Key a face-to-face (FTF) b centre-to-face (CTF) Figure 1 — Face to face and centre to face dimensions
Key a face-to-face (FTF)
Type A
Type B Figure 2 — Flanged valves PN and Class designated (flat and raised faces) SIST EN 558:2008+A1:2012

Type C Type D
Type E
Type F
Type G
Type H Key a face-to-face (FTF) Figure 3 — Flanged valves PN designated (spigot and recess) Dimensions in millimetres
Class 150 and Class 300Class 600
Large or small male face
Large or small female face
Large or small tongue
Large or small groove
Key a for dimensions see Table 2 b face-to-face (FTF) c centre-to-face (CTF)
Figure 4 — Flanged valves Class designated 4 Dimensions and tolerances 4.1 Basic series The basic series of FTF and CTF dimensions shall be as given in Table 2. 4.2 Face-to-face and centre-to-face dimensions 4.2.1 General The FTF and CTF dimensions shall be in accordance with Figures 1 to 4. For each type of valve, the basic series to be taken into consideration are given in Table 4 to Table 14. NOTE 1 Table 2 gives complete series. In Table 4 to Table 14 the columns of series may be incomplete. NOTE 2 For certain sizes/types of valves, alternative dimensions are permitted and these are specified in Table 4 to Table 14 as appropriate. NOTE 3 The origin of the basic series is shown in Annex A (informative). For Class designated valves with ring joint flanges, the FTF or CTF dimensions given in Table 2 shall be in-creased by x as defined in the Table 1. SIST EN 558:2008+A1:2012

Key
1 FTF = Dimension of Table 2 + x
a face-to-face (FTF) 2 CTF = Dimension of Table 2 + 0,5 x
b centre-to-face (CTF) Figure 5 - FTF and CTF dimensions for Class designated valves with ring joint flanges SIST EN 558:2008+A1:2012

Dimensions in millimetres Nominal size Additional length x for ring joint flanges DN Class 150 Class 300 Class 600 Class 900 Class 1 500 Class 2 500 15 11,1 11,1 - 1,6 0 0 0 20 12,7 12,7 0 25 32 3,2 40 50 15,9 3,2 3,2 3,2 65 6,4 80 100 9,5 125 12,7 150 6,4 200 9,5 15,9 250 22,2 300 15,9 350 9,5 19,1 — 400 22,2 450 12,7 500 19,1 6,4 600 22,2 9,5 19,1 28,6 700 — 25,4 12,7 — — 750 800 28,6 15,9 900 1 000 " 4.2.2 For valves having a resilient lining which forms the gasket joint with the mating flanges, the FTF and CTF dimensions shall be the distance between the extremities of the valve in the installed condition. If the dimensions for CTF and FTF differ from the standard dimensions, they shall be given by the manufac-turer. 4.2.3 For valves having a resilient or hard lining, the thickness of the lining on the mating surface shall be included in the FTF and CTF dimensions given in Table 2, unless the design of the valve precludes such an inclusion. If this is the case, the manufacturer shall indicate the deviation from the standardised FTF or CTF dimensions in his documentation. SIST EN 558:2008+A1:2012

4.2.4 Raised face flanges For valves:  having flanges with 1,6 mm raised flange:  in grey cast iron, Class 250;  ductile cast iron, Class 150 and 300;  having flanges with 6,4 mm raised flange:  in steel, Class 600. The FTF and CTF dimensions shall be in accordance with Figure 1 and Figure 6.
Dimensions in millimetres
Key a face-to-face (FTF) or centre-to-face (CTF), for dimensions see Table 2
Figure 6 — FTF and CTF dimensions for Class designated valves with raised face flanges
4.3 Tolerances Tolerances on FTF and CTF dimensions are given in Table 3a. Both Tolerances shall be fulfilled. End flange seating surfaces shall be parallel or perpendicular. Tolerances “c” on the parallelism or perpen-dicularity as shown in Figure 7 are given in Table 3b.
Figure 7 — Tolerances on parallelism and perpendicularity
13 Table 2 — Dimensions of basic series
