CISPR 14-1:1993/AMD1:1996
(Amendment)Amendment 1 - Electromagnetic compatibility - Requirements for household appliances, electric tools and similar apparatus - Part 1: Emission - Product family standard
Amendment 1 - Electromagnetic compatibility - Requirements for household appliances, electric tools and similar apparatus - Part 1: Emission - Product family standard
Amendement 1 - Compatibilité électromagnétique - Exigences pour les appareils électrodomestiques, outillages électriques et appareils analogues - Partie 1: Emission - Norme de famille de produits
General Information
Relations
Buy Standard
This May Also Interest You
CISPR 15:2024 Amendment 1
- Standard71 pagesEnglish and French languagesale 15% off
CISPR 14-1:2020 specifies the requirements that apply to the emission of radio-frequency disturbances in the frequency range 9 kHz to 400 GHz from appliances, electric tools and similar apparatus as defined below, whether powered by AC or DC (including a battery). This document is applicable to the following equipment:
- household appliances or similar equipment;
- electric tools;
- similar apparatus.
Also included in the scope of this document are separate parts of the above mentioned equipment such as motors and switching devices (e.g. power or protective relays). However, no emission requirements apply to such separate parts, unless otherwise stated in this document. Products which incorporate radio transmit/receive functions are included in the scope of this document. Equipment under the scope of this document making use of IPT is also in the scope. Excluded from the scope of this document are:
- equipment for which all emission requirements in the radio-frequency range are explicitly formulated in other CISPR standards;
- equipment intended to be used only on a vehicle, ship or aircraft;
- equipment used only in industrial environment
- the effects of electromagnetic phenomena relating to the safety of the equipment.
Multifunction equipment may be required to comply with clauses in this and other standards. The details are given in 6.5. The emission requirements in this document are not intended to be applicable to the intentional transmissions from a radio transmitter as defined by the ITU including their spurious emissions. This seventh edition cancels and replaces the sixth edition published in 2016. This edition constitutes a technical revision. This edition includes the following significant changes with respect to the previous edition:
- extension of the frequency range for radiated measurements above 1 GHz;
- revision of general test conditions and addition of new specific test conditions (e.g. for robotic equipment);
- introduction of additional requirements for equipment making use of inductive power transfer technology;
- remove from the normative text any compliance requirement based on statistical evaluation;
- revision of clicks analysis, with particular relevance to the determination of the observation time and the application of the upper quartile method for different types of click analysers.
Refer to the Foreword of the document for examples of equipment.
- Standard112 pagesEnglish languagesale 15% off
- Standard230 pagesEnglish and French languagesale 15% off
- Standard2 pagesEnglish languagesale 15% off
CISPR 15:2018 applies to the emission (radiated and conducted) of radiofrequency disturbances from:
- lighting equipment (3.3.16);
- the lighting part of multi-function equipment where this lighting part is a primary function;
- UV and IR radiation equipment for residential and non-industrial applications;
- advertising signs;
- decorative lighting;
- emergency signs.
Excluded from the scope of this document are:
- components or modules intended to be built into lighting equipment and which are not user-replaceable;
- lighting equipment operating in the ISM frequency bands (as defined in Resolution 63 (1979) of the ITU Radio Regulation);
- lighting equipment for aircraft and airfield facilities (runways, service facilities, platforms);
- video signs;
- installations;
- equipment for which the electromagnetic compatibility requirements in the radio-frequency range are explicitly formulated in other CISPR standards, even if they incorporate a built-in lighting function.
The frequency range covered is 9 kHz to 400 GHz. No measurements need to be performed at frequencies where no limits are specified in this document.
Multi-function equipment which is subjected simultaneously to different clauses of this document and/or other standards need to meet the provisions of each clause/standard with the relevant functions in operation.
For equipment outside the scope of this document and which includes lighting as a secondary function, there is no need to separately assess the lighting function against this document, provided that the lighting function was operative during the assessment in accordance with the applicable standard. The radiated emission requirements in this document are not intended to be applicable to the intentional transmissions from a radio transmitter as defined by the ITU, nor to any spurious emissions related to these intentional transmissions.
