EN 10225:2009
(Main)Weldable structural steels for fixed offshore structures - Technical delivery conditions
Weldable structural steels for fixed offshore structures - Technical delivery conditions
This European Standard specifies requirements for weldable structural steels to be used in the fabrication of fixed offshore structures in the form of plates up to and including 150 mm thick. It also specifies sections up to 63 mm thick except for sections delivered in the as-rolled condition which are permitted up to 25 mm thick only. Seamless hollow sections up to and including 40 mm thick and high frequency electric resistance welded hollow sections up to and including 20 mm thick are specified. Greater thicknesses for sections and hollow sections may be agreed, provided the technical requirements of this European Standard are maintained.
For plates the thickness limitations are:
S355G2+N, S355G5+M, - up to and including 20 mm
S355G3+N, S355G6+M - up to and including 40 mm
S355G7+N, S355G8+N, S355G9+N, S355G10+N - up to and including 150 mm
S355G7+M, S355G8+M, S355G9+M, S355G10+M - up to and including 100 mm
S420G1+Q, S420G1+M, S420G2+Q, S420G2+M - up to and including 100 mm
S460G1+Q, S460G1+M, S460G2+Q, S460G2+M - up to and including 100 mm
The standard is applicable to steels for offshore structures, designed to operate in the offshore sector but not to steels supplied for the fabrication of subsea pipelines, risers, process equipment, process piping, and other utilities. It is primarily applicable to the North Sea Sector, but may also be applicable in other areas provided that due consideration is given to local conditions e.g. temperature.
In the case of hollow sections formed from plate with the seam fusion welded, this European standard covers only the requirements of the plate material.
Minimum yield strengths up to 460 MPa are specified together with low temperature impact properties at temperatures down to –40 °C.
This European standard applies to material supplied ex-mill or from merchant's stock.
Schweißgeeignete Baustähle für feststehende Offshore-Konstruktionen - Technische Lieferbedingungen
Diese Europäische Norm legt die Anforderungen an schweißgeeignete Baustähle fest, die zur Herstellung von
fest stehenden Offshore-Konstruktionen verwendet werden, und zwar in Form von Blechen mit einer Dicke bis
einschließlich 150 mm; von Profilen mit einer Dicke bis 63 mm, außer bei Profilen im Walzzustand, die nur bis
zu einer Dicke von 25 mm geliefert werden, sowie von nahtlosen Hohlprofilen mit eine Dicke bis einschließlich
40 mm und von elektrisch widerstandsgeschweißten Hohlprofilen mit einer Dicke bis einschließlich 20 mm.
Größere Dicken für Profile und Hohlprofile können vereinbart werden, vorausgesetzt, die technischen
Lieferbedingungen dieser Norm werden eingehalten.
Für Bleche gelten die folgenden Dickenbeschränkungen:
S355G2+N, S355G5+M: bis einschließlich 20 mm;
S355G3+N, S355G6+M: bis einschließlich 40 mm;
S355G7+N, S355G8+N, S355G9+N, S355G10+N: bis einschließlich 150 mm;
S355G7+M, S355G8+M, S355G9+M, S355G10+M: bis einschließlich 100 mm;
S420G1+QT, S420G1+M, S420G2+QT, S420G2+M: bis einschließlich 100 mm;
S460G1+QT, S460G1+M, S460G2+QT, S460G2+M: bis einschließlich 100 mm.
Diese Norm gilt für Stähle für Offshore-Konstruktionen, die für den Einsatz im Offshore-Bereich vorgesehen
sind, jedoch nicht für Stähle zur Herstellung von Unterwasser-Pipelines, Steigleitungen (risers), Verfahrens-
Ausrüstungen, Rohrsystemen und anderen Einrichtungen und Ausrüstungen. Sie gilt in erster Linie für den
Bereich der Nordsee, kann jedoch auch für andere Gebiete angewendet werden, vorausgesetzt, dass die
örtlichen Bedingungen, z. B. die Temperatur, genügend berücksichtigt werden.
Bei Hohlprofilen, die aus Blech mit schmelzgeschweißter Naht erzeugt werden, deckt diese Europäische
Norm nur die Anforderungen an den Blechwerkstoff ab.
