INTERNATIONAL IEC
STANDARD
First edition
1999-04
Maritime navigation and radiocommunication
equipment and systems –
Integrated bridge systems (IBS) –
Operational and performance requirements,
methods of testing and required test results
Matériels et systèmes de navigation et de
radiocommunication maritimes –
Systèmes intégrés de passerelle –
Exigences d'exploitation et de fonctionnement,
méthodes d'essai et résultats d'essai exigés
 IEC 1999  Copyright - all rights reserved
No part of this publication may be reproduced or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without permission in writing from the publisher.
International Electrotechnical Commission 3, rue de Varembé Geneva, Switzerland
Telefax: +41 22 919 0300 e-mail: inmail@iec.ch IEC web site http://www.iec.ch
Commission Electrotechnique Internationale
PRICE CODE
XA
International Electrotechnical Commission
For price, see current catalogue

– 2 – 61209 © IEC:1999(E)
CONTENTS
Page
FOREWORD . 3
INTRODUCTION .4
Clause
1 Scope.5
2 Normative references.5
3 Definitions and abbreviations. 6
3.1 Definitions.6
3.2 Abbreviations.8
4 General requirements.8
4.1 General.8
4.2 Integration.9
4.3 Data exchange.9
4.4 Failure analysis.10
4.5 Quality assurance.10
5 Operational requirements.10
5.1 Human factors.10
5.2 Functionality.11
5.3 Training.11
6 Technical requirements.12
6.1 Sensors.12
6.2 Alarm management.12
6.3 Human factors.13
6.4 Power interruptions and shut-down. 13
6.5 Power supply.14
7 Methods of testing and required results . 14
7.1 Introduction.14
7.2 General requirements (clause 4) . 14
7.3 Operational requirements (clause 5). 16
7.4 Technical requirements (clause 6). 17
Annex A (normative) Additional IMO requirements . 19
Annex B (informative) Abbreviations . 24
Annex C (informative) Operational areas. 27
Annex D (normative) Power supply requirements in addition to the main source of energy 35
Annex E (informative) Definition of integration related terms . 37
Bibliography .55

61209 © IEC:1999(E) – 3 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
___________
MARITIME NAVIGATION AND RADIOCOMMUNICATION
EQUIPMENT AND SYSTEMS –
Integrated bridge systems (IBS) –
Operational and performance requirements,
methods of testing and required test results
FOREWORD
1) The IEC (International Electrotechnical Commission) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of the IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, the IEC publishes International Standards. Their preparation is
entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. The IEC collaborates closely with the International Organization
for Standardization (ISO) in accordance with conditions determined by agreement between the two
organizations.
2) The formal decisions or agreements of the IEC on technical matters express, as nearly as possible, an
international consensus of opinion on the relevant subjects since each technical committee has representation
from all interested National Committees.
3) The documents produced have the form of recommendations for international use and are published in the form
of standards, technical reports or guides and they are accepted by the National Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
5) The IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with one of its standards.
6) Attention is drawn to the possibility that some of the elements of this International Standard may be the subject
of patent rights. The IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 61209 has been prepared by IEC technical committee 80: Maritime
navigation and radiocommunication equipment and systems.
The text of this standard is based on the following documents:
FDIS Report on voting
80/199/FDIS 80/221/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
Annexes A and D form an integral part of this standard.
Annexes B, C and E are for information only.
A bilingual version of this standard may be issued at a later date.

