Interchange on 120 mm and 80 mm Optical Disk using +R
Format — Capacity: 4,7 and 1,46 Gbytes per Side (Recording speed up to 16X)
ISO 26925:2006, Information technology — Digital storage media for information interchange — Data
Interchange on 120 mm and 80 mm Optical Disk using +RW HS Format — Capacity: 4,7 and 1,46 Gbytes per
Side (Recording speed 8X)
ECMA-287 (2002), Safety of electronic equipment
4 Terms and definitions
For the purpose of this document, the following terms and definitions apply.
4.1
Channel bit
the elements by which the binary values ZERO and ONE are represented by marks and spaces on the disk
4.2
Clamping Zone
the annular part of the disk within which the clamping force is applied by the clamping device
2 © ISO/IEC 2007 – All rights reserved

4.3
Digital Sum Value (DSV)
the arithmetic sum obtained from a bit stream by allocating the decimal value +1 to bits set to ONE and the
decimal value −1 to bits set to ZERO
4.4
Disk Reference Plane
a plane defined by the perfectly flat annular surface of an ideal spindle onto which the clamping Zone of the
disk is clamped, and which is normal to the axis of rotation
4.5
dummy substrate
a layer, which may be transparent or not, provided for the mechanical support of the disk and, in some cases,
of the recording layer as well
4.6
entrance surface
the surface of the disk onto which the optical beam first impinges
4.7
field
a subdivision of a sector
4.8
groove
a trench-like feature of the disk, applied before the recording of any information and used to define the track
location
NOTE The groove is located nearer to the entrance surface than the so-called land in between the grooves. The
recording is made on the groove.
4.9
interleaving
the process of reallocating the physical sequence of units of data so as to render the data more immune to
burst errors
4.10
layer structure
dual layer DVD discs generally are constructed according to one of the following two structures:
“2P” structure: in this method the first recording layer (L0) is applied to the substrate with the impressed
pre-groove, after which the recording layer is covered with a semi-transparent mirror. On top of this structure a
spacer layer is applied, which in general consists of a Photo-Polymerisation (2P) lacquer, in which the pre-
groove for the second layer is impressed and fixated by means of UV-light. Next the second recording layer
(L1) and a mirror are applied. Finally the dummy substrate is glued onto this structure.
“inverted-stack” structure: in this method the first recording layer (L0) is applied to the substrate with the
impressed pre-groove, after which the recording layer is covered with a semi-transparent mirror. The dummy
substrate with the impressed pre-groove for the second layer is covered with the mirror after which the
recording layer (L1) is applied. Next the two substrates are glued together, separated by a spacer.
“2P” structure “inverted-stack” structure
dummy-substrate dummy-substrate
mirror mirror
recording layer recording layer
spacer glue spacer
semi-mirror semi-mirror
recording layer recording layer
substrate substrate
laser laser
beam beam
© ISO/IEC 2007 – All rights reserved 3

4.11
mark
a non-reversible feature of the recording layer which may take the form of less reflective area, a pit, or any
other type or form that can be sensed by the optical system
NOTE The pattern of marks and spaces represents the data on the disk.
4.12
Multi-session disk
a disk containing more than one set of Lead-in/Intro, Data, and Lead-out/Closure Zones
4.13
Physical Sector
the smallest addressable part of a track in the Information Zone of a disk that can be accessed independently
of other addressable parts of the Zone
4.14
recording layer
a layer of the disk on which data is written during manufacture and/or use
4.15
Reed-Solomon code (RS)
an error detection and/or correction code
4.16
Reference velocity
the linear velocity that results in the nominal Channel bit rate of 26,156 25 Mbit/s
4.17
Single-session disk
a disk containing a Lead-in Zone, one Data Zone and a Lead-out Zone
4.18
session
a continuous part of the Information Zone of the disk consisting of a Lead-in or Intro Zone, a Data Zone and a
Lead-out or Closure Zone
4.19
space
a feature of the recording layer represented by any area between two marks which can be sensed by the
optical system
NOTE The pattern of marks and spaces represents the data on the disk.
4.20
spacer
a transparent layer of the disk, provided for achieving an accurate separation of the pair of recording layers
which are accessed by the optical beam through the same entrance surface
4.21
substrate
a transparent layer of the disk, provided for mechanical support of the recording layer, through which the
optical beam accesses the recording layer
4.22
track
a 360° turn of a continuous spiral
4 © ISO/IEC 2007 – All rights reserved