Mindestwerte der Streckgrenze bis zu 460 MPa sind zusammen mit Tieftemperatur-Kerbschlageigenschaften
bei Temperaturen bis zu −40 °C festgelegt.
Aciers de construction soudables destinés à la fabrication de structures marines fixes - Conditions techniques de livraison
La présente Norme européenne spécifie les prescriptions applicables aux aciers de construction soudables
destinés à la fabrication de structures marines fixes sous forme de tôles, d'épaisseur inférieure ou égale à
150 mm. Elle spécifie également les prescriptions applicables aux profilés d'épaisseur jusqu'à 63 mm, à
l'exception des profilés livrés à l'état brut de laminage (G) qui ne sont autorisés que jusqu'à 25 mm
d'épaisseur. Les spécifications applicables aux profils creux sans soudure (S) d'épaisseur inférieure ou égale
à 40 mm et aux profils creux soudés par résistance électrique à haute fréquence (HFW) d'épaisseur inférieure
ou égale à 20 mm sont également indiquées. Des épaisseurs plus importantes pour les profilés normaux et
les profils creux peuvent être acceptées, sous réserve de respecter les prescriptions techniques de la
présente Norme européenne.
Pour les tôles, les limites d'épaisseur sont les suivantes :
S355G2+N, S355G5+M, - jusqu'à 20 mm inclus ;
S355G3+N, S355G6+M - jusqu'à 40 mm inclus ;
S355G7+N, S355G8+N, S355G9+N, S355G10+N - jusqu'à 150 mm inclus ;
S355G7+M, S355G8+M, S355G9+M, S355G10+M - jusqu'à 100 mm inclus ;
S420G1+Q, S420G1+M, S420G2+Q, S420G2+M - jusqu'à 100 mm inclus ;
S460G1+Q, S460G1+M, S460G2+Q, S460G2+M - jusqu'à 100 mm inclus.
La norme s'applique aux aciers pour constructions marines exploitées sur le domaine maritime européen, à
l'exclusion des aciers fournis pour réaliser des oléoducs sous-marins, conduites montantes, équipement de
procédés et autres tuyauteries de transport. Elle s'applique prioritairement au secteur de la mer du Nord mais
elle peut également s'appliquer dans d'autres zones dans la mesure où les conditions locales sont dûment
prises en compte, notamment la température.
Dans le cas de profils creux constitués de tôles soudées par fusion, la norme ne concerne que les
prescriptions applicables à la tôle en tant que matériau.
Konstrukcijska jekla za varjene konstrukcije naftnih ploščadi - Tehnični dobavni pogoji
General Information
- Status
- Withdrawn
- Publication Date
- 30-Jun-2009
- Withdrawal Date
- 20-Jan-2026
- Technical Committee
- ECISS/TC 103 - Structural steels other than reinforcements
- Drafting Committee
- ECISS/TC 103 - Structural steels other than reinforcements
- Current Stage
- 9960 - Withdrawal effective - Withdrawal
- Start Date
- 15-May-2019
- Completion Date
- 21-Jan-2026
Relations
- Effective Date
- 08-Jun-2022
- Effective Date
- 04-Jul-2009
- Effective Date
- 08-Jun-2022
- Effective Date
- 08-Jun-2022
- Effective Date
- 08-Jun-2022
- Effective Date
- 08-Jun-2022
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Frequently Asked Questions
EN 10225:2009 is a standard published by the European Committee for Standardization (CEN). Its full title is "Weldable structural steels for fixed offshore structures - Technical delivery conditions". This standard covers: This European Standard specifies requirements for weldable structural steels to be used in the fabrication of fixed offshore structures in the form of plates up to and including 150 mm thick. It also specifies sections up to 63 mm thick except for sections delivered in the as-rolled condition which are permitted up to 25 mm thick only. Seamless hollow sections up to and including 40 mm thick and high frequency electric resistance welded hollow sections up to and including 20 mm thick are specified. Greater thicknesses for sections and hollow sections may be agreed, provided the technical requirements of this European Standard are maintained. For plates the thickness limitations are: S355G2+N, S355G5+M, - up to and including 20 mm S355G3+N, S355G6+M - up to and including 40 mm S355G7+N, S355G8+N, S355G9+N, S355G10+N - up to and including 150 mm S355G7+M, S355G8+M, S355G9+M, S355G10+M - up to and including 100 mm S420G1+Q, S420G1+M, S420G2+Q, S420G2+M - up to and including 100 mm S460G1+Q, S460G1+M, S460G2+Q, S460G2+M - up to and including 100 mm The standard is applicable to steels for offshore structures, designed to operate in the offshore sector but not to steels supplied for the fabrication of subsea pipelines, risers, process equipment, process piping, and other utilities. It is primarily applicable to the North Sea Sector, but may also be applicable in other areas provided that due consideration is given to local conditions e.g. temperature. In the case of hollow sections formed from plate with the seam fusion welded, this European standard covers only the requirements of the plate material. Minimum yield strengths up to 460 MPa are specified together with low temperature impact properties at temperatures down to –40 °C. This European standard applies to material supplied ex-mill or from merchant's stock.