– 4 – 61209 © IEC:1999(E)
INTRODUCTION
In 1991, the International Electrotechnical Commission (IEC) technical committee 80 (TC 80)
observed that, while considerable work was progressing to develop standards for the individual
systems or subsystems of a modern ship’s bridge, no international organization had yet
assigned the task of integrating these individual systems or co-ordinating the individual
standards.
The normal progression would be the development of an International Maritime Organization
(IMO) safety-related circular or assembly resolution, to be followed by assignment for the
development of the IEC standard to a TC working group (WG).
IEC TC 80 felt that the development of an integrated bridge system was so important that they
should not wait any longer before embarking on the development of this International Standard.
They therefore assigned the task to TC 80, WG 9, Integrated bridge systems (IBS) for ships,
and informed IMO of this work programme.
WG 9 co-ordinated their work closely with similar activity within the IMO subcommittees on
Safety of Navigation (NAV), Design and Equipment, Radiocommunications, Search and
Rescue, and other working groups of TC 80, the activities of the International Association of
Classification Societies (IACS), as well as individual classification societies, and national
initiatives. Many of the working group members actively participated in one or more of these
other groups.
IEC TC 80 submitted the material contained in the requirements section of this standard to IMO
with a proposal that it could provide the basis for an international agreement on the subject of
integrated bridges. The IMO Maritime Safety Committee (MSC), at its 67th session, agreed to
the essence of this proposal and adopted resolution MSC.64(67), annex 1, performance
standards for integrated bridge systems (IBS).
The aims of this standard are to provide recommendations for the design, manufacture,
integration and testing of:
– stand-alone equipment;
– networks;
– integration units; and
– multifunction displays
in connection with the aspect of interaction (integration) within a bridge.

61209 © IEC:1999(E) – 5 –
MARITIME NAVIGATION AND RADIOCOMMUNICATION
EQUIPMENT AND SYSTEMS –
Integrated bridge systems (IBS) –
Operational and performance requirements,
methods of testing and required test results
1 Scope
This International Standard specifies the minimum requirements for the design, manufacture,
integration and testing of integrated bridge systems (IBS) to comply with IMO resolution
MSC.64(67), annex 1, of the International Maritime Organization (IMO), and other relevant IMO
performance standards, in order to meet the functional requirements contained in applicable
IMO instruments, not precluding multiple usage of equipment and modules or the need for
duplication.
Reference is made, where appropriate, to IMO resolution MSC.64(67) annex 1, and text in this
standard, the meaning of which is identical to that in the IMO resolution, is printed in italics and
identified by the resolution paragraph numbers in brackets.
This standard aims to increase safe and efficient ship management by suitably qualified
personnel taking care of, inter alia, uninterrupted functional availability of systems, and of
human factors.
Operation of the IBS may conflict with the requirements for individual equipment. Such conflicts
may imply modification to, or deviation from, individual equipment standards or the carriage of
additional equipment. This standard highlights those deviations as well as their justification.
Existing standards for individual equipment are not addressed.
2 Normative references
The following normative documents contain provisions which, through reference in this text,
constitute provisions of this International Standard. For dated references, subsequent amend-
ments to, or revisions of, these publications do not apply. However parties to agreements
based on this International Standard are encouraged to investigate the possibility of applying
the most recent editions of the normative documents indicated below. For undated references,
the latest edition of the normative documents referred to applies. Members of IEC and ISO
maintain registers of currently valid International Standards.
IEC 60945:1996, Maritime navigation and radiocommunication equipment and systems –
General requirements – Methods of testing and required test results
IEC 61162 (all parts), Maritime navigation and radiocommunication equipment and systems –
Digital interfaces
ISO 8468:1990, Ship’s bridge layout and associated equipment – Requirements and guidelines
ISO 9000 (all parts), Quality management and quality assurance standards
ISO 9001:1994, Quality systems – Model for quality assurance in design, development,
production, installation and servicing

– 6 – 61209 © IEC:1999(E)
ISO 9002:1994, Quality systems – Model for quality assurance in production, installation and
servicing
IMO International Convention for the Safety of Life at Sea (SOLAS ):1997, Consolidated edition
IMO A.686:1991, Code on alarms and indicators
IMO A.823:1995, Performance standards for automatic radar plotting aids (ARPAs)
IMO A.830:1995, Code on alarms and indicators (amendments to IMO 686: 1991)
IMO A.694:1991, General requirements for shipborne radio equipment forming part of the
global maritime distress and safety system (GMDSS) and for electronic navigational aids
IMO MSC.64(67):1996, Annex 1 – Performance standards for integrated bridge systems (IBS)
IMO MSC.64(67):1996, Annex 4 – Amendments to A.477:1981, Performance standards for
radar equipment
IMO MSC/Circular 566:1991, Provisional guidelines on the conduct of trials in which the officer
of the navigational watch acts as the sole look-out in periods of darkness
IACS UR N1:1992, Unified requirements for one man bridge operated (OMBO) ships
NOTE – Additional IMO requirements which may be applicable to IBS are listed in annex A.
3 Definitions and abbreviations
3.1 Definitions
For the purpose of this standard, the following definitions apply.
3.1.1
configuration of complete system
all operational functions of the IBS as installed
3.1.2
configuration available
operation(s) allocated to and available at each workstation
3.1.3
configuration in use
operation(s) and task(s) currently in use at each workstation
3.1.4
connectivity
a complete data link and the presence of valid data
3.1.5
essential functions
functions related to determination, execution and maintenance of safe course, speed and
position of the ship in relation to the waters, traffic and weather conditions (passage execution)

