INTRODUCTION
Short-range radar systems are widely exploited in civil applications, such as automotive,
weather forecast, mobile, aviation, or security inspections applications. The performance of
each radar system is guaranteed in the field without any harmful interference but the frequency
allocation using theoretical calculations does not consider the latest mitigation technologies. In
order to increase the efficiency of the system usage without any degradation of the performance
of the radars, this document describes the principles of the radar systems and their performance
in applications.
This document summarizes the technological features of short-range radar systems. In addition,
some practical applications are also investigated and reported.
