IEC CDV 60269-7/Ed1 © IEC:2021 -2- 32B/700/CDV
1 LOW VOLTAGE FUSES
2 Part 7: Supplementary Requirements for fuse-links for the protection of batteries and battery systems
4 FOREWORD
6 1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
7 all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
8 international co-operation on all questions concerning standardization in the electrical and electronic fields. To
9 this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
10 Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
11 Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
12 in the subject dealt with may participate in this preparatory work. International, governmental and non17
13 governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
14 with the International Organization for Standardization (ISO) in accordance with conditions determined by
15 agreement between the two organizations.
16 2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
17 consensus of opinion on the relevant subjects since each technical committee has representation from all
18 interested IEC National Committees.
19 3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
20 Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
21 Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
22 misinterpretation by any end user.
23 4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
24 transparently to the maximum extent possible in their national and regional publications. Any divergence
25 between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
26 the latter.
27 5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
28 assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
29 services carried out by independent certification bodies.
30 6) All users should ensure that they have the latest edition of this publication.
31 7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
32 members of its technical committees and IEC National Committees for any personal injury, property damage or
33 other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
34 expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
35 Publications.
36 8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
37 indispensable for the correct application of this publication.
38 9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
39 patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
42 International Standard IEC 60269-7 has been prepared by subcommittee 32B: Low-voltage
43 fuses, of IEC technical committee 32: Fuses.
44 The text of this standard is based on the following documents:
46 Full information on the voting for the approval of this standard can be found in the
47 report on voting indicated in the above table.
48 This part is to be used in conjunction with IEC 60269-1, Low-voltage fuses, Part 1:
49 General requirements.
51 This Part 7 supplements or modifies the corresponding clauses or subclauses of Part 1.
52 Where no change is necessary, this Part 7 indicates that the relevant clause or subclause of Part 1
53 applies.
55 Tables and figures which are additional to those in Part 1 are numbered starting from 101.
56 Additional annexes are lettered AA, BB, etc.
58 This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.
59 A list of all parts of the IEC 60269 series, under the general title: Low-voltage fuses, can be
60 found on the IEC website.
62 The committee has decided that the contents of this publication will remain unchanged until
63 the stability date indicated on the IEC web site under "http://webstore.iec.ch" in the data
64 related to the specific publication. At this date, the publication will be
IEC CDV 60269-7/Ed1 © IEC:2021 -3- 32B/700/CDV
66 • reconfirmed;
67 • withdrawn;
68 • replaced by a revised edition, or
69 • amended
70 The standard specifically supports the UN goals
71 Nr. 7: affordable and clean energy
72 Nr. 9: Industry, innovation and infrastructure
73 Nr. 11: Sustainable cities and communities
74 Nr. 12: Responsible consumption and communities
76 1 General
78 Fuse-links for the protection of battery energy systems shall comply with aIl
79 requirements of IEC 60269-1, if not otherwise indicated hereinafter, and shall also comply
80 with the supplementary requirements laid down below.
82 1.1 Scope and object
83 These supplementary requirements apply to fuse-links for the protection of batteries and battery
84 systems, including, but not limited to terminology, for electricity storage in equipment for circuits of
85 nominal voltages up to 1 500 V d.c.
86 Their rated voltage may be higher than 1 500 V d.c.
88 The object of these supplementary requirements is to establish the characteristics of Battery fuse-
89 links in such a way that they can be replaced by other fuse-links having the same characteristics,
90 provided that their dimensions are identical.
92 1.2 Normative references
94 The following referenced documents are indispensable for the application of this document.
95 For dated references, only the edition cited applies. For undated references, the latest edition
96 of the referenced document (including any amendments) applies.