61209 © IEC:1999(E) – 7 –
Such functions normally include, but are not limited to,
– route planning;
– navigation;
– collision avoidance;
– manoeuvring;
– docking;
– monitoring of internal safety systems;
– external and internal communication related to safety in bridge operation and distress
situations;
– ship stability
3.1.6
essential information
that information which is necessary for the monitoring and control of essential functions
3.1.7
functionality
ability to perform an intended function. The performance of a function normally involves a
system of displays, controls and instrumentation
3.1.8
IMO requirements
IMO conventions, regulations, resolutions, codes, recommendations, guidelines, circulars and
related ISO and IEC standards
3.1.9
(1.1, 2) integrated bridge system (IBS)
any combination of systems which are interconnected in order to allow centralized access to
sensor information or command/control from workstations to perform two or more of the
following operations:
– passage execution;
– communications;
– machinery control;
– loading, discharging and cargo control;
– safety and security.
Management operations may also be performed within the IBS (see annex C).
3.1.10
integrity
ability of a system to provide users with accurate, timely, complete and unambiguous
information and warnings within a specified time when the system shall not be used
3.1.11
latency
time interval between an event and the resulting information, including time for processing,
transmission and reception
3.1.12
multifunction display
a single visual display unit which can present, either simultaneously or through a series of
selectable pages, information from more than one operation of an IBS

– 8 – 61209 © IEC:1999(E)
3.1.13
part
an individual subsystem, equipment or module
3.1.14
performance check
a representative selection of short qualitative tests, to confirm correct operation of essential
functions of the IBS
3.1.15
sensor
a device which provides information to or is controlled or monitored by the IBS
A compilation of definitions of integration related terms is contained in annex E.
3.2 Abbreviations
Abbreviations used in this standard:
ARPA Automatic radar plotting aid
GMDSS Global maritime distress and safety system
IACS International Association of Classification Societies
IBS Integrated bridge system
IEC International Electrotechnical Commission
IMO International Maritime Organization
ISO International Organization for Standardization
MMI Man-machine-interface
MSC IMO Maritime Safety Committee
NAV IMO Subcommittee on Safety of Navigation
SOLAS (International Convention for the) Safety of Life at Sea
SSD System specification document
VDU Visual display unit
Additional relevant abbreviations are found in annex B.
4 General requirements
4.1 (3.1) General
4.1.1 (3.1.1) The IBS shall comply with all applicable IMO requirements as contained in
clause 2 and annex A of this standard. Parts executing multiple operations shall meet the
requirements specified for each individual function they can control, monitor or perform. By
complying with the provisions of this standard, all essential functions remain available in the
event of a single failure. Therefore, means for operation independent of the IBS shall not be
required.
4.1.2 (3.1.2) Each part of an IBS shall meet the relevant requirements of IMO resolution
A.694(17) as detailed in IEC 60945. In consequence the IBS is in compliance with these
requirements without further environmental testing to IEC 60945.
4.1.3 Where implemented, passage execution shall not be interfered with by other operations.
4.1.4 (3.1.3) A failure of one part shall not affect the functionality of other parts except for
those functions directly dependent upon the information from the defective part.