This European Standard specifies requirements for weldable structural steels to be used in the fabrication of fixed offshore structures in the form of plates up to and including 150 mm thick. It also specifies sections up to 63 mm thick except for sections delivered in the as-rolled condition which are permitted up to 25 mm thick only. Seamless hollow sections up to and including 40 mm thick and high frequency electric resistance welded hollow sections up to and including 20 mm thick are specified. Greater thicknesses for sections and hollow sections may be agreed, provided the technical requirements of this European Standard are maintained. For plates the thickness limitations are: S355G2+N, S355G5+M, - up to and including 20 mm S355G3+N, S355G6+M - up to and including 40 mm S355G7+N, S355G8+N, S355G9+N, S355G10+N - up to and including 150 mm S355G7+M, S355G8+M, S355G9+M, S355G10+M - up to and including 100 mm S420G1+Q, S420G1+M, S420G2+Q, S420G2+M - up to and including 100 mm S460G1+Q, S460G1+M, S460G2+Q, S460G2+M - up to and including 100 mm The standard is applicable to steels for offshore structures, designed to operate in the offshore sector but not to steels supplied for the fabrication of subsea pipelines, risers, process equipment, process piping, and other utilities. It is primarily applicable to the North Sea Sector, but may also be applicable in other areas provided that due consideration is given to local conditions e.g. temperature. In the case of hollow sections formed from plate with the seam fusion welded, this European standard covers only the requirements of the plate material. Minimum yield strengths up to 460 MPa are specified together with low temperature impact properties at temperatures down to –40 °C. This European standard applies to material supplied ex-mill or from merchant's stock.
EN 10225:2009 is classified under the following ICS (International Classification for Standards) categories: 77.140.10 - Heat-treatable steels. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 10225:2009 has the following relationships with other standards: It is inter standard links to EN 10225:2001, EN 10225:2001/AC:2002, EN 10225-1:2019, EN 10225-2:2019, EN 10225-3:2019, EN 10225-4:2019, EN 10025-3:2019, EN ISO 6947:2019, EN ISO 15614-1:2017, EN ISO 6507-1:2023, EN 10210-2:2019, EN 10025-6:2019+A1:2022, EN 10210-1:2006, EN ISO 12737:2010, EN 1011-1:2009. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN 10225:2009 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.SRJRMLSchweißgeeignete Baustähle für feststehende Offshore- Konstruktionen - Technische LieferbedingungenAciers de construction soudables destinés à la fabrication de structures marines fixes - Conditions techniques de livraisonWeldable structural steels for fixed offshore structures - Technical delivery conditions77.140.10Jekla za toplotno obdelavoHeat-treatable steelsICS:Ta slovenski standard je istoveten z:EN 10225:2009SIST EN 10225:2009en,fr,de01-september-2009SIST EN 10225:2009SLOVENSKI
STANDARDSIST EN 10225:2002/AC:2003SIST EN 10225:20021DGRPHãþD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 10225July 2009ICS 77.140.10Supersedes EN 10225:2001
English VersionWeldable structural steels for fixed offshore structures -Technical delivery conditionsAciers de construction soudables destinés à la fabricationde structures marines fixes - Conditions techniques delivraisonSchweißgeeignete Baustähle für feststehende Offshore-Konstruktionen - Technische LieferbedingungenThis European Standard was approved by CEN on 5 June 2009.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre:
Avenue Marnix 17,
B-1000 Brussels© 2009 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 10225:2009: ESIST EN 10225:2009
Location of test samples for tensile and impact tests . 46Annex B (normative)
Location of tensile test piece when two rolled surfaces cannot be retained . 48Annex C (normative when option 2 is specified by the purchaser)
