EN ISO 1172:1998
(Main)Textile-glass-reinforced plastics - Prepregs, moulding compounds and laminates - Determination of the textile-glass and mineral-filler content - Calcination methods (ISO 1172:1996)
Textile-glass-reinforced plastics - Prepregs, moulding compounds and laminates - Determination of the textile-glass and mineral-filler content - Calcination methods (ISO 1172:1996)
Gives two calcination methods for the determination of the textile-glass and mineral-filler content of glass-reinforced plastics. Method A is used for the determination of the textile-glass content when no mineral fillers are present; method B is used when both components are present. Replaces the first edition.
Textilglasverstärkte Kunststoffe - Prepregs, Formmassen und Laminate - Bestimmung des Textilglas- und Mineralfüllstoffgehalts - Kalzinierungsverfahren (ISO 1172:1996)
Diese Internationale Norm legt zwei Kalzinierverfahren zur Bestimmung des Textilglas- und Mineralfüllstoffgehalts von glasfaserverstärkten Kunststoffen fest: Verfahren A: zur Bestimmung des Textilglasgehalts, falls keine Mineralfüllstoffe vorhanden sind. Verfahren B: zur Bestimmung des Textilglas- und Mineralfüllstoffgehalts, wenn beide Bestandteile vorhanden sind.
Plastiques renforcés de verre textile - Préimprégnés, compositions de moulage et stratifiés - Détermination des taux de verre textile et de charge minérale - Méthodes par calcination (ISO 1172:1996)
S stekleno tkanino ojačeni polimerni materiali - Prepregi, zmesi za oblikovanje in laminati - Določevanje steklene tkanine in mineralnih polnil - Metoda s sežigom (ISO 1172:1996)
General Information
Relations
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Textilglasverstärkte Kunststoffe - Prepregs, Formmassen und Laminate - Bestimmung des Textilglas- und Mineralfüllstoffgehalts - Kalzinierungsverfahren (ISO 1172:1996)Plastiques renforcés de verre textile - Préimprégnés, compositions de moulage et stratifiés - Détermination des taux de verre textile et de charge minérale - Méthodes par calcination (ISO 1172:1996)Textile-glass-reinforced plastics - Prepregs, moulding compounds and laminates - Determination of the textile-glass and mineral-filler content - Calcination methods (ISO 1172:1996)83.120Reinforced plasticsICS:Ta slovenski standard je istoveten z:EN ISO 1172:1998SIST EN ISO 1172:2000en01-maj-2000SIST EN ISO 1172:2000SLOVENSKI
STANDARDSIST EN 60:1999/A1:19991DGRPHãþD
INTERNATIONAL STANDARD ISO 1172 Second edition 1996-12-15 Textile-glass-reinforced plastics - Prepregs, moulding compounds and laminates - Determination of the textile- glass and mineral-filler content - Calcination methods Plas tiques ren forcks de verre textile - Preimpr@gn&, compositions de moulage et s tra tifies - Determination des taux de verre textile et de Charge mirGrale - M6 thodes par calcina tion Reference number ISO 1172:1996(E) SIST EN ISO 1172:2000
ISO 1172:1996(E) Foreword ISO (the International Organization for Standardization) is a worldwide federation of national Standards bodies (ISO member bodies). The work of preparing International Standards is normally carried out through ISO technical committees. Esch member body interested in a subject for which a technical committee has been established has the right to be represented on that committee. International organizations, governmental and non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization. Draft International Standards adopted by the technical committees are circulated to the member bodies for voting. Publication as an International Standard requires approval by at least 75 % of the member bodies casting a vote. International Standard ISO 1172 was prepared by Technical Committee ISO/TC 61, Plastics, Subcommittee SC 13, Composites and rehforcement fibres. This second edition cancels and replaces the first edition (ISO 1 172:1975), which has been technically revised (an additional method, method B, has been included and the annex, which concerned the estimation of the Standard deviation, has been replaced by annex A describing an alternative method of separating chopped glass fibre from mineral filier). Annex A of this International Standard is for information only. 0 ISO 1996 All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronie or mechanical, including photocopying and microfilm, without Permission in writing from the publisher. International Orga nization for Standardization Case Postale 56 l CH-1 21 1 Geneve 20 l Switzerland Printed in Switzerland ii SIST EN ISO 1172:2000
INTERNATIONAL STANDARD @ ISO ISO 1172:1996(E) Textile-glass-reinforced plastics - Prepregs, moulding compounds and laminates - Determination of the textile-glass and mineral- filler content - Calcination methods WARNING - This International Standard does not give details of the precautions that should be taken to meet health and safety requirements. The test methods described require the use of high temperatures and concentrated acids. lt is the responsibility of the User of this International Standard to follow the appropriate health and safety procedures. 1 Scope This International Standard specifies two calcination methods for the determination of the textile-glass and mineral- filier content of glass-reinforced plastics: Method A: for the determination of the textile-glass content when no mineral fillers are present. Method B: for the determination of the textile-glass and mineral-filler content when both components are present. This International Standard is applicable to the following types of material: - prepregs made from yarns, rovings, tapes or fabrics; - SMC, BMC and DMC moulding compounds; - textile-glass-reinforced thermoplastic moulding materials and granules; - filled or unfilled textile-glass laminates made with thermosetting or thermoplastic resins. The methods are not applicable to the following types of reinforced plastic: - those containing reinforcements other than textile glass; - those containing materials which do not completely burn off at the test temperature (for example, those based on Silicone resin); - those containing mineral fillers which degrade at temperatures below the minimum calcination temperatute. For these materials, ISO 1 1667, Fibre-reinforced plastics - Maulding compounds and prepregs - Determination of resin, reinforcement-fibre and mineral-filler content - Dissolution method, may be used. SIST EN ISO 1172:2000