61209 © IEC:1999(E) – 9 –
4.2 (3.2) Integration
The IBS shall provide functional integration meeting the following requirements.
4.2.1 (3.2.1) The functionality of the IBS shall ensure that operations are at least as
effective as with stand-alone equipment.
4.2.2 (3.2.2) Continuously displayed information shall be reduced to the minimum necessary
for safe operation of the ship. Supplementary information shall be readily accessible.
4.2.3 Integrated display and control functions shall adopt a consistent man-machine-interface
(MMI) philosophy and implementation. Particular consideration shall be paid to
– symbols;
– colours;
– controls;
– information priorities;
– layout.
4.2.4 (3.2.3) Where multifunction displays and controls are used to perform functions
necessary for safe operation of the ship they shall be duplicated and interchangeable.
4.2.5 (3.2.4) It shall be possible to display the complete system configuration, the available
configuration and the configuration in use.
4.2.6 Any unintentional change of a configuration shall be brought to the immediate attention
of the user. An unintentional change of the configuration in use shall, in addition, activate an
audible and visual alarm.
4.2.7 (3.2.5) Each part to be integrated shall provide details of its operational status and the
latency and validity of essential information. Means shall be provided within the IBS to make
use of this information.
4.2.8 (3.2.6) An alternative means of operation shall be provided for essential functions.
4.2.9 For integrated machinery control, it shall be possible for all machinery essential for the
safe operation of the ship to be controlled from a local position.
4.2.10 (3.2.7) An alternative source of essential information shall be provided. The IBS shall
identify loss of either source.
4.2.11 (3.2.8) The source of information (sensor, result of calculation or manual input) shall
be displayed continuously or on request.
4.3 (3.3)  Data exchange
4.3.1 (3.3.1) Interfacing within the IBS and to an IBS shall comply with IEC 61162, as
applicable.
4.3.2 (3.3.2) Data exchange shall be consistent with safe operation of the ship. The
manufacturer shall specify in the system specification document (SSD) the maximum
permissible latency for each function, considering the use of fast control loop, normal control
loop, essential information and other information.

– 10 – 61209 © IEC:1999(E)
4.3.3 Corrupted data shall not be accepted by the IBS. Corrupted or missing data shall not
affect functions which are not dependent on this data.
4.3.4 (3.3.3) The integrity of data flowing on the network shall be ensured.
4.3.5 The network shall be such that in the event of a single fault between nodes there shall
be an indication, and the sensors and displays on the network shall continue to operate and
data transmission between them shall be maintained.
4.3.6 (3.3.4) A failure in the connectivity shall not affect independent functionality.
4.4 (3.4) Failure analysis
(3.4.1) A failure analysis shall be performed, documented and be acceptable.
4.4.1 Parts, functions and connectivity shall be identified.
4.4.2 Possible failures of parts and connectivity associated with essential functions and
information shall be identified.
4.4.3 Consequences of failures with respect to operation, function or status of the IBS shall
be identified.
4.4.4 Each failure shall be classified with respect to its impact on the IBS taking into account
relevant characteristics, such as detectability, diagnosability, testability, replaceability and
compensating and operating provisions.
4.4.5 The results of the failure analysis shall confirm the possibility for continued safe
operation of the ship.
4.5 Quality assurance
The IBS shall be designed, developed, produced, installed and serviced by companies certified
to ISO 9001 or ISO 9002, as applicable.
(4) Operational requirements
5.1 (4.1) Human factors
5.1.1 (4.1.1) The IBS shall be capable of being operated by personnel holding appropriate
certificates.
5.1.2 (4.1.2) The MMI shall be designed to be easily understood and in a consistent style for
all integrated functions.
5.1.3 Operational information shall be presented in a format readily understandable without
need to transpose, compute or translate.
5.1.4 Indications, which may be accompanied by a short low-intensity audible signal, shall
occur when
– an attempt is made to execute an invalid function;
– an attempt is made to use invalid information.

