RADIO-FREQUENCY CONNECTORS –
Part 2: Sectional specification –
Radio frequency coaxial connectors of type 9,52

1 Scope
This part of IEC 61169, which is a sectional specification (SS), provides information and rules
for the preparation of detail specifications (DS) for RF coaxial connectors of type 9,52.
It describes the interface dimensions for general purpose grade 2 connectors, dimensional
details for standard test connectors, grade 0, together with gauging information and the
mandatory tests selected from IEC 61169-1, applicable to all DS relating to type 9,52
connectors.
This specification indicates the recommended performance characteristics to be considered
when writing a DS and covers test schedules and inspection requirements.
2 Normative references
The following referenced documents are indispensable for the application of this document.
For dated references, only the edition cited applies. For undated references, the latest edition
of the referenced document (including any amendments) applies.
IEC 61169-1:1992, Radio-frequency connectors – Part 1: Generic specification – General
requirements and measuring methods
3 Interface dimensions
3.1 Interface
3.1.1 General
All dimensions are in millimetres.
All undimensioned pictorial configurations are for reference purposes only.
3.1.2 Dimensions
Figures 1, 2 and 3 provide dimensions for sliding connectors, screw coupling connectors and
standard test connectors respectively.

– 6 – 61169-2  IEC:2007
9,1 min.
+0,43
7,11
0,8 ± 0,4
2 max.
Cone or radius
IEC  105/07
Figure 1a – Sliding male connector

7,54 min.
+1,5
0,5
IEC  106/07
Figure 1b – Sliding female connector
Figure 1 – Sliding connector
+0,3
∅1
–0,1
+0,03
∅2,35
–0,08
∅8,5 min.
∅9,525 ± 0,05
61169-2  IEC:2007 – 7 –
+0,43
7,11
4 ± 0,5
Optional sealing
4 min.
gasket
IEC  107/07
Figure 2a – Screw coupling male connector

5 min.
IEC  108/07
Figure 2b – Screw coupling female connector
Figure 2 – Screw coupling connector

M14 × 1
M14 × 1
– 8 – 61169-2  IEC:2007
9,1 min.
+0,43
7,11
0,8 ± 0,4
2 max.
4 min.
IEC  109/07
Figure 3a – Standard test male connector

7,54 min.
7,2 min.
5 min.
+0,2
0,5
4 slots
width 0,3 mm
lenght 4,5 mm
IEC  110/07
Figure 3b – Standard test female connector
Figure 3 – Standard test connectors
M14 × 1
∅3,2 ± 0,02
+0,3
∅1
–0,1
∅2,35 ± 0,01
∅8,5 ± 0,02
∅9,525 ± 0,05
M14 × 1
61169-2  IEC:2007 – 9 –
3.2 Mechanical gauges
3.2.1 General
All dimensions are in millimetres.
All undimensioned pictorial configurations are for reference purposes only.
3.2.2 Socket connectors – Gauges for the resilient outer contact
Figure 4 illustrates gauge pins for outer contacts of socket connectors.

∅a
7 ± 0,5
IEC  111/07
Surface finish: Ra <=0,5
Weight: 5 N
Gauge A Gauge B
Reference mm mm
Min. Max. Min. Max.
∅ a 9,575 9,585 9,465 9,475
b 5,0 5,2 7,0 7,2
Test sequence
a) Steel test pin (A) (Figure 4) shall be inserted at least three times into the outer contact.
b) A second steel test pin (B) (Figure 4) shall be inserted into the outer contact.
This gauge, when in a vertical downward attitude, shall be retained by the contact.
Figure 4 – Gauge pins for outer contact of socket connector

b
– 10 – 61169-2  IEC:2007
3.2.3 Socket connectors – Gauges for the resilient centre contact
Figure 4 illustrates gauge pins for outer contacts of socket connectors.

