EN ISO 2398:1997

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Gummischläuche mit Textileinlage für Druckluft - Anforderung (ISO 2398:1995)Tuyaux en caoutchouc renforcés textile pour l'air comprimé - Spécifications (ISO 2398:1995)Rubber hose, textile-reinforced, for compressed air - Specification (ISO 2398:1995)23.040.70Gumene cevi in armatureHoses and hose assembliesICS:Ta slovenski standard je istoveten z:EN ISO 2398:1997SIST EN ISO 2398:2000en01-december-2000SIST EN ISO 2398:2000SLOVENSKI
STANDARD
INTERNATIONAL STANDARD Fourth edition 1995-l 2-15 Rubber hose, textile-reinforced, for compressed air - Specification Tuyaux en caoutchouc renforcb textile pour I’air cornprim - Spkifications Reference number IS0 2398:1995(E) SIST EN ISO 2398:2000

Foreword IS0 (the International Organization for Standardization) is a worldwide fed- eration of national standards bodies (IS0 member bodies). The work of preparing International Standards is normally carried out through IS0 tech- nical committees. Each member body interested in a subject for which a technical committee has been established has the right to be represented on that committee. International organizations, governmental and non- governmental, in liaison with ISO, also take part in the work. IS0 collabor- ates closely with the International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization. Draft International Standards adopted by the technical committees are circulated to the member bodies for voting. Publication as an International Standard requires approval by at least 75 % of the member bodies casting a vote. International Standard IS0 2398 was prepared by Technical Committee ISOnC 45, Rubber and rubber products, Subcommittee SC 1, Hoses (rubber and plastics). This fourth edition cancels and replaces the third edition (IS0 2398:1987), which has been technically revised. 0 IS0 1995 All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from the publisher. International Organization for Standardization Case postale 56 l CH-1211 Geneve 20 l Switzerland Printed in Switzerland ii SIST EN ISO 2398:2000

NORME INTERNATIONALE o IS0 IS0 2398: 1995(E) Rubber hose, textile-reinforced; for compressed air - Specification 1 Scope This International Standard specifies the requirements for seven types and two classes of rubber hose for compressed air up to a maximum working pressure of 2,5 MPa and a hose operating-temperature range of between -40 “C and + 70 OC, depending on the class. 2 Normative references The following standards contain provisions which, through reference in this text, constitute provisions of this International Standard. At the time of publication, the editions indicated were valid. All standards are subject to revision, and parties to agreements based on this International Standard are encouraged to in- vestigate the possibility of applying the most recent editions of the standards indicated below. Members of IEC and IS0 maintain registers of currently valid International Standards. IS0 3:1973, Preferred numbers - Series of preferred numbers. IS0 37: 1994, Rubber, vulcanized or thermoplastic - Determination of tensile stress-s train properties. I SO 188: 1982, Rubber, vulcanized - Accelerated ageing or heat-resistance tests. IS0 1307: 1992, Rubber and plastics hoses for gen- eral-purpose industrial applications - Bore diameters and tolerances, and tolerances on length. IS0 1402:1994, Rubber and plastics hoses and hose assemblies - H ydos ta tic testing. IS0 1746: 1983, Rubber or plastics hoses and tubing - Bending tests. IS0 1817: 1985, Rubber, vulcanized - Determination of the effect of liquids. IS0 4671: 1984, Rubber and plastics hose and hose assemblies - Methods of measurement of dimen- srons. IS0 4672: -‘I, Rubber and plastics hoses - Sub- ambient-temperature flexibility tests. IS0 7326:1991, Rubber and plastics hoses - As- sessment of ozone resistance under static con- ditions. IS0 8033:1991, Rubber and plastics hose - Determi- nation of adhesion between components. 3 Types and classes of hose Seven types and two classes of hose are specified as follows: Types - Type 1: general industrial air hose for a maximum working pressure of I,0 MPa - Type 2: air hose for heavy-duty construction work and a maximum working pressure of I,0 MPa - Type 3: air hose for heavy-duty construction work and a maximum working pressure of I,0 MPa, and having good oil resistance - Type 4: air hose for heavy-duty construction work and a maximum working pressure of I,6 MPa - Type 5: air hose for heavy-duty construction work and a maximum working pressure of I,6 MPa, and having good oil resistance - Type 6: air hose for heavy-duty construction work and a maximum working pressure of 2,5 MPa 1) To be published. (Revision of IS0 4672:1988) SIST EN ISO 2398:2000

IS0 2398:1995(E) 0 IS0 - Type 7
...