ISO 1172:1996(E) @ ISO 2 Normative references The following Standards contain provisions which, through reference in this text, constitute provisions of this International Standard. At the time of publication, the editions indicated were valid. All Standards are subject to revision, and Parties to agreements based on this International Standard are encouraged to investigate the possibility of applying the most recent editions of the Standards indicated below. Members of IEC and ISO maintain registers of currently valid International Standards. ISO 472:1988, Plastics - Vocabulary. ISO 4793: 1980, Laboratory sintered (fritted) filters - Porosity gradhg, classifica tjon and designa tion. ISO 8604: 1988, Plastics - Prepregs - Definitions of terms and Symbols for deslgnations. 3 Definitions For the purposes of this International Standard, the definitions given in ISO 472 and ISO 8604 apply. 4 Principle A test specimen is weighed and subsequently calcinated at a defined temperature. The specimen is then reweighed and the non-combustible matter content (glass + filier) obtained by determining the differente in mass of a test specimen before and after calcination in one of the following ways: a) In the case of materials containing no fillers the glass content is calculated directly from the differente in mass (method A); b) In the case of materials containing both glass and filler, the glass and filier remaining after calcination are separated by dissolution of the filier in hydrochloric acid. The differente between the mass of the specimen before calcination and the mass of the dried specimen after reaction with acid is used to measure the glass content. The filier content is obtained by calculating the differente between the mass of the specimen after calcination and the mass of the dried specimen after reaction with acid (method B). The test method requires that all weighings be made at constant mass after repeated calcination and/or drying. In those cases where known materials are being tested regularly, a minimum time for the calcination and drying stages may be determined by experiment to ensure that constant mass has been reached. NOTES 1 If the material tested contains a resin which is combustible under the test conditions and/or fillers which do not degrade by calcination, then the loss on ignition is equal to the resin content. lt should be noted that the resin content calculated in this way includes the combustible part of the other components in the composition (glass size, Pigments, etc.) but this is usually small compared to the resin content. 2 In those cases where fillers are present that are degraded at the test temperature, it is not possible to obtain an accurate determination of the glass, resin or filier content. 5 Sampling 5.1 The determination of the glass and filier contents is shall be carried out in parallel on two specimens which are as near identical as possible. The result of the test is the average of the measurements on the two specimens, provided that the differente between the two measurements is less than 5 %. If this is not the case, a third specimen shall be tested which is as near identical to the other two as possible. The three values shall then be used to calculate the test result. 5.2 In Order to carry out an evaluation test the result of which is as representative as possible of the glass and filier content of the elementary unit or laboratory Sample, this test procedure may need to be repeated a certain number of times, at specific locations in the elementary unit examined. The number of times and the actual SIST EN ISO 1172:2000
0 ISO ISO 1172:1996(E) locations will be defined either in the product specification or by the person reques tin g the case, the number and location will be decided by experience or as the result 0 f previo us work. 5.3 For all tests other than those under test as circumstances allow. on elementary units, take specimens that are as representative of the material 6 Preparation of test specimens The test specimen s shal accordance with cla use 5. I be fully representative of the piece or batch examined. They shall be obtained in analysis. In the latter Unless otherwise specified, it is recommended that the specimens be tut out in a shape which allows them to fit into a silica boat or porcelain crucible. The mass of each specimen shall be within the range 2 g to 20 g for prepregs and moulding compounds; 2 g to 10 g for laminates. For each test result, use a minimum of two specimens (see 5.1). In the case of prepregs and moulding compounds which contain solvents or free monomer, care shall be taken to avoid loss of volatile matter. For SMC, the protective release film shall not be removed from the laboratory Sample or the test specimen until just before commencing the test procedure. All prepreg and moulding-compound laboratory samples, including SMC, shall be sealed in a vapourproof plastic bag immediately after the laboratory Sample has been taken. 7 Determination The choice of method used to determine the glass and filler content will depend on the presence or absence of filler. The methods described in this International Standard are Method A: for the determination of the glass content when no fillers are present. Method B: for the determination of the glass and filler content when both components are present. 7.1 Method A 7.1.1 Reagents No reagents are required for method A. 7.1.2 Apparatus Normal laboratory apparatus, plus the fol
...
