EN ISO 17633:2018
(Main)Welding consumables - Tubular cored electrodes and rods for gas shielded and non-gas shielded metal arc welding of stainless and heat-resisting steels - Classification (ISO 17633:2017)
Welding consumables - Tubular cored electrodes and rods for gas shielded and non-gas shielded metal arc welding of stainless and heat-resisting steels - Classification (ISO 17633:2017)
ISO 17633:2017 specifies requirements for classification of tubular flux and metal cored electrodes and rods, based on the all-weld metal chemical composition, the type of core, shielding gas, welding position and the all-weld metal mechanical properties, in the as-welded or heat-treated conditions, for gas shielded and non-gas shielded metal arc welding of stainless and heat-resisting steels.
ISO 17633:2017 is a combined standard providing for classification utilizing a system based upon nominal composition or utilizing a system based upon alloy type.
a) Clauses, subclauses, and tables which carry the suffix letter "A" are applicable only to products classified using the system based upon nominal composition.
b) Clauses, subclauses, and tables which carry the suffix letter "B" are applicable only to products classified using the system based upon alloy type.
c) Clauses, subclauses, and tables which do not have either the suffix letter "A" or the suffix letter "B" are applicable to all products classified in accordance with this document.
ISO 17633:2017 does not use pulsed current for determining the product classification.
Schweißzusätze - Fülldrahtelektroden und Füllstäbe zum Metall-Lichtbogenschweißen mit und ohne Gasschutz von nichtrostenden und hitzebeständigen Stählen - Einteilung (ISO 17633:2017)
Dieses Dokument legt Anforderungen für die Einteilung von Fülldrahtelektroden und Füllstäben zum Metall-Lichtbogenschweißen mit oder ohne Gasschutz von nichtrostenden und hitzebeständigen Stählen fest. Die Einteilung beruht auf der chemischen Zusammensetzung des reinen Schweißgutes, der Art der Füllung, dem Schutzgas, der Schweißposition und den mechanischen Eigenschaften des reinen Schweißgutes im Schweißzustand oder nach einer Wärmenachbehandlung.
Dieses Dokument ist eine kombinierte Norm und benutzt zur Einteilung ein System entsprechend der Nennzusammensetzung oder entsprechend dem Legierungstyp.
a) Abschnitte, Unterabschnitte und Tabellen mit einem nachgestellten „A“ sind nur für solche Produkte anwendbar, die nach dem System auf Basis der Nennzusammensetzung eingeteilt sind;
b) Abschnitte, Unterabschnitte und Tabellen mit einem nachgestellten „B“ sind nur für solche Produkte anwendbar, die nach dem System auf Basis des Legierungstyps eingeteilt sind;
c) Abschnitte, Unterabschnitte und Tabellen, die kein nachgestelltes „A“ oder „B“ enthalten, sind für alle nach dieser Internationalen Norm eingeteilten Produkte anwendbar.
Dieses Dokument verwendet zur Bestimmung der Produkteinteilung keinen pulsierenden Strom
Produits consommables pour le soudage - Fils et baguettes fourrés pour le soudage à l'arc avec ou sans protection gazeuse des aciers inoxydables et des aciers résistant aux températures élevées - Classification (ISO 17633:2017)
ISO 17633:2017 spécifie les exigences de classification des fils et baguettes fourrés de flux ou de métal, en fonction de la composition chimique du métal fondu hors dilution, du type fourrage, du gaz de protection, de la position de soudage et des caractéristiques mécaniques du métal fondu hors dilution, fils et baguettes étant destinés au soudage à l'arc avec ou sans protection gazeuse des aciers inoxydables et résistant aux températures élevées.
ISO 17633:2017 est une norme mixte permettant une classification utilisant un système basé sur la classification d'après la composition nominale ou utilisant un système d'après le type d'alliage.
a) Les articles, paragraphes et tableaux qui portent la lettre «A» ne sont applicables qu'aux produits classifiés selon le système basé sur la composition nominale.
b) Les articles, paragraphes et tableaux qui portent la lettre «B» ne sont applicables qu'aux produits classifiés selon le système basé sur le type d'alliage.
c) Les articles, paragraphes et tableaux qui ne portent ni la lettre «A» ni la lettre «B» sont applicables aux fils fourrés pour le soudage à l'arc classifiés conformément au présent document.
ISO 17633:2017 n'utilise pas le courant pulsé pour la détermination de la classification des produits.
Dodajni materiali za varjenje - Strženske žice in palice za obločno varjenje nerjavnih in ognjeodpornih jekel v zaščitnem plinu in brez zaščite - Razvrstitev (ISO 17633:2017)
Ta dokument določa zahteve za razvrstitev strženskih žic in palic na osnovi kemične sestave čistega vara, vrste stržena, zaščitnega plina, položaja varjenja ter mehanskih lastnosti čistega vara v varjenem stanju ali s toplotno obdelavo za obločno varjenje nerjavnih in ognjeodpornih jekel v zaščitnem plinu in brez zaščite.
Ta dokument je združen standard, ki omogoča razvrstitev po sistemu na osnovi nominalne sestave ali sistemu na osnovi vrste zlitine.
a) Točke, podtočke in preglednice z dodano črko »A« se uporabljajo samo za proizvode, razvrščene po sistemu na osnovi nominalne sestave.
b) Točke, podtočke in preglednice z dodano črko »B« se uporabljajo samo za proizvode, razvrščene po sistemu na osnovi vrste zlitine.
c) Točke, podtočke in preglednice brez dodane črke »A« ali »B« se uporabljajo za vse proizvode, razvrščene v skladu s tem dokumentom.
Za določanje razvrstitve proizvodov v tem dokumentu se ne uporablja udarni tok.