Details of manufacturing procedures to be supplied by the manufacturer for steels of groups 2 and 3 . 49Annex D (normative when option 16 is specified by the purchaser)
Cold forming characteristics for steel plate of groups 2 and 3 . 50Annex E (normative when option 18 is specified by the purchaser)
Weldability testing for steels of groups 2 and 3 and mechanical testing of butt welds . 51Annex F (normative when option 18 is specified by the purchaser)
Weldability testing for steels of groups 2 and 3 - Bead-on-plate . 68Annex G (normative)
Weldability testing for steels of groups 2 and 3 - Controlled thermal severity tests (CTS) . 70Bibliography . 76 SIST EN 10225:2009
EN ISO 4063, Welding and allied processes — Nomenclature of processes and reference numbers
(ISO 4063:1998) EN ISO 6507-1, Metallic materials — Vickers hardness test — Part 1: Test method (ISO 6507-1:2005) EN ISO 6947, Welds — Working positions — Definitions of angles of slope and rotation (ISO 6947:1993) EN ISO 8492, Metallic materials — Tube — Flattening test (ISO 8492:1998) EN ISO 9934-1, Non-destructive testing —- Magnetic particle testing — Part 1: General principles (ISO 9934-1:2001) EN ISO 12737, Metallic materials — Determination of plane-strain fracture toughness (ISO 12737:2005) EN ISO 14284:2002, Steel and iron — Sampling and preparation of samples for the determination of chemical composition (ISO 14284:1996) EN ISO 15614-1, Specification and qualification of welding procedures for metallic materials — Welding procedure test — Part 1: Arc and gas welding of steels and arc welding of nickel and nickel alloys
(ISO 15614-1:2004+A1:2008) 3 Terms and definitions For the purposes of this standard, the following terms and definitions and those given in EN 10020:2000, EN 10021:2006, EN 10052:1993, EN 10079:2007 and EN ISO 14284:2002 apply: SIST EN 10225:2009
3.12.1 quenching operation which consists of cooling a ferrous product more rapidly than in still air NOTE Quenching also includes direct quenching. 3.12.2 tempering heat treatment applied to a ferrous product generally after quench hardening or other heat treatment to bring the properties to the required level NOTE 1 It consists of heating to specific temperatures (< Ac1) and soaking one or more times followed by cooling at an appropriate rate. NOTE 2 For the purposes of this European standard, the designation of delivery condition quenched and tempered is +QT. 4 Information to be supplied by the purchaser 4.1 General The following information shall be supplied by the purchaser at the time of enquiry and order: a) details of the product form; b) number of this European standard i.e. EN 10225; c) the steel grade (steel name or steel number); d) the type of inspection documents required (see 9.1); e) where applicable, the number of additional copies of inspection documents required and the forwarding address (see 9.2); f) nominal dimensions and when necessary tolerances; g) where applicable, that the material is required for the manufacture of piling; h) purchaser’s order number and item number if applicable; i) quantity. SIST EN 10225:2009
plate with thickness ≥≥≥≥ 12 mm Length (L)
m Maximum number of ripples or corrugations L ≤ 6 6 < L ≤ 9 9 < L ≤ 12 12 < L ≤ 15 2 3 4 5
with thickness ≥≥≥≥ 10 mm < 12 mm Length (L)
m Maximum number of ripples or corrugations L ≤ 6 6 < L ≤ 9 9 < L ≤ 12 12 < L ≤ 15 4 5 6 8 5.2 Mass of steel The calculated mass shall be determined using a density of 7,85 kg/dm3. 6 Classification and designation 6.1 Classification The steel grade S355 specified in this European Standard is classified as alloy quality steel and the steel grades S420 and S460 specified in this European Standard are classified as alloy special steels according to EN 10020. This standard includes the following grades: a) Group 1 grades with few changes from EN 10025 Parts 1, 3 and 4 and EN 10210-1: (minor changes to chemical analysis, CEV and impact requirements only); b) Groups 2 and 3 grades substantially modified from EN 10025 Parts 1, 3 and 4 and EN 10210-1 including qualities with enhanced through-thickness ductility. 