98 IEC 60269-1: Low-voltage fuses – Part 1: General requirements1
100 IEC 60269-2: Low-voltage fuses – Part 2: Supplementary requirements for fuses for use by
101 authorized persons (fuses mainly for industrial application) – Examples of standardized
102 systems of fuses A to K
104 IEC 60364-4-41: Low-voltage electrical installations – Part 4-41: Protection for safety –Protection
105 against electric shock
107 IEC 60364-4-43: Low-voltage electrical installations – Part 4-43: Protection for safety –Protection
108 against overcurrent
110 IEC 60086-4/Ed5: Primary batteries - Part 4: Safety of lithium batteries
112 IEC 62932-1: Flow battery systems for stationary applications – Part 1: General Aspects, Terminology
113 and Definitions
115 IEC 62485-5: Safety requirements for secondary batteries and battery installations – Part 5: Safe
116 operation of stationary lithium-ion batteries in applications
IEC CDV 60269-7/Ed1 © IEC:2021 -4- 32B/700/CDV
118 IEC 62485-6: Safety requirements for secondary batteries and battery installations – Part 5: Safe
119 operation of lithium-ion batteries in traction applications
121 IEC 62660-4 TR: Candidate alternative test methods for the internal short circuit test of IEC 62660-3
123 ISO 3, Preferred numbers – Series of preferred numbers
125 IECEE OD-5014 : IEC System of Conformity Assessment Schemes for Electrotechnical Equipment and
126 Components (IECEE System), Committee of Testing Laboratories (CTL),Instrument Accuracy Limits
128 ISO/IEC 17025 : General requirements for the competence of testing and calibration laboratories
130 2 Terms and definitions
132 For the purposes of this document, the terms and definitions given in IEC 60269-1 as well as
133 the following applies.
135 2.1 General terms
137 2.1.101 battery (IEV 482-01-04)
138 one or more cells fitted with devices necessary for use. For example case, terminals, markings and
139 protective devices etc., as necessary for use
141 2.1.102 cell (IEV 482-01-01)
142 basic functional unit, consisting of an assembly of electrodes, electrolyte, container, terminals and
143 usually separators, that is a source of electric energy obtained by direct conversion of chemical
144 energy
146 2.1.103 battery module
147 group of cells connected together, either in a series and/or parallel configuration with or without protective
148 devices (e.g. fuse or PTC: Positive Temperature Coefficient) and monitoring circuitry
150 2.1.104 battery system
152 battery system which incorporates one or more cells, modules or battery packs including associated devices.
154 NOTE - It has battery management unit to cut off in case of overcharging, over current, and overheating. It may have cooling or heating
155 units.
157 2.1.105 rated energy
158 quantity of energy, declared by the manufacturer, which under the specified conditions can be discharged from
159 fully charged flow battery energy storage system, to fully discharge
160 Note 1 to entry:: The rated energy is expressed in watt hour (Wh).
162 2.1.106 rated output power
163 electrical power, declared by the manufacturer, which under the specified operating conditions is the maximum
164 output power designed to achieve
166 Note 1 to entry: The rated output power is normally expressed in watt (W).
168 2.1.107 short-circuit current (IEV 482-03-26)
169 maximum current which can be delivered by a cell or battery into an external circuit with zero electric
170 resistance, or an external circuit which depresses the cell or battery voltage to approximately zero volts
172 2.1.108 open circuit voltage OCV, , off-load voltage U (IEV 482-03-32)
OC
173 voltage across the terminals of a cell or battery when no external current is flowing
175 2.1.109 overcurrent protective device (IEV 482-03-32)
176 Device provided to interrupt an electrical circuit in case the conductor current in the electrical circuit
177 exceeds a predetermined value for a specified duration.
IEC CDV 60269-7/Ed1 © IEC:2021 -5- 32B/700/CDV
179 2.1.110 rated capacity (IEV 482-03-15)
180 capacity value of a cell or battery determined under specified conditions and declared by the
181 manufacturer
184 3 Conditions for operation in service
186 3.4 Voltage
188 The d.c. system voltage has a maximum value not exceeding 100% of the rated voltage of the
189 fuse.
191 3.4.1 Rated voltage
193 The rated d.c. voltage of a fuse-link shall exceed the maximum value of the open circuit
194 voltage of the Battery (OCV, UOC, off-load voltage) or of the network. See Annex AA.
196 3.5 Current
198 3.5.1 Rated Current
200 Rated currents are given in paragraph 5.3. These values depend upon the utilization categories and
201 rated voltages. For specific systems and sizes, see appendix AA
203 3.6 Frequency, power factor and time constant
205 3.6.1 Frequency
206 Not applicable
208 3.6.2 Power factor
209 Not applicable
211 3.6.3 Time constant
212 The time constants expected in practice are considered to correspond to th
...
