EN 4008-005:2006

Overview

EN 4008-005:2006 is a European standard that specifies the product requirements for the positioner used with the M22520/2-01 crimping tool. This positioner is a critical accessory for crimping electrical contacts in aerospace applications, ensuring precise and reliable connections as dictated by the aerospace series elements of electrical and optical connection. Developed under the auspices of the AeroSpace and Defense Industries Association of Europe (ASD-STAN) and endorsed by CEN, this standard facilitates consistent quality and interoperability for aerospace electrical systems.

Key Topics

• Scope and Application
  Defines characteristics for a positioner component designed exclusively for use with the M22520/2-01 crimping tool. It focuses on achieving accurate longitudinal positioning of electrical contacts in compliance with EN 4008-002.

• Design and Functional Requirements

  • Positioner retention on the crimping tool uses two bayonet locks and a spring-loaded central locator.
  • The locator must provide a precise depression of 0.79 mm with a force of 9 ± 4.5 N to ensure the accurate placement of contacts.
  • Material specifications include a blue aluminium alloy body and stainless steel ferrule for durability in demanding aerospace environments.

• Dimensions and Tolerances

  • The positioner’s maximum mass is 30 grams.
  • Precise dimensions and tolerances (±0.25 mm) are mandated to ensure compatibility and repeatability.

• Marking and Identification

  • Clear product marking requirements are outlined for traceability, with examples provided for designation.

• Associated Standards Referenced
  Includes full alignment with related aerospace standards such as EN 4008-001 (technical specifications), EN 4008-002 (crimping tools), EN 2591-100 (test methods), and electrical contact product standards (EN 3155-032, EN 3155-033).

Applications

EN 4008-005:2006 applies in the manufacturing, maintenance, and quality assurance of aerospace electrical and optical connections. The positioner it specifies is essential for:

• Aerospace Electrical Wiring Systems
  Facilitates the reliable crimping of wire contacts, ensuring mechanical stability and electrical integrity in aircraft and spacecraft wiring.

• Defense and Aviation Industry
  Used by manufacturers and repair facilities adhering to strict aerospace standards for connectors, enhancing safety and operational reliability.

• High-Precision Manufacturing
  Enables controlled and repeatable crimping processes critical for the high-performance demands of aerospace electrical systems.

Related Standards

To fully comply with aerospace electrical connection requirements, EN 4008-005:2006 works together with these standards:

• EN 4008-001: Technical specifications for crimping tools and accessories.
• EN 4008-002: Product standards for crimping tools used with electrical contacts.
• EN 2591-100: General test methods for electrical and optical connection elements.
• EN 3155-032 & EN 3155-033: Product standards for coaxial electrical contacts suitable for use with the specified crimping tools.
• MIL C-22520/2: U.S. military specification on crimping tools covering wire barrel sizes 20 through 28.

By adhering to this suite of standards, aerospace manufacturers ensure compatibility, safety, and performance consistency across all electrical connection elements and crimping processes.

Keywords: aerospace standard, crimping tool positioner, M22520/2-01 crimping tool, electrical contacts, aerospace electrical connections, EN 4008-005, positioner specifications, crimping tool accessories, aerospace wiring systems, ASD-STAN standards.