6.2 Designation For the steel grades covered by this European Standard the steel names are based on EN 10027-1. The steel numbers are allocated in accordance with EN 10027-2. The designation consists of: a) the number of this European Standard i.e. EN 10225; b) the symbol S; c) the indication of the minimum specified yield strength for thicknesses ≤ 16 mm expressed in MPa; d) the letter G, followed by the relevant digit(s) characterizing the steel grade; e) where applicable, the letter indicating the delivery condition i.e. +N, +M or +QT (see 7.3). SIST EN 10225:2009
Plate with few changes from EN 10025-3 and with minimum specified Re = 355 MPa and impact values
verified at –20 °C, supplied in the normalized or normalized rolled condition. b) Plate to grade S355G6+M
Plate with few changes from EN 10025-4 and with minimum specified Re = 355 MPa and impact values
verified at –40 °C, supplied in the thermomechanically rolled condition. 7.3.2 Plates of groups 2 and 3 Plates shall be supplied in the furnace normalized (+N), thermomechanically rolled (+M) or quenched and tempered (+QT) condition. The customer shall specify the appropriate grade at the time of enquiry and order. SIST EN 10225:2009
Plate substantially modified from EN 10025-3 (or EN 10025-4) and with minimum specified Re = 355 MPa and impact values
verified at –40 °C, supplied in the normalized or normalized rolled (or thermomechanically rolled) condition. NOTE The normalized rolled condition is only permitted when option 5 has been called up. b) Plate to grade S460G2+QT (or S460G2+M)
Plate substantially modified from EN 10025-6 (or EN 10025-4), with controlled chemistry, particularly carbon, minimum specified Re = 460 MPa and impact values verified
at –40 °C with specified through-thickness properties, supplied in the quenched and tempered (or thermomechanically rolled) condition. 7.3.3 Sections Sections shall be supplied in the as-rolled, normalized/normalized rolled (+N) or thermomechanically rolled (+M) condition as shown in Tables 11 and 12, at the manufacturer’s discretion. The as-rolled delivery condition is limited to a maximum thickness of 25 mm. 7.3.4 Hollow sections Hollow sections shall be supplied in the normalized/normalized rolled (+N) or quenched and tempered (+QT) condition as shown in Tables 13 to 16 at the manufacturer’s discretion. NOTE S420 and S460 grades are normally only available in circular form. 8 Requirements 8.1 General In addition to the requirements of this European Standard, the general technical delivery requirements specified in EN 10021 also apply. 8.2 Chemical composition 8.2.1 Cast analysis a) The chemical composition for all qualities determined by cast analysis shall comply with the values in Tables 6, 11, 13 and 15. b) For residual element control in steels of groups 2 and 3, boron (B) shall not be intentionally added to the steel. The deliberate addition of any elements other than those listed in Tables 6, 11, 13 and 15 shall not be permitted. c) When a restricted cast analysis is agreed for steels of groups 2 and 3, the steel shall comply with the agreed analysis range. See option 7. SIST EN 10225:2009
See option 6. b) When restricted product analysis is agreed the steel shall comply with the agreed analysis range. See option 7. 8.2.3 Carbon equivalent value (CEV) and Pcm 8.2.3.1 General CEV1) and Pcm shall be calculated using the following equations where each element is expressed as a mass percentage: 8.2.3.2 Plates The maximum permissible CEV and Pcm values for plates are given in Table 3. These apply to product analysis except for grades S355G2+N, G3+N, G5+M and G6+M which shall be based on cast analysis. The CEV value shall apply for all designations except S355G9+N, G9+M, G10+N and G10+M where the Pcm value shall apply. See option 9.