∅a
R0,5
–0,1
IEC  112/07
Surface finish: Ra <=0,5
Gauge C Gauge D
Reference mm mm
Min. Max. Min. Max.
∅ a 2,38 2,39 2,29 2,30
Test sequence
a) Steel test pin (C) (Figure 5) shall be inserted at least three times into the centre contact.
b) A second steel test pin (D) (Figure 5) shall be inserted into the centre contact.
This gauge, when in a vertical downward attitude, shall be retained by the contact.
This gauge will have a mass (weight) of 0,25 N.
Figure 5 – Gauge pins for centre contact of socket connector
4 Quality assessment procedures
4.1 General
The following subclauses provide recommended ratings, performance and test conditions to
be considered when writing a detail specification (DS). They also provide an appropriate
schedule of tests with minimum levels of conformance inspection.
4.2 Ratings and characteristics
The RF connectors defined in this standard are designed for use with a variety of flexible and
semi-rigid coaxial cables and in microwave integrated circuits and similar uncabled
applications. Table 1 lists the ratings and characteristics involved.

+0,2
61169-2  IEC:2007 – 11 –
Table 1 – Ratings and characteristics
Remarks
IEC 61169-1
Ratings and characteristics Value including any deviations
subclause
from standard test methods
Electrical
Nominal impedance  Shall meet the requirements of
9.2.1.1 of IEC 61169-1 when
terminating a Z = 75 Ω cable
c
Frequency range 0-3 GHZ See DS
Reflection factor 49.2.14.
a
– straight styles
7 7% up to 2 GHZ
10% up to 3 GHZ
up to 2 GHZ%
10% up to 3 GHZ
– right angle styles  See DS
– solder bucket and PCB mounting style  Under consideration
Centre contact resistance 9.2.3
– initial ≤ 5 mΩ
– after conditioning ≤ 10 mΩ
Outer conductor continuity
– initial ≤ 2,0 mΩ
– after conditioning
≤  2,5 mΩ
Insulation resistance .9.2.5
– initial
> 1 GΩ
– after conditioning
> 1 MΩ
b c
Proof voltage at sea level  .9.2.6 750 V 86 kPa - 106 kPa
Screening effectiveness .9.2.8 Z
a ≥ 90 dB t
s
Discharge test (Corona) .9.2.9 na
Mechanical
Gauge retention force (resilient contacts) 9.3.4 See 3.2 of IEC 61169-1
Contact captivation 9.3.5
– axial force 30 N
Captivated contacts only
– torque na
Engagement and separation 9.3.6 Screw coupling connectors
Coupling torque
To overcome friction of a coupling
– friction 0,066 Nm max.
nut
– coupling 0,46 Nm to 0,69 Nm
– proof 1,7 Nm
Mechanical tests on cable
– cable pulling 9.3.8 120 N
– cable torsion 9.3.10 0,1 Nm
Tensile strength of coupling mechanism 9.3.11 300 N
Bending moment 9.3.12 2 Nm Relative to reference plane
Environmental
Vibration 9.3.3 98 m/s²  10 g acceleration
10 Hz to 500 Hz
Climatic sequence 9.4.2 40/70/21
Sealing 9.4.5 1 cm /h max 100 kPa - 110 kPa pressure
Salt mist 9.4.6 48 h
Endurance
Mechanical 0,19.57.10 1 000 cycles
High temperature 9.60 1 000 h
a
These values apply to basic connectors. They depend on the cable used. Relevant values are given in the DS.
b
Voltage values are r.m.s. values at 50 Hz – 60 Hz, unless otherwise specified.
c
Cables used with these connectors may have values of lower performance than those given in this table.