61209 © IEC:1999(E) – 11 –
5.1.5 If an input error is detected by the system, it shall require the operator to correct the
error immediately. Messages actuated by an input error shall guide the correct responses, for
example
do not use: Invalid entry
but use: Invalid entry: re-enter set point between 0 and 10.
5.1.6 Layered menus shall be presented in a way which minimizes the added workload to find
and return from the desired functions.
5.1.7 An overview shall be easily available to assist the operator in the use of a multiple page
system. Each page shall have a unique identifier.
5.1.8 (4.1.3) Where multifunction displays are used, they shall be in colour. Continuously
displayed information and functional areas, for example menus, shall be presented in a
consistent manner.
5.1.9 (4.1.4) For actions which may cause unintended results, the IBS shall request
1)
confirmation from the operator.
5.1.10 Functions requested by the operator shall be acknowledged or clearly indicated by the
IBS on completion.
5.1.11 Default values, where applicable, shall be indicated by the IBS when requesting
operator input.
5.1.12 For bridge operation by one person, special consideration shall be given to the
technical requirements in IMO MSC/Circular 566, paragraphs 10 to 32.
5.2 (4.2) Functionality
5.2.1 (4.2.1) It shall always be clear from where essential functions may be performed.
5.2.2 (4.2.2) The system management shall ensure, that one user only has the control of an
input or function at the same time. If so, all other users shall be informed about that by the IBS.
5.3 Training
5.3.1 Manufacturers of integrated bridge systems shall provide training possibilities for the
ship’s crew. This training shall take place ashore or on board and shall be carried out by
means of suitable material and methods to cover the following topics.
5.3.2 General understanding and operation of the system:
– knowledge and understanding of the system’s configuration and application;
– reading and understanding of the operating manual;
– usage and understanding of brief descriptions and instructions provided on the bridge;
– usage and understanding of electronic "HELP" functions, if provided in the system;
– familiarization with the system using safe trial modes.
___________
1)
Examples of such actions are
– attempting to change position of next waypoint while in track mode steering;
– attempting to switch on bow thruster when insufficient electrical power is available.

– 12 – 61209 © IEC:1999(E)
5.3.3 Mastering of uncommon conditions in the system:
– detecting and locating of failures;
– resetting the system to safe default values and modes;
– operating safely without certain sensor data or parts;
– possibilities for on-board repair;
– identifying the potential for unintended results.
5.3.4 Methods and support for providing the above-mentioned training may be, for example
– printed material;
– training courses;
– video films;
– computer-based learning programmes;
– simulation of different situations or data, respectively;
– recorded speech.
6 (5) Technical requirements
6.1 (5.1) Sensors
In order to ensure an adequate system functionality, the sensors employed shall meet the
following requirements, as applicable:
6.1.1 ensure communication compatibility in accordance with the relevant international marine
interface standard, IEC 61162; and provide information about their operational status and about
the latency and validity of essential information;
6.1.2 respond to a command with minimal latency, and indicate receipt of invalid commands,
when remote control is employed;
6.1.3 have the capability to silence and re-establish the audible portion of the local alarm;
6.1.4 have information documented about deterministic and stochastic errors and how they
are handled, insofar as signals are pre-processed locally, for example plausibility check.
6.2 (5.2) Alarm management
6.2.1 (5.2.1) The IBS alarm management as a minimum shall comply with the requirements
(see also IMO A.686).
of the Code on Alarms and Indicators,1995 (IMO Resolution A.830(19))
6.2.2 (5.2.2) Appropriate alarm management on priority levels (see 6.2.5) and grouping of
1)
alarms based on operations and tasks (see annex C) shall be provided within the IBS.
___________
1)
The purpose of grouping alarms is to achieve the following:
− to reduce the variety in type and number of audible and visual alarms and indicators so as to provide quick
and unambiguous information to the personnel responsible for the safe operation of the ship;
− to readily identify any abnormal situation requiring action to maintain the safe operation of the ship;
− to avoid distraction by alarms which require attention but do not require immediate action to restore or
maintain the safe operation of the ship.

