EN 4508:2006

Overview

EN 4508:2006 is a European standard developed by CEN that specifies a precise test method for determining the sliding friction behaviour of anti-slip coatings used in aerospace applications. This standard provides a reproducible and quantitative procedure to evaluate the sliding friction coefficient of paints and varnishes formulated as anti-slip coatings, ensuring safety and performance on aerospace surfaces.

The method outlined by EN 4508:2006 is crucial for assessing the effectiveness of coatings in preventing slips and falls by characterizing their frictional resistance under sliding conditions. It applies specifically to test specimens coated on aluminum alloy panels, representative of aerospace surfaces.

Key Topics

• Sliding Friction Coefficient (µ): Defined as the ratio between the sliding friction load and the mass of the sliding block, this coefficient quantifies the anti-slip performance of coatings.
• Test Specimen Preparation: Panels are manufactured using aluminum alloy per EN 2090 specifications and coated with the anti-slip material to a dry film thickness not exceeding 125 µm, then cured as per material specifications.
• Testing Apparatus: The test setup includes a calibrated tensile test machine capable of 500 mm/min pulling speed, a plane steel support plate, a sliding block with NBR rubber strips, a deflection pulley, and connecting cable.
• Test Procedure: The sliding block is drawn across the coated specimen surface under oil-wet conditions (using ASTM-D 471 IRM oil) while frictional loads are recorded continuously over three consecutive runs per specimen.
• Data Analysis: Load-path diagrams are divided into multiple segments to calculate an averaged sliding friction load, which is then used to compute the friction coefficient.
• Reporting Requirements: Test reports must detail specimen identification, preparation, test conditions, equipment, raw data, calculations, and any anomalies affecting results.

Applications

EN 4508:2006 is specifically designed for the aerospace sector, where slip-resistant coatings are critical on aircraft floorings, stair treads, walkways, and other surfaces requiring reliable traction under operational conditions. By applying this standard, manufacturers and certification bodies can:

• Ensure Safety: Verify that anti-slip coatings meet minimum sliding friction requirements, reducing the risk of slips and accidents during aircraft maintenance or passenger movement.
• Material Qualification: Facilitate material selection by providing standardized friction data critical for performance comparisons and compliance with aerospace quality standards.
• Regulatory Compliance: Support adherence to European aerospace regulations and harmonized testing protocols for coatings, aiding aircraft certification and maintenance processes.
• Research and Development: Assist in the design and improvement of anti-slip paint formulations through consistent laboratory testing and benchmarking.

Related Standards

EN 4508:2006 references several key standards and materials essential for consistent testing:

• EN 2090: Specification for aluminum alloy AL-P2024-T3 sheets used as test substrates.
• AMS 3200: Standard describing the NBR rubber used on the sliding block.
• ASTM D471: Standard test method for evaluating rubber properties and effects of liquids, applied here to define the lubricating oil conditions.
• AECMA-STAN Standards: Aerospace paint and coating related specifications contributing to the preparation and performance evaluation of aerospace coatings.

By integrating EN 4508:2006 into testing protocols, aerospace manufacturers and coating suppliers can assure reliable anti-slip performance critical for operational safety and regulatory acceptance.