– 12 – 61169-2  IEC:2007
4.3 Test schedule and inspection requirements
4.3.1 Acceptance tests
Table 2 indicates the various acceptance tests, methods and assessment criteria involved.
Table 2 – Acceptance tests
Test Assessment level M (higher) Assessment level H (lower)
method
Test Test
IEC 61169-1
IL AQL % Period IL AQL % Period
Required Required
subclause
Group A1
Visual examination 9.1.2 a II 1,0 A S3 1,5
Group B1
Outline dimensions 9.1.3.1 a S4 0,4 A S3 4,0
Mechanical compatibility 9.1.3.3 a II 1,0 A S3 1,5
Engagement and separation 9.3.6 a S4 0,40 Lot A S3 1,5 Lot
Gauge retention (resilient 9.3.4 ia II 1,0 Ia S3 1,5
contact)
Sealing, non-hermetic 9.4.5.1 ia II 0,65 by ia S3 1,0 by
Sealing, hermetic 9.4.5.2 ia II 0,015 ia S3 0,025
Voltage proof 9.2.6 a S4 0,40 lot a II 4,0 lot
Solderability piece parts 9.3.2.1.1 ia S4 0,40 ia S3 4,0
Insulation resistance 9.2.5 a S4 0,40 a S3 4,0
NOTE Details of symbols, abbreviations and procedures:
a = suggested as applicable
ia = test suggested (if technically applicable)
IL = Inspection Level
AQL = Acceptable Quality Level
(d)  = destructive tests – specimens shall not be returned to stock

4.3.2 Periodic tests
Table 3 indicates the various periodic tests, methods and assessment criteria involved.
There are no group C tests for levels H and M.

61169-2  IEC:2007 – 13 –
Table 3 – Periodic tests
Test Assessment level M (higher) Assessment level H (lower)
method
Test Number Permitted Period Test Number Permitted Period
IEC 61169-1
required of speci- failures required of speci- failures
subclause
mens per mens per
group# group#
Group D1 (d)  6 1 3 years 3 1 3 years
Solderability 9.3.2.1.1 ia  ia
connector
assemblies
Resistance to 9.3.2.1.2 ia  ia
soldering heat
Mechanical tests
on cable fixing
– cable rotation 9.3.7.2 ia  ia
(nutation)
– cable pulling 9.3.8 ia  ia
– cable bending 9.3.9 ia  ia
– cable torsion 9.3.10 ia  ia
Group D2 (d)  6 1 3 years 3 1 3 years
Contact 9.2.3 a  a
resistance, outer
conductor and
screen continuity
centre conductor
continuity
Vibration 9.3.3 a
Damp heat, 9.4.3 a  a
steady state
Group D3 (d)  1* 1 3 years 1* 1 3 years
Dimensions 9.1.3.2 a  a
piece-parts and
materials
Group D4 (d)  6 1 3 years 3 1 3 years
Mechanical 9.5 a  a
endurance
High 9.6 a  a
temperature
endurance
Sulphur dioxide 9.4.8 na  na
Group D5 (d)  6 1 3 years 3 1 3 years
Reflection factor 9.2.1 a  a
Screening 9.2.8 a  a
effectiveness
Water immersion 9.2.7 ia  ia
Group D6 (d)  6 1 3 years 3 1 3 years
Contact 9.3.5 a  a
captivation
Rapid change of 9.4.4 na  na
temperature
Climatic 9.4.2 a  a
sequence
– 14 – 61169-2  IEC:2007
Table 3 (continued)
Test Assessment level M (higher) Assessment level H (lower)
method
Test Number Permitted Period Test Number Permitted Period
IEC 61169-1
required of speci- failures required of speci- failures
subclause
mens per mens per
group# group#
Group D7 (d)  1§ 3 years 1 3 years
Resistance to 9.7 ia  ia
solvents and
contaminating
fluids
Details of symbols, abbreviations and procedures:
a = suggested as applicable
ia = test suggested (if technically applicable)
na = not applicable
IL = Inspection Level
AQL = Acceptable Quality Level
* = one set of piece-parts each style and variant, unless using common piece parts
# = for Qualification Approval (QA) a total of two failures only permitted for level H and 1 failure only for level M from
groups D1 to D7
§ = Group D7 – number of pairs for each solvent
(d) = destructive tests – specimens shall not be returned to stock