61209 © IEC:1999(E) – 13 –
6.2.3 (5.2.3) The number of alarms shall be kept as low as possible by providing indications
for information of lower importance.
6.2.4 (5.2.4) Alarms shall be displayed so that the alarm reason and the resulting functional
restrictions can be easily understood. Indications shall be self-explanatory.
6.2.5 Alarms shall be prioritized as follows:
a) Emergency alarms
Alarms which indicate that immediate danger to human life or to the ship and its machinery
exists, and that immediate action shall be taken.
b) Distress, urgency and safety alarms
Alarms which indicate that a mobile unit or a person is in distress, or the calling station has
a very urgent message concerning the safety of a mobile unit or a person, or has an
important warning to transmit.
c) Primary alarms
Alarms which indicate a condition that requires prompt attention to prevent an emergency
condition as specified in statutory and classification rules and regulations.
d) Secondary alarms
Alarms which are not included above.
6.3 Human factors
6.3.1 A multifunction display, if used, shall be a colour display.
6.3.2 The size, colour and density of text and graphic information presented on a display shall
be such that it may be easily read from the normal operator position under all operational
2)
lighting conditions .
6.3.3 Symbols used in mimic diagrams shall be standardized throughout the system displays.
6.3.4 All information shall be presented on a background providing high contrast and emit as
little light as possible by night.
6.4 (5.3) Power interruptions and shut-down
6.4.1 (5.3.1) If subjected to an orderly shut-down, the IBS shall, upon turn-on come to an
initial default state.
6.4.2 (5.3.2) After a power interruption full functionality of the IBS shall be available after
recovery of all subsystems. The IBS shall not increase the recovery time of individual
subsystem functions after power restoration.
6.4.3 (5.3.3) If subjected to a power interruption the IBS shall upon restoration of power
maintain the configuration in use and continue automated operation as far as practicable.
Safety related automatic functions, for example automated steering control shall only be
restored upon confirmation by the operator.
___________
2)
(See 6.2.3 of ISO 8468.)
– 14 – 61209 © IEC:1999(E)
6.5 (5.4) Power supply
6.5.1 General power supply requirements are summarized in annex D.
6.5.2 (5.4.1) Power supply requirements applying to parts of the IBS as a result of other IMO
requirements shall remain applicable.
6.5.3 (5.4.2) The IBS shall be supplied
– from the main and emergency source of power with automated changeover through a local
distribution board with provision to preclude inadvertent shut-down;
– from a transitional source of power for a duration of not less than 1 min; and
– where required in annex D, parts of the IBS shall also be supplied from a reserve source of
power.
7 Methods of testing and required results
7.1 Introduction
7.1.1 The testing proposed as part of this standard is intended to supplement, and not
replace, testing of parts that is required to meet the relevant IMO performance standards. The
intention is to ensure that when parts are integrated there is no degradation of their individual
functionality and the overall system meets the requirements contained in clauses 4 to 6.
7.1.2 In all instances, the performance standards for parts will form the minimum test
requirement for an integrated system. Parts previously type-approved will not require re-testing.
Bridge-mounted parts for which no IMO performance standard exists shall be tested to the
requirements of IEC 60945. Integration aspects of the IBS shall require testing to ensure
compliance with requirements contained in clauses 4 to 6.
7.1.3 The test strategy shall demonstrate that the IBS, when operated by suitably trained
personnel, shall increase safe and efficient management of the ship (clause 1).
7.2 General requirements (clause 4)
7.2.1 The manufacturer shall state the operations intended to be performed by the IBS.
7.2.2 Since each IBS may integrate an individual set of operations and parts, it is not possible
to define in advance which IMO requirements apply. Therefore, the following steps shall be
taken with each individual IBS being considered.
7.2.2.1 Produce a matrix of the applicable IMO requirements from annex A:
– collect IMO requirements referring generally to IBS (for example SOLAS Chapter V and
Code on Alarms and Indicators (A. 686 and A.830);
– collect IMO requirements applicable to the operations stated in 7.2.1 (for example if a
radar/ARPA is integrated, collect IMO MSC.64(67), annex 4 and A.823);
– identify the individual parts of the IBS and their interfaces;
– identify parts executing multiple operations;
– identify functions necessary to perform the operations stated in 7.2.1;
– identify power supply requirements for the individual parts of the IBS from annex D.

