EN 2591-207:1996

Overview

EN 2591-207:1996 is a European standard under the aerospace series that defines the test methods for voltage proof testing of electrical and optical connection elements. Specifically, this part focuses on the voltage proof test applied to insulators in both mated and unmated connection elements. The standard is published by CEN and is intended to be used in conjunction with EN 2591, ensuring comprehensive testing coverage for aerospace electrical and optical connectors. This standard is critical for verifying the dielectric strength and reliability of connection components in demanding aerospace environments.

Key Topics

• Voltage Proof Test Methodology
  Defines procedures to apply voltage stress to connection insulators to verify their insulation performance and resistance to dielectric breakdown.

• Scope of Application
  Applicable to both mated (connected) and unmated (disconnected) electrical and optical connector elements, ensuring full coverage of possible use scenarios.

• Compliance with EN 2591
  Designed as a complementary part to EN 2591 series standards, establishing a consistent framework for testing aerospace connectors.

• Insulator Evaluation
  Focuses on testing the insulator materials and configurations to ensure high electrical reliability under operating voltage conditions.

• Consistency and Reproducibility
  Provides standardized test parameters to ensure repeatable and comparable results across different laboratories and manufacturers.

Applications

• Aerospace Electrical Equipment
  Ensures connectors used in aircraft and spacecraft meet strict voltage insulation criteria, preventing failures due to electrical breakdown.

• Optical Connection Elements
  Extends reliability testing to optical connectors, which are increasingly used for high-speed data transmission in aerospace systems.

• Connector Quality Assurance
  Helps manufacturers validate connector designs, contributing to product certification and safety compliance.

• Maintenance and Inspection
  Enables aerospace operators to perform routine voltage proof tests to detect early-stage insulation degradation.

• Research and Development
  Assists R&D teams in qualifying new connector materials or designs for aerospace applications.

Related Standards

• EN 2591 Series
  This part 207 should be used together with other parts of the EN 2591 series, covering various test methods and requirements for aerospace electrical and optical connectors.

• IEC and ISO Electrical Connector Standards
  While EN 2591 is aerospace-focused, it complements international standards dealing with connectors and voltage testing.

• Aerospace Quality and Safety Standards
  Aligns with aerospace quality management frameworks like AS9100 to ensure connectors meet rigorous aerospace industry requirements.

By adhering to EN 2591-207:1996, aerospace manufacturers and handlers ensure that electrical and optical connection elements perform reliably under electrical stress. This improves overall system safety, reliability, and longevity in critical aerospace applications.
