INTERNATIONAL STANDARD ISO 14324:2003(E)

Resistance spot welding — Destructive tests of welds —
Method for the fatigue testing of spot welded joints
1 Scope
This International Standard specifies test specimens and procedures for fatigue testing spot welds, at ambient
conditions, under repeated tensile loading to produce either shear or cross-tension loading of the spot weld, in
steel of sheet thicknesses of 0,5 mm to 6 mm. The test results are not, in general, directly applicable to the
fatigue behaviour of a spot-welded component or structure. This procedure can be used for other materials
provided proper test conditions (e.g., heating) have been determined.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 669, Resistance welding — Resistance welding equipment — Mechanical and electrical requirements
ISO 14271, Vickers hardness testing of resistance spot, projection and seam welds (low load and
microhardness)
ISO 14272, Specimen dimensions and procedure for cross tension testing resistance spot and embossed
projection welds
ISO 14273, Specimen dimensions and procedure for shear testing resistance spot, seam and embossed
projection welds
ISO 14329, Resistance welding — Destructive tests of welds — Failure types and geometric measurements
for resistance spot, seam and projection welds
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1
cross-tension fatigue test
fatigue test that entails the application of a repeated tensile load to the cross-tension fatigue test specimen
mounted between the jaws of the fatigue-testing machine
3.2
endurance limit
maximum load range at which the test specimen can endure a designated number of load cycles without
failing
3.3
fatigue life
N
number of cycles that can be applied at a specified load before failure occurs
ISO 14324:2003(E)
3.4
1)
fatigue limit
maximum load range at which the test specimen can endure an infinite number of load cycles
3.5
1)
L-N curve
curve drawn by plotting the load range as ordinate and the fatigue life (or fatigue endurance if the test is
terminated before failure) as abscissa, also called the load range-number of load cycles curve
NOTE It is normal practice to use logarithmic axes.
3.6
load amplitude
L
a
half of the load range
L = 0,5∆L
a
3.7
load ratio
R
minimum load divided by the maximum load
R = L /L
min max
3.8
load range
∆L
difference between the maximum and minimum loads
∆L = L − L
max min
3.9
maximum load
L
max
highest algebraic value of the repeated load
3.10
mean load
L
m
average o
...