4.23
track pitch
the distance between adjacent track centrelines, measured in a radial direction
4.24
VCPS
Video Content Protection System
a method to prevent unauthorized copying and/or redistribution of video data that is recorded in the
DVD+R/+RW Video Format
NOTE See Annex P.
4.25
wobble
a continuous sinusoidal deviation of the track from the average centreline
NOTE Location information is included as phase modulated data in the wobble.
4.26
zone
an annular area of the disk
5 Conventions and notations
5.1 Representation of numbers
A measured value may be rounded off to the least significant digit of the corresponding specified value. For
instance, it implies that a specified value of 1,26 with a positive tolerance of + 0,01 and a negative tolerance of
− 0,02 allows a range of measured values from 1,235 to 1,274.
Numbers in decimal notations are represented by the digits 0 to 9.
Numbers in hexadecimal notation are represented by the hexadecimal digits 0 to 9 and A to F in parentheses.
The setting of bits is denoted by ZERO and ONE.
Numbers in binary notations and bit patterns are represented by strings of digits 0 and 1, with the most
significant bit shown to the left. In a pattern of n bits, bit b shall be the most significant bit (msb) and bit b
n-1 0
shall be the least significant bit (lsb). Bit b shall be recorded first.
n-1
Negative values of numbers in binary notation are given as Two's complement.
In each data field, the data is recorded so that the most significant byte (MSB), identified as Byte 0, shall be
recorded first and the least significant byte (LSB) last.
In a field of 8n bits, bit b shall be the most significant bit (msb) and bit b the least significant bit (lsb). Bit
(8n-1) 0
b shall be recorded first.
(8n-1)
5.2 Names
The names of entities, e.g. specific tracks, fields, etc., are given with an initial capital.
© ISO/IEC 2007 – All rights reserved 5

6 Abbreviations and acronyms
a.c. alternating current NRZ Non Return to Zero
ADIP Address in Pre-groove NRZI Non Return to Zero Inverted
ASM Asymmetry NSL Normalized Slicing Level
BP Byte Position NWPW Normalized Write Power Window
BPF Band Pass Filter OPC Optimum Power Control
CAV Constant Angular Velocity OTP Opposite Track Path
CLD Constant Linear Density PAA Physical Address in ADIP
CLV Constant Linear Velocity PBS Polarizing Beam Splitter
cm current mark PI Parity of Inner-code
d.c. direct current PLL Phase Locked Loop
DCB Disk Control Block PO Parity of Outer-code
DCC d.c. component suppression Control PP Push-Pull
DSV Digital Sum Value pp peak-to-peak
ECC Error Correction Code ps previous space
EDC Error Detection Code PSN Physical Sector Number
EI Extended Information PTP Parallel Track Path
HF High Frequency RIN Relative Intensity Noise
ID Identification Data RPM Revolutions per Minute
IED ID Error Detection code RS Reed-Solomon code
LPF Low Pass filter RSV Reserved
LSB Least Significant Byte (in use by specific applications)
lsb Least Significant Bit RUN Recording UNit
LSN Logical Sector Number SDCB Session DCB
MSB Most Significant Byte SNR Signal to Noise Ratio
msb Most Significant Bit SYNC Synchronization code
NA Numerical Aperture TOC Table of Contents
7 General description of the optical disk
The optical disk that is the subject of this Standard consists of two substrates bonded together by an adhesive
layer, so that the recording layer(s) is (are) on the inside. The centring of the disk is performed on the edge of
the centre hole of the assembled disk on the side currently accessed. Clamping is performed in the Clamping
Zone. This Standard provides for two Types of such disks.
Type S9 consists of a substrate, a dummy substrate and two recording layers with a spacer between
them. Both recording layers can be accessed from one side only. The capacity is 8,55 Gbytes
for the 120 mm sized disk and 2,66 Gbytes for the 80 mm sized disk.
Type D18 consists of two substrates, each having two recording layers with a spacer between those two
recording layers. From each side of the disk only one pair of recording layers can be accessed.
The capacity is 17,1 Gbyte
...
