EN 12733:2001+A1
March 2009 ICS 65.060.50 Supersedes EN 12733:2001English Version
Agricultural and forestry machinery - Pedestrian controlled motor mowers - Safety
Matériel agricole et forestier - Motofaucheuses à conducteur à pied - Sécurité
Land- und forstwirtschaftliche Maschinen - Handgeführte Motormäher - Sicherheit This European Standard was approved by CEN on 21 January 2001 and includes Corrigendum 1 issued by CEN on 15 October 2003 and Amendment 1 approved by CEN on 29 December 2008.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2009 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 12733:2001+A1:2009: ESIST EN 12733:2001+A1:2009

List of hazards . 37 Annex B (normative)
Noise test code for motor mowers - Engineering method (grade 2) . 42 B.0 Scope . 42 B.1 A-weighted sound power level determination . 42 B.2 A-weighted emission sound pressure level determination . 44 B.3 Requirements for test floor . 44 B.4 Installation, mounting and operating conditions . 44 B.5 Measurement uncertainties and declaration of noise emission values. 45 B.6 Information to be recorded and reported . 45 Annex C (normative)
Vibration measurement of motor mowers . 46 C.1 Quantities to be measured . 46 C.2 Instrumentation . 46 C.3 Measurement direction and measurement location. 46 C.4 Test procedure . 47 C.5 Measurement procedure . 48 C.6 Determination of the measurement result . 49 Annex D (normative)
Foot probe test . 50 D.1 Test equipment . 50 D.2 Test method . 50 D.3 Test acceptance . 50 Annex E (normative)
Material of protective skirts . 52 SIST EN 12733:2001+A1:2009

Corrugated fibreboard penetration tests on grassland mowers - Test enclosure wall panels (see 6.2.2.2.4.2) . 53 F.1 Purpose. 53 F.2 Test fixture . 53 F.3 Fibreboard samples . 53 F.4 Procedure . 53 F.5 Acceptance criteria . 53 Annex G (normative)
Target elevation areas. 55 G.1 Lower elevation target. 55 G.2 Middle elevation target . 55 G.3 Top elevation target . 55 G.4 Operator target area . 55 Annex H (normative)
Test enclosure . 56 H.1 Base . 56 H.2 Target composition . 56 Annex I (normative)
Thrown object test for flail mower . 59 I.1 Principle . 59 I.2 Test installation . 59 I.3 Test procedure . 62 I.4 Test result . 63 I.5 Acceptance criteria . 63 Annex J (normative)
Thrown object test for scrub clearing machines . 64 J.1 Test equipment . 64 J.2 Test method . 64 J.3 Data sheet - Thrown object test for scrub clearing machine . 66 Annex K (informative)
Example of a material and construction fulfilling the requirements for an artificial surface . 68 K.1 Material . 68 K.2 Construction . 68 Annex L (informative)
Examples of machines. 71 Annex ZA (informative)
!!!!Relationship between this European Standard and the Essential Requirements of EU Directive 98/37/EC, amended by Directive 98/79/EC"""" . 72 Annex ZB (informative)
!!!!Relationship between this European Standard and the Essential Requirements of EU Directive 2006/42/EC"""" . 73 Bibliography . 74
(ISO 4871:1996). EN ISO 11201:1995, Acoustics — Noise emitted by machinery and equipment — Measurement of emission sound pressure levels at a work station and at other specified positions — Engineering method in an essentially free field over a reflecting plane (ISO 11201:1995). EN ISO 11688-1:1998, Acoustics — Recommended practice for the design of low-noise machinery and equipment — Part 1: Planning (ISO/TR 11688-1:1995). EN ISO 11688-2:2000, Acoustics — Recommended practice for the design of low-noise machinery and equipment — Part 2: Introduction to the physics of low-noise design. ISO 2758:1983, Paper — Determination of bursting strength. ISO 3789-1:1982, Tractors, machinery for agriculture and forestry, powered lawn and garden equipment — Location and method of operation of operator controls — Part 1: Common controls. ISO 5718-1:1989, Harvesting equipment — Flat blades for rotary mowers — Specifications — Part 1: Type A flat blades. ISO 5718-2:1991, Harvesting equipment — Flat blades for rotary mowers — Part 2: Specifications for type B flat blades. ISO 11102-1:1997, Reciprocating internal combustion engines — Handle starting equipment — Part 1: Safety requirements and tests. ISO 11102-2:1997, Reciprocating internal combustion engines — Handle starting equipment — Part 2: Method of testing the angle of disengagement. SIST EN 12733:2001+A1:2009

Figure 1 — Volume of “hand reach zone” and “foot reach zone” 5.4 Marking of controls Controls, whose purpose is not obvious, shall have the function, direction and/or method of operation clearly identified by a durable label or mark. Detailed instructions on the operation of all controls shall be provided in the instruction handbook. If symbols are used for marking controls, they shall correspond to those in ISO 3767-1:1991 and ISO 3767-3:1995. 5.5 Controls of the movement of the machine and of the blade(s) On motor mowers which are self-propelled it shall be possible to engage or disengage the traction drive when the cutting blade is operating. The movement of the machine and the movement of the blade(s) shall be possible only by actuating hold-to-run controls. The hold-to-run controls shall be located on at least one of the handlebar grips. Motor mowers shall be fitted with a device on the control handle which will automatically stop blade movement when the operator's hands are removed from the handle. For restarting blade movement the hold-to-run control shall require two separate actions. SIST EN 12733:2001+A1:2009

Key 1 Horizontal plane a) Cone A
b) Cone B Figure 2 — Test cones SIST EN 12733:2001+A1:2009

a)
b) Figure 3 SIST EN 12733:2001+A1:2009

Key 1 Swinging outrigger cover 2 Zone A 3 Zone B Figure 4 — Sickle bar mower 6.2 Grassland mowers 6.2.1 Protection against contact with cutting blades The cutting blade tip circle shall not extend beyond the upper enclosure of the machine. Except for an arc at the front of the machine concentric with the cutting blade tip circle and extending up to 90° on either side of the line of working, and up to 30° more on the side from which the grass is ejected (see Figure 5), the casing shall extend vertically at least 3 mm below the plane of the cutting blade tip circle. This requirement shall not apply to the fastening elements of the cutting blade(s) extending downwards if they lie within a concentric circle whose diameter is half that of the outer cutting blade tip circle. For every section of the perimeter of the cutting blade tip circle with less than 3 mm overlap, the casing, a deflector or barrier shall prevent access to the cutting blade. This requirement is considered to be satisfied if either:  this zone (see Figure 5) is provided with a barrier located at a minimum horizontal distance of 200 mm from the cutting blade tip circle and at a maximum vertical distance of 400 mm above the ground; or  this zone shall satisfy the foot probe test in annex D. SIST EN 12733:2001+A1:2009

Key 1 Zone between the two rear wheels 2 Front 3 Rotation axis of the cutting blade NOTE 4 and 5 show optional front and rear barriers to indicate the 200 mm all round the 180° - 30° Figure 5 — Grassland mower - Covering of the cutting blade tip circle (plane view and sectional view) SIST EN 12733:2001+A1:2009
