EN 1254-1:1998

(Main)

Copper and copper alloys - Plumbing fittings - Part 1: Fittings with ends for capillary soldering or capillary brazing to copper tubes

Copper and copper alloys - Plumbing fittings - Part 1: Fittings with ends for capillary soldering or capillary brazing to copper tubes

This European standard specifies materials, assembly dimensions and tolerances and test requirements for fittings of copper and copper alloys with or without plating. Maximum permissible temperatures and pressures are also established. This part of prEN 1254 specifies connection end dimensions of capillary soldering and brazing ends for the purposes of joining copper tubes specified in EN 1057. Fittings may comprise a combination of any of the end types specified in prEN 1254-1 to prEN 1254-5 or other standards. The standard establishes a designation system for the fittings.

Kupfer und Kupferlegierungen - Fittings - Teil 1: Kapillarlötfittings für Kupferrohre (Weich- und Hartlöten)

Diese europäische Norm legt Werkstoffe, Anschlußmaße, Toleranzen und Anforderungen an die Prüfung von Fittings aus Kupfer und Kupferlegierungen mit oder ohne galvanischen Überzug fest sowie die maximal zulässigen Drücke und Temperaturen. Dieser Teil der EN 1254 legt die Abmessungen fest, die für den Anschluß von kapillarlötfittings an Kupferrohre nach EN 1057 geeignet sind. Die Fittings können eine Kombination aller Anschlußarten umfassen, die in prEN 1254-1 bis prEN 1254-5 oder anderen Normen festgelegt sind. Die Norm legt ein Bezeichnungssystem für Fittings fest.

Cuivre et alliages de cuivre - Raccords - Partie 1: Raccords à braser par capillarité pour tubes en cuivre

La présente norme européenne spécifie les matériaux, les dimensions et les tolérances d'assemblage ainsi que les prescriptions d'essai concernant les raccords en cuivre et alliages de cuivre, avec ou sans revêtement. Les températures et les pressions de service maximales acceptables sont aussi établies. Cette partie du prEN 1254 spécifie les dimensions des extrémités de raccords à braser par capillarité destinés à l'assemblage de tubes en cuivre spécifiés dans l'EN 1057. Les raccords peuvent comporter une combinaison de plusieurs types d'extrémités spécifiés dans prEN 1254-1 à -5.

Baker in bakrove zlitine - Fitingi - 1. del: Fitingi s konci za kapilarno mehko in trdo lotanje na bakrene cevi

General Information

Status
Withdrawn
Publication Date
20-Jan-1998
Withdrawal Date
25-May-2021
ICS
23.040.40 - Metal fittings
Technical Committee
CEN/TC 133 - Copper and copper alloys
Drafting Committee
CEN/TC 133/WG 8 - Fittings
Current Stage
9960 - Withdrawal effective - Withdrawal
Completion Date
26-May-2021
Directive
305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
89/106/EEC - Construction products
93/38/EEC - Procurement procedures of entities operating in the water, energy, transport and telecommunications sectors
Mandate
M/131 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on pipes, tanks and ancillaries, not in contact with water intended for human consumption
M/BC/CEN/88/15 - Standardization request to CEN/CENELEC in the field of Water supply, drainage and sewerage
Ref Project
SIST EN 1254-1:1999 - Copper and copper alloys - Plumbing fittings - Part 1: Fittings with ends for capillary soldering or capillary brazing to copper tubes

Relations

Replaced By
EN 1254-1:2021 - Copper and copper alloys - Plumbing fittings - Part 1: Capillary fittings for soldering or brazing to copper tubes
Effective Date
02-Jun-2021
Revised
FprEN 1254-1 - Copper and copper alloys - Plumbing fittings - Part 1: Fittings with ends for capillary soldering or capillary brazing to copper tubes
Effective Date
18-Jan-2023
Child
EN 1254-3:1998 - Copper and copper alloys - Plumbing fittings - Part 3: Fittings with compression ends for use with plastics pipes
Effective Date
22-Dec-2008
Child
EN 1254-2:1998 - Copper and copper alloys - Plumbing fittings - Part 2: Fittings with compression ends for use with copper tubes
Effective Date
22-Dec-2008
Child
EN 1254-4:1998 - Copper and copper alloys - Plumbing fittings - Part 4: Fittings combining other end connections with capillary or compression ends
Effective Date
22-Dec-2008