4.4 Procedures
4.4.1 Quality conformance inspection
This shall consist of test groups A1 and B1 on a lot-by-lot basis.
4.4.2 Qualification approval and its maintenance
This shall consist of three consecutive lots passing test groups A1 and B1 followed by
selection of specimens from the lots as appropriate. These specimens shall successfully pass
the specified periodic D tests.
5 Instructions for preparation of detail specifications
5.1 General
Detail specifications (DS) writers shall use the appropriate BDS pro-forma. The following
pages comprise the pro-forma BDS dedicated for use with 75 Ω type 9,52 connectors. As
such, it will already have entered on it information relating to
a) the basic specification number applicable to all the detail specifications covering
connector styles of the type covered by the sectional specification;
b) the connector series designation.
The specification writer should enter the details relating to the connector style/variant(s) to be
covered as indicated. The numbers in brackets on the BDS pro-forma correspond to the
following indications which shall be given.
5.2 Identification of the detail specification
(1) The name of the National Standards Organization (NSO) under whose authority the DS is
published and, if applicable, the organization from whom the DS is available.
(2) The relevant mark of conformity and the number allotted to the DS by the relevant national
or international organization authorizing the DS

61169-2  IEC:2007 – 15 –
(3) The number and issue number of the IEC/IECQ generic or sectional specification as
relevant; also national reference if different.
(4) If different from the IEC/IECQ number, any national number of the DS, date of issue and
any further information required by the national system, together with any amendment
numbers.
5.3 Identification of the component
(5) Enter the following details:
Style: The style designation of the connector including type of fixing and
sealing, if applicable.
Attachment: By deletion of the inapplicable options of cable/wire: given for
centre and outer conductors.
Special features and markings: As applicable.
(6) Enter details of assessment level and the climatic category.
(7) A reproduction of the outline drawing and details of the panel piercing, if applicable. It
shall provide the maximum envelope dimensions, also the position of the reference plane
and, in the case of a fixed connector, the position of the mounting plane(s) relative to the
front face of the connector.
Any maximum panel thickness limitations for fixed connectors shall be stated.
(8) Particulars of all variants covered by the DS. As appropriate, the information shall
include:
• cable types (or sizes) applicable to each variant;
• alternative plated or protective finishes;
• details of alternative mounting flanges having either tapped or plain mounting holes;
• details of alternative solder spills or solder buckets including, when applicable, those
for use with Microwave Integrated Circuit (MIC) components.
5.4 Performance
(9) Performance data listing the most important characteristics of the connector taking into
account the recommended values in 4.2. of this specification. Deviations from the
minimum requirements shall be clearly indicated. Non-applicable parameters shall be
marked ‘na’.
5.5 Marking, ordering information and related matters
(10) Insert marking and ordering information as appropriate, together with details of related
documents and any invoked structural similarity.
5.6 Selection of tests, test conditions and severities
(11) ‘na’ shall be used to indicate non-applicable tests. All tests marked ‘a’ by the detail
specification writer shall be mandatory.
When using the normal procedure with a dedicated BDS, the letter ‘a’ – for applicable –
shall be entered in the ‘Test required’ column against each of the tests indicated as
being mandatory in the test schedule as in 4.3 of this specification. Any additional tests
required at the discretion of the specification writer shall also be indicated by an ‘a’.
The specification writer shall also indicate, when necessary, details of deviations from
the standard test methods and test conditions, including any relevant deviations given in
the test schedule of the sectional specification.
The qualification approval and conformance inspection shall be such that the National
Supervising Inspectorate (NSI) shall be satisfied that they are appropriate and in line
with those for other connectors within the system providing a reasonably comparable
service.
– 16 – 61169-2  IEC:2007
5.7 Blank detail specification pro-forma for type 9,52 connector
The following pages contain the complete BDS pro-forma.
(1)
Page 1 of 10
QC 220201
ELECTRONIC COMPONENT OF ASSESSED (4) ISSUE
QUALITY IN ACCORDANCE WITH
GENERIC SPECIFICATION QC 220000 .
SECTIONAL SPECIFICATION QC 220200
NATIONAL REFERENCE .
(5) Detail specification for type 9,52
Radio frequency coaxial connector of assessed quality
Style:. Special features and markings
Method of cable/wire+ attachment centre conductor – solder/crimp+
outer conductor – solder/clamp/crimp +
+ delete as appropriate
(6) Assessment level. Characteristic impedance 75 Ω Climatic category./././
(7) Outline and maximum dimensions Panel piercing and mounting details
(8) Variants
Variant No. Description of variant 60096 IEC
01. . . . . .
............. ............. ............. ............. ............. .............
............. ............. ............. ............. ............. .............
............. ............. ............. ............. ............. .............
............. ............. ............. ............. ............. .............
............. ............. ............. ............. ............. .............
............. ............. ............. ............. ............. .............
............. ............. ............. ............. ............. .............
............. ............. ............. ............. .............
Information about manufacturers who have components qualified to this detail specification is available in the
current QC 001005 Qualified Product List.