61209 © IEC:1999(E) – 15 –
7.2.2.2 Verify the validity of the appropriate type-approval certificates (4.1.1).
7.2.2.3 Verify that all functions identified in 7.2.2.1 are performed (4.1.1).
7.2.3 Confirm compliance with IEC 60945 by one of the following:
– a valid type-approval certificate;
– a test certificate issued by an appropriate body;
– successful completion of appropriate tests (4.1.2).
7.2.4 Confirm by examination of the SSD that operational functions in addition to passage
execution are implemented on a non-interference basis (4.1.3).
7.2.5 Independently disable each part identified in 7.2.2.1 and determine by a test that only
those functions dependent on the disabled part are affected (4.1.4).
7.2.6 Confirm by examination that only minimum information necessary for the safe operation
of the ship and as applicable to the configuration in use is continuously displayed, and that
supplementary information is readily accessible (4.2.2).
7.2.7 Where IMO requirements governing the symbols, colours, controls, information priorities
and layout of the integrated display and control functions exist, confirm compliance by
examination. Where no such requirements exist, confirm by examination that the use of
symbols, colours, controls, information priorities and layout is consistent (4.2.3).
7.2.8 Where used, confirm by examination that there are at least two identical and
interchangeable multifunction displays and controls (4.2.4).
7.2.9 Confirm by examination that it is possible to display the configuration of the complete
system, the configuration available and the configuration in use (4.2.5).
7.2.10 Disable a part of the configuration in use and confirm that an audible and visual alarm
is activated immediately (4.2.6).
7.2.11 Confirm by examination of relevant certificates and documentation that each part
integrated in the IBS provides details of its operational status, latency and validity of essential
information. Confirm by a performance check that changes in status of the parts and of the
latency and validity of information is used by the IBS in a safe and unambiguous manner
(4.2.8).
7.2.12 Confirm by examination of the SSD that there is an alternative means of performing
each applicable essential function (4.2.8).
7.2.13 Confirm by examination of the SSD that, for integrated machinery control, it is possible
for all machinery essential for the safe operation of the ship to be controlled from a local
position (4.2.9).
7.2.14 Confirm by examination that there is an alternative source of essential information.
Confirm by a performance check that loss of essential information is recognized by the IBS
(4.2.10).
7.2.15 Confirm by examination that the source of information is displayed continuously or on
request (4.2.11).
– 16 – 61209 © IEC:1999(E)
7.2.16 Confirm by examination of relevant certificates and documentation that interfacing
complies with IEC 61162, as applicable (4.3.1).
7.2.17 Confirm by examination of the SSD that the stated latencies are appropriate to all
intended operations. Confirm by examination of the manufacturer’s SSD that the stated
latencies are achieved while the network is loaded to its maximum expected loading (4.3.2).
7.2.18 Confirm by a performance check that corrupted data is not accepted by the IBS and
that corrupted and missing data does not affect functions which are not dependent on this data
(4.3.3).
7.2.19 Confirm by examination of the manufacturer’s SSD that, as a minimum, data includes
a checksum in accordance with IEC 61162, and that, in addition, limits checking is applied to
essential data (4.3.4).
7.2.20 Create a representative number of single faults between network nodes and confirm
that there is an indication of the fault and the displays and sensors continue to operate and
data transmission is maintained (4.3.5).
7.2.21 Identify the system connectivity by examination of the SSD. Independently interrupt
each connection and determine by a performance check that only those functions dependent
on the connection are affected and that all essential functions can still be performed (4.3.6).
7.2.22 Confirm by examination of the SSD that a failure analysis has been performed and
documented. The results of the failure analysis and the possibility for continued safe operation
of the ship shall be verified by testing a representative selection of failures (4.4).
7.2.23 Confirm by examination of the relevant certificate(s) that the manufacturer complies
with ISO 9000 series standards (4.5).
7.3 Operational requirements (clause 5)
7.3.1 Confirm by examination that the IBS includes displays, controls and instrumentation
necessary to perform the functions identified in 7.2.2.1.
7.3.2 Confirm by a performance check, performed by suitably qualified personnel, that
information presented is understandable without the need to transpose, compute or translate,
and that operation of integrated functions of the IBS identified in 7.2.1.1 is as effective as for
equivalent stand-alone equipment (4.2.1, 5.1.1, 5.1.2).
7.3.3 Confirm by examination of the manufacturer´s SSD that the specific requirements in
MSC/Circular 566, paragraphs 10 to 32, are met, if applicable (5.1.3).
7.3.4 Confirm by a performance check that normal execution of functions and use of
information are not accompanied by acoustic signals. If provided, ensure that acoustic signals
accompanying attempts to execute an invalid function or use invalid information are short, of
low intensity and are clearly distinguishable from alarms (5.1.4).
7.3.5 Create an input error and ensure that immediate correction is required and that relevant
guidance is given (5.1.5).
7.3.6 Confirm by a performance check, performed by suitably qualified personnel, that layered
menus, if provided, are presented such as to minimize workload (5.1.6).
7.3.7 If provided, ensure that multiple pages are uniquely identified and that an overview is
available (5.1.7).
61209 © IEC:1999(E) – 17 –
7.3.8 Ensure that continuously displayed information and functional areas, for example
menus, are presented in a consistent manner in multifunction displays (5.1.2, 5.1.8).
7.3.9 Initiate a situation causing a potentially unintended result and ensure that the result is
identified and that confirmation of the action is requested from the operator (5.1.9).
7.3.10 Confirm by a performance check that completion of functions is acknowledged or
clearly indicated (5.1.10).
7.3.11 No test is required for 5.1.11.
7.3.12 Confirm that there is an indication of configurations available at each workstation
(5.2.1).
7.3.13 Confirm that essential functions cannot be performed simultaneously at more than one
workstation and that there is an indication of the configuration in use at each workstation
(5.2.2).
7.3.14 The manufacturer shall produce a written statement that training possibilities are
provided. Confirm by examination of the training material that it covers general understanding
and operation and mastering of uncommon conditions (5.3).
7.4 Technical requirements (clause 6)
7.4.1 As applicable, confirm by examination of the SSD that sensors employed:
– communicate in accordance with IEC 61162 (6.1.1);
– provide details of operational status, latency and validity of essential information (6.1.1);
– respond to a command with minimal latency and indicate receipt of invalid commands when
remote control is employed (6.1.2);
– have the capability to silence and re-establish the audible portion of the local alarm (6.1.3);
– have information documented about deterministic and stochastic errors and how they are
handled (6.1.4).
7.4.2 Initiate a situation identified in the SSD as requiring immediate reaction by an operator
and confirm that the resultant alarm complies with IMO A.686 and A.830 (6.2.1).
7.4.3 Create conditions necessary to generate all types of alarms and indications listed in the
matrix prepared in 7.2.2.1.
7.4.3.1 Confirm that appropriate alarm management on priority levels and functional groups is
provided and that the number of alarm types and their release is kept as low as possible by
providing indications for information of lower importance (6.2.2, 6.2.3).
7.4.3.2 Confirm that alarms are displayed so that the alarm reason and the resulting
functional restrictions can be easily understood and that indications are self-explanatory
(6.2.4).
7.4.3.3 Confirm that alarms are prioritized as emergency alarms, distress, urgency and safety
alarms, primary alarms and secondary alarms (6.2.5).

