HD 493.3 S2:1993

HD 493.3 S2:1993 is a standardization document published by CLC. Its full title is "Dimensions of mechanical structures of the 482,6 mm (19 in) series - Part 3: Subracks and associated plug-in units". This standard covers: Covers the basic dimensions of a modular range of sub racks for mounting in equipment according to HD 493.1 together with the basic dimensions of a compatible range of plug-in units and printed boards. Covers also the connector-dependent dimensions to be used when two-part connectors according to EN 60603-2 are mounted on subracks and plug-in units.

Covers the basic dimensions of a modular range of sub racks for mounting in equipment according to HD 493.1 together with the basic dimensions of a compatible range of plug-in units and printed boards. Covers also the connector-dependent dimensions to be used when two-part connectors according to EN 60603-2 are mounted on subracks and plug-in units.

HD 493.3 S2:1993 has the following relationships with other standards: It is inter standard links to EN 60297-3-101:2004, EN 61076-4-100:2001, EN 60297-5-105:2001, EN 60297-5-101:2001, EN 60917-1:1998, EN 60297-5-103:2001, EN 60297-5-102:2001, EN 60917-2:1994, EN 60821:1994, EN 61587-1:1999, EN 60297-5-107:2001, EN 60297-5-104:2001, EN 60297-4:1995, EN 60297-5-100:2001, EN 61969-2:2000. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.

HD 493.3 S2:1993 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