61169-2  IEC:2007 – 17 –
(9) Performance (including limiting conditions of use)
IEC 61169-1 Remarks including any
Ratings and characteristics (QC 220000) Value deviations from standard test
Subclause methods
Electrical
Nominal impedance  75 Ω
Frequency range  Measurement frequency range
0 GHz – 3 GHZ
Reflection factor 9.2.1
Variant No.
...........
Designation .
...........
01. .
........... ............
Centre contact resistance 9.2.3 ≤ .mΩ Initial
After conditioning
≤.mΩ
Centre conductor 01. 9.2.3 Resistance change due to
.............mΩ
continuity . conditioning
.............mΩ
...........
.............mΩ
...........
.............mΩ
Outer contact continuity 9.2.3
≤ .mΩ Initial
After conditioning
≤.mΩ
Insulation resistance 9.2.5 Initial
≥.GΩ
After conditioning
≥.GΩ
#+ Proof voltage at sea 01. 9.2.6 .kV 86 kPa – 106 kPa
level . .kV
........... ..............kV
........... ..............kV
#+ Proof voltage at 01. .V .kPa (if not 4,4 kPa)
4,4 kPa . .V
........... ...............V
........... ...............V
#+ Environment test 01. .V 86-106 kPa
voltage at sea level . .V
........... ...............V
........... ...............V
Environment test voltage 01. .V .kPa (if not 4,4 kPa)
at 4,4 kPa . .V
........... ...............V
........... ...............V
Screening effectiveness 01. 9.2.8 ≥ dB at.GHz Z≤.Ω
t
...........
...........
...........
ADDITIONAL
ELECTRICAL
CHARACTERISTICS
+ Voltage values are r.m.s. values at 50 Hz – 60 Hz, unless otherwise specified.

– 18 – 61169-2  IEC:2007
IEC 61169-1 Remarks including any
Ratings and characteristics (QC 220000) Value deviations from standard test
Subclause methods
Mechanical
Soldering 9.3.2.1.1
- bit size .
Gauge retention resilient
contacts 9.3.4.3
...............
- inner contact
- outer contact
Centre contact captivation 9.3.5
- axial force .N
- permitted displacement .mm
each direction
Engagement and 9.3.6
separation
- axial force
Effectiveness of cable
fixing against
- cable rotation 01. 9.3.7.2 Rotations
........... .................
........... .................
........... .................
- cable pulling 01. 9.3.8 .N
........... ...........
........... ...........
........... ...........
- cable bending 01. 9.3.9 .Cycles Length of cable mass
........... ........... ................. ..........
........... ........... ................. ..........
........... ........... ................. ..........
- cable torsion 01. 9.3.10 .Nm
........... ...........
........... ...........
........... ...........
Bending moment 9.3.12 .Nm Relative to reference plane
Vibration 9.3.3 .m/s² (.g acceleration)
n
......to....Hz
ADDITIONAL
MECHANICAL
CHARACTERISTICS
61169-2  IEC:2007 – 19 –
IEC 61169-1 Remarks including any
Ratings and characteristics (QC 220000) Value deviations from standard test
Subclause methods
Environmental
Climatic category  ././.
Sealing non-hermetically 9.4.5.1 .cm /h 100 kPa – 110 kPa pressure
sealed connectors differential
–5 3
Sealing hermetically sealed 9.4.5.2 10 bar/cm /h 100 kPa – 110 kPa pressure
connectors differential
Water immersion 9.2.7
ADDITIONAL
ENVIRONMENTAL
CHARACTERISTICS
ENDURANCE
Mechanical 9.5 ….operations
High temperature 9.6 .h
at.°C
ADDITIONAL ENDURANCE
CHARACTERISTICS
CHEMICAL CONTAMINATION
Resistance to solvents and 9.7 .
contaminating fluids to be .
used. .
Applicable fluids.
Sulphur dioxide 9.4.8
– 20 – 61169-2  IEC:2007
(10) Supplementary information
– Marking of the component: in accordance with 11.1 of IEC 61169-1 (QC 220000) in the
following order of preference:
1) Manufacturer code: .
2) Manufacturing date code: year/week
3) Component identification: Variant No./Identification
Designation
..................................
..................................
..................................
..................................
..................................
..................................
..................................
..................................
– Marking and contents of package: in accordance with 11.2 of IEC 61169-1
1) Information prescribed in 11.1 of IEC 61169-1 detailed above
2) Nominal characteristic impedance .75 Ω.
3) Assessment level code letter .
4) Any additional marking required .
– Ordering information
1) Number of the detail specification IECQC 220201  /  Variant code.
2) Assessment level code letter .
3) Body finish (if more than one listed) .
4) Any additional information or
special requirements .
– Related documents (if not included in IEC 61169-1 or sectional specification):
.......................................................................................................................
.......................................................................................................................
– Structural similarity in accordance with 10.2.2 IEC 61169-1
NOTE Relevant information on a basic style should be entered as variant 01.