Within the remainder of this document, wherever the term "lighting equipment" or "EUT" is used, it is meant to be the electrical lighting and similar equipment falling in the scope of this document as specified in this clause. This ninth edition cancels and replaces the eighth edition published in 2013 and its Amendment 1:2015. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) full editorial revision and restructuring;
b) the restriction to mains and battery operation is deleted in the scope;
c) radiated disturbance limits in the frequency range 300 MHz to 1 GHz have been introduced;
d) the load terminals limits and the CDNE (alternative to radiated emissions) limits have changed;
e) deletion of the insertion-loss requirements and the associated Annex A;
f) introduction of three basic ports: wired network ports, local wired ports and the enclosure port;
g) introduction of a more technology-independent approach;
h) replacement of Annex B (CDNE) by appropriate references to CISPR 16-series of standards;
i) modified requirements for the metal holes of the conical housing;
j) new conducted disturbance measurement method for GU10 self-ballasted lamp;
k) addition of current probe measurement method and limits for various types of ports (in addition to voltage limits and measurement methods);
l) introduction of the term ‘module’ (instead of independent auxiliary) and requirements for measurement of modules using a host (reference) system;
m) modified specifications for stabilization times of EUTs;
n) for large EUT (> 1,6 m), addition of the magnetic field measurement method using a 60 cm loop antenna at 3 m distance (method from CISPR 14-1) as an alternative to the 3 m and 4 m LAS.
Keywords: emission (radiated and conducted) of radiofrequency disturbance
The contents of the Interpretation Sheet 1 of November 2019 have been included in this copy.
- Standard170 pagesEnglish languagesale 15% off
- Standard153 pagesEnglish and French languagesale 15% off
- Standard2 pagesEnglish languagesale 15% off
- Standard2 pagesEnglish languagesale 15% off
- Standard10 pagesEnglish and French languagesale 15% off
CISPR 14-1:2016 specifies the requirements that apply to the emission of radio-frequency disturbances in the frequency range 9 kHz to 400 GHz from appliances, electric tools and similar apparatus, whether powered by AC or DC (including a battery). Also included in the scope of this standard are separate parts of the above mentioned equipment such as motors and switching devices (e.g. power or protective relays); however, no emission requirements apply to such separate parts, unless otherwise stated in this standard. This sixth edition cancels and replaces the fifth edition published in 2005, Amendment 1:2008 and Amendment 2:2011. This edition constitutes a technical revision. The contents of the corrigendum of October 2016 and interpretation sheet 1 and 2 of May 2017 have been included in this copy.
- Standard195 pagesEnglish and French languagesale 15% off
- Standard45 pagesEnglish and French languagesale 15% off
CISPR 15:2013 applies to the emission (radiated and conducted) of radiofrequency disturbances from:
- all lighting equipment with a primary function of generating and/or distributing light intended for illumination purposes, and intended either for connection to the low voltage electricity supply or for battery operation;
- the lighting part of multi-function equipment where one of the primary functions of this is illumination;
- independent auxiliaries exclusively for use with lighting equipment;
- UV and IR radiation equipment;
- neon advertising signs;
- street/flood lighting intended for outdoor use;
- and transport lighting (installed in buses and trains). Excluded from the scope of this standard are:
- lighting equipment operating in the ISM frequency bands (as defined in Resolution 63 (1979) of the ITU Radio Regulation);
- lighting equipment for aircraft and airports;
- and apparatus for which the electromagnetic compatibility requirements in the radio-frequency range are explicitly formulated in other CISPR standards. The frequency range covered is 9 kHz to 400 GHz. This eighth edition cancels and replaces the seventh edition published in 2005, its Amendment 1 (2006) and Amendment 2 (2008). It is a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- inclusion of LED light sources and luminaires, clarification of test supply voltage and frequency, and improvements to clause 5 relating to the application of limits to the various types of lighting equipment covered under the scope of CISPR 15;
- introduction of requirements for flashing type emergency lighting luminaires utilizing xenon lamps;
- introduction of requirements for neon and other advertising signs;
- and clarification of the requirement for radiated disturbances between 30 MHz and 300 MHz in case the operating frequency of the light source is below 100 Hz. The contents of the interpretation sheet 1 and 2 of june 2013 have been including in this copy.
- Standard121 pagesEnglish and French languagesale 15% off
- Standard300 pagesEnglish and French languagesale 15% off