1) IIW, International Institute of Welding formular 1556Ni + Cu + VCr + Mo +
+ MnCEV = C +
(1) cmP = C + Si30 + Mn + Cu + Cr20 + Ni60 + Mo15 + V10 + 5B (2) SIST EN 10225:2009
max. max. S355G2+N
0,43
Not specified S355G3+N S355G5+M S355G6+M S355G7+N
0,43
0,24 S355G7+M S355G8+N S355G8+M S355G9+N
0,43
0,22 S355G10+N S355G9+M
0,41b/0,42c
0,21b/0,22c S355G10+M S420G1+QT
0,42
0,22d S420G1+M S420G2+QT S420G2+M S460G1+QT
0,43
0,22d S460G1+M S460G2+QT S460G2+M a For steel numbers, see Tables 6 to 16. b For t ≤ 75 mm. c For 75 mm < t ≤ 100 mm. d A Pcm value of 0,23 for t ≤ 15 mm is permitted. 8.2.3.3 Sections The CEV of all sections shall not exceed 0,43. See option 9, where a Pcm value not exceeding 0,24 shall apply in lieu of CEV. These values apply to the product analysis except for grades S355G1, G1+N, G4 and G4+M where cast analysis shall apply. 8.2.3.4 Hollow sections The CEV of all hollow sections shall not exceed 0,43. See option 9, where a Pcm value not exceeding 0,25 shall apply in lieu of a CEV. These values apply to the product analysis except for the grade S355G1+N where cast analysis shall apply. SIST EN 10225:2009
See option 20. 8.5.2.2 Internal soundness for steels of group 1 The material shall be sound and free from such internal defects as might preclude its use for the purpose for which it is intended.
See option 21. 8.5.2.3 Internal soundness for steels of groups 2 and 3 The material shall be sound and free from such internal defects as might preclude its use for the purpose for which it is intended. Internal soundness for rolled sections with web thickness greater than 12 mm shall be subject to ultrasonic examination of webs and flanges when specified by the purchaser and shall meet the requirements of
EN 10306:2001, Class 2.1. See option 21. NOTE Testing of the region between the web and the flange should be subject to agreement between the supplier and the purchaser. 8.5.3 Hollow sections 8.5.3.1 Surface condition Hollow sections shall be free from external and internal defects that can be detected by visual inspection in accordance with this European Standard as follows: The outside surface condition and, where practical, the inside surface condition shall be such that surface discontinuities requiring dressing and/or surface defects can be identified. It shall be permissible to rectify surface discontinuities by grinding or machining, provided that after so doing, the hollow section thickness in the dressed region is not less than the minimum permissible wall thickness. All dressed areas shall blend smoothly into the contour of the section. SIST EN 10225:2009
See option 22. 8.5.3.3 Non-destructive testing of the weld seam of welded hollow sections The weld seam of welded hollow sections shall be tested full length for longitudinal defects in accordance with EN 10246-3, EN 10246-5 or EN 10246-8 to acceptance levels E4, F4 or U4 respectively. NOTE For rectangular or square hollow sections this is normally carried out in the circular form before squaring. The method of test shall be at the discretion of the manufacturer. When EN 10246-5 or EN 10246-8 are used, calibration shall be carried out using an external reference notch. When the purchaser has indicated that welded hollow sections are to be used in primary elements, the internal weld bead shall be removed and the weld seam tested full length for longitudinal defects in accordance with EN 10246-8 to acceptance level U3. Calibration shall be carried out using both internal and external reference notches. See option 23. 8.5.3.4 Non-destructive testing of seamless hollow sections All seamless hollow sections shall be ultrasonically tested for longitudinal defects in accordance with EN 10246-7 to acceptance level U3/C. When the purchaser has indicated that the seamless hollow section is to be used in primary elements, they shall be tested in accordance with EN 10246-7 to acceptance level U2/C.
See option 23. 9 Inspection and testing 9.1 General The products shall be subjected to specific inspection and testing in accordance with EN 10021 and supplied with an inspection document in accordance with EN 10204. The purchaser shall indicate on the enquiry and order the type of inspection document required and, where applicable, their nominated representative. SIST EN 10225:2009
available (see 9.4); 6) dimensions; 7) designation of steel (see 6.2). b) Composition 1) cast analysis; 2) product analysis where applicable; 3) carbon equivalent value where applicable (CEV); 4) Pcm value where applicabl
...