___________
– 22 – 61169-2  CEI:2007
SOMMAIRE
AVANT-PROPOS . 23

1 Domaine d'application . 25
2 Références normatives . 25
3 Dimensions d'interface . 25
3.1 Interface . 25
3.2 Calibres mécaniques . 29
4 Procédures d'assurance de la qualité . 30
4.1 Généralités . 30
4.2 Valeurs assignées et caractéristiques. 30
4.3 Séquence d'essais et exigences de contrôle . 32
4.4 Procédures . 34
5 Instructions pour l'élaboration de spécifications particulières . 35
5.1 Généralités . 35
5.2 Identification de la spécification particulière . 35
5.3 Identification du composant . 35
5.4 Performances . 36
5.5 Marquage, information relative aux commandes et éléments concernés . 36
5.6 Choix des essais, des conditions d'essai et des sévérités . 36
5.7 Spécification particulière cadre pro-forma pour les connecteurs de série 9,52 . 37

Figure 1a – Connecteur mâle coulissant . 26
Figure 1b – Connecteur femelle coulissant. 26
Figure 1 – Connecteur coulissant . 26
Figure 2a – Connecteur mâle avec verrouillage à vis . 27
Figure 2b – Connecteur femelle avec verrouillage à vis . 27
Figure 2 – Connecteur avec verrouillage à vis . 27
Figure 3a – Connecteur mâle d'essai standard . 28
Figure 3b – Connecteur femelle d'essai standard . 28
Figure 3 – Connecteurs d'essai standard . 28
Figure 4 – Calibres mâles pour le contact extérieur du connecteur femelle . 29
Figure 5 – Calibres mâles pour le contact central du connecteur femelle . 30

Tableau 1 – Valeurs assignées et caractéristiques . 31
Tableau 2 – Essais d'acceptation . 32
Tableau 3 – Essais périodiques . 33

61169-2  CEI:2007 – 23 –
COMMISSION ÉLECTROTECHNIQUE INTERNATIONALE
___________
CONNECTEURS POUR FRÉQUENCES RADIOÉLECTRIQUES –

Partie 2: Spécification intermédiaire –
Connecteurs coaxiaux pour fréquences radioélectriques de type 9,52

AVANT-PROPOS
1) La CEI (Commission Électrotechnique Internationale) est une organisation mondiale de normalisation
composée de l'ensemble des comités électrotechniques nationaux (Comités nationaux de la CEI). La CEI a
pour objet de favoriser la coopération internationale pour toutes les questions de normalisation dans les
domaines de l'électricité et de l'électronique. A cet effet, la CEI – entre autres activités – publie des Normes
internationales, des Spécificatio
...
