Optical fibre cables –
Part 2-23: Indoor cables – Detail specification for multi-fibre cables for use in

MPO connector terminated cable assemblies

Câbles à fibres optiques –
Partie 2-23: Câbles intérieurs – Spécification particulière pour les câbles

multifibres utilisés dans les câbles assemblés équipés de connecteurs MPO

INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
INTERNATIONALE
ICS 33.180.10  ISBN 978-2-8322-8135-2

– 2 – IEC 60794-2-23:2024 © IEC 2024
CONTENTS
FOREWORD . 3
1 Scope . 5
2 Normative references . 5
3 Terms and definitions . 6
4 Construction . 6
4.1 General . 6
4.2 Optical fibres . 7
4.3 Ribbon structure . 7
4.4 Strength and anti-buckling members . 7
4.5 Ripcord . 7
4.6 Cable sheath . 7
4.7 Sheath marking . 7
4.8 Example of cable construction . 7
5 Tests . 7
5.1 General . 7
5.2 Dimensions . 8
5.3 Mechanical requirements . 8
5.3.1 General . 8
5.3.2 Tensile performance . 8
5.3.3 Crush . 9
5.3.4 Impact . 9
5.3.5 Bending . 9
5.3.6 Repeated bending . 10
5.3.7 Torsion . 10
5.3.8 Kink . 10
5.3.9 Abrasion resistance of cable marking . 11
5.4 Environmental requirements . 11
5.4.1 Temperature cycling . 11
5.4.2 Sheath shrinkage . 12
6 Transmission requirements . 12
7 Fire performance . 12
Annex A (normative) Cable sample preparation for bending and temperature cycling
test . 13
Annex B (informative) Examples of cable constructions . 14
B.1 Optical cables for use in MPO connector terminated cable assemblies, with
single sheath . 14
B.2 Optical cables for use in MPO connector terminated cable assemblies, with
double sheath . 14
Bibliography . 15

Figure A.1 – Sample preparation and length for multi-fibre cables for use in MPO
connector terminated cable assemblies. 13
Figure B.1 – Example of a cross-section of a 12-fibre cable with single sheath . 14
Figure B.2 – Example of a cross-section of a 12-fibre cable with double sheath . 14

Table 1 – Preferred low and high temperatures . 11