– 18 – 61209 © IEC:1999(E)
7.4.4 Confirm by examination, performed by suitably qualified personnel, that:
– a multifunction display is a colour display (6.3.1);
– the size, colour and density of text and graphic information displayed on a VDU is such that
it can be easily read from the normal operator position under all operational lighting
conditions (6.3.2);
– symbols used in mimic diagrams are standardized throughout the system displays (6.3.3);
and
– all information is presented on a background providing high contrast and emitting as little
light as possible by night (6.3.4).
7.4.5 Perform an orderly shut-down of the IBS and confirm that when power is turned on
again, the default state specified in the SSD is reached (6.4.1).
7.4.6 Record the configuration in use and the recovery times of all subsystems. Disconnect all
external sources of power and wait for expiration of the IBS transitional source of power.
Restore power and wait for recovery of all subsystems. The recovery times of all subsystems
shall be as recorded (6.4.2).
7.4.7 The IBS shall come to the configuration in use and continue automated operation as far
as practicable. Verify that safety related automatic functions are continued only after
confirmation (6.4.3).
7.4.8 Confirm by examination of the SSD that provisions are made to comply with the power
supply requirements listed in annex D and in the matrix prepared in 7.2.2.1 (6.5).

61209 © IEC:1999(E) – 19 –
Annex A
(normative)
Additional IMO requirements
IEC 60533:1977, Electromagnetic compatibility of electrical and electronic installations in ships
IEC 60872-1:1998, Maritime navigation and radiocommunication equipment and systems –
Radar plotting aids – Part 1: Automatic radar plotting aids (ARPA) – Methods of testing and
required test results
IEC 60936:1988, Shipborne radar – Operational and performance requirements – Methods of
test and required test results
IEC 60936-2:1998, Maritime navigation and radiocommunication equipment and systems –
Radar – Part 2: Shipborne radar
...
