Industrial communication networks - Fieldbus specifications - Part 5-10: Application layer service definition - Type 10 elements

IEC 61158-5-10:2019 defines the services provided to the FAL user at the boundary between the user and the application layer of the fieldbus reference model, and Systems Management at the boundary between the application layer and Systems Management of the fieldbus reference model. This standard specifies the structure and services of the IEC fieldbus application layer, in conformance with the OSI Basic Reference Model (ISO/IEC 7498-1) and the OSI application layer structure (ISO/IEC 9545).
This fourth edition cancels and replaces the third edition published in 2014 and constitutes a technical revision which includes the following significant technical changes with respect to the previous edition:
– integration of system redundancy basic functionality;
– integration of dynamic reconfiguration basic functionality;
– integration of reporting system basic functionality;
–-integration of asset management basic functionality;
– integration of media redundancy ring interconnection basic functionality.

Réseaux de communication industriels - Spécifications des bus de terrain - Partie 5-10 : Définition des services de la couche application - Eléments de type 10

L’IEC 61158-5-10:2019 fournit des éléments communs pour les communications de messagerie prioritaires et non prioritaires élémentaires entre les programmes d’application des environnements d’automatisation et le matériel spécifique au bus de terrain de type 10. On utilise le terme "prioritaire" pour traduire la présence d’une fenêtre temporelle, à l’intérieur de laquelle il est exigé qu’une ou plusieurs actions spécifiées soient terminées avec un niveau de certitude défini. Si les actions spécifiées ne sont pas réalisées dans la fenêtre temporelle, les applications demandant les actions risquent de connaître une défaillance, avec les risques que cela comporte pour les équipements, les installations et éventuellement la vie humaine.

General Information

Status
Published
Publication Date
09-Apr-2019
Technical Committee
Drafting Committee
Current Stage
DELPUB - Deleted Publication
Start Date
24-Mar-2023
Completion Date
26-Oct-2025
Ref Project

Relations

Overview

IEC 61158-5-10:2019 is part of the IEC 61158 series for industrial communication networks (fieldbus specifications). This fourth edition defines the application layer service definition for Type 10 elements of the IEC fieldbus application layer (FAL). It specifies the structure, data types and Application Service Elements (ASEs) provided at the boundary between the FAL user and the application layer - and between the application layer and Systems Management - in conformance with the OSI Basic Reference Model (ISO/IEC 7498-1) and OSI application layer structure (ISO/IEC 9545).

This edition (2019) supersedes the 2014 edition and introduces key technical additions such as system redundancy, dynamic reconfiguration, reporting system, asset management, and media redundancy ring interconnection basic functionalities.

Key topics and technical requirements

  • Application layer architecture: formal definition of FAL structure, ASE classes, data types and service conventions.
  • ASE catalogue: many ASEs are specified (examples include Remote Procedure Call, DNS, SNMP, IP suite, real-time cyclic and acyclic services, discovery/configuration, dynamic host configuration, media redundancy, precision time control, IEEE 802.1AS and bridge/fragmentation related ASEs).
  • Decentralized periphery model: ASEs and communication models for IO devices, controllers and supervisors, including application processes, associations and device instance models.
  • Data types and transfer rules: fixed and variable length types, date/time specifics and transfer of user data.
  • Systems management interfaces: services for asset management, diagnosis, logbook, reporting and system redundancy handling.
  • Media and time-critical features: media redundancy ring interconnection, precision time control and mapping to IEEE Ethernet families (e.g., IEEE 802.3, 802.1AS).
  • Conformance and interoperability: requirements follow OSI principles to enable multi-vendor interoperability and predictable behaviour for fieldbus application functions.

Practical applications

  • Ensures interoperability of industrial devices and fieldbus implementations across vendors.
  • Supports high-availability use cases through system and media redundancy for manufacturing, process control and critical infrastructure.
  • Enables dynamic reconfiguration and remote device management for scalable, maintainable automation networks.
  • Provides the foundation for real-time cyclic/acyclic communications, precise time synchronization and diagnostic/reporting services in factory and process automation.

Who should use this standard

  • Device and gateway manufacturers implementing fieldbus application layer services
  • Network architects and system integrators designing industrial Ethernet/fieldbus solutions
  • Automation engineers, test labs and certification bodies validating conformance and interoperability
  • Product managers and consultants assessing fieldbus capabilities for industrial control systems

Related standards and alignment

  • ISO/IEC 7498-1 (OSI Basic Reference Model)
  • ISO/IEC 9545 (OSI application layer structure)
  • Other parts of IEC 61158 (physical and data link specifications) and related Ethernet/IEEE standards referenced within the document

Keywords: IEC 61158-5-10, fieldbus, application layer, FAL, ASE, industrial communication networks, media redundancy, system redundancy, dynamic reconfiguration, asset management.
