Aerospace series - Lockbolts, protruding head, sheartype, close tolerance, in titanium alloy TI-P64001, anodized, metric series - Classification: 1 100 MPa (at ambient temperature) / 315 °C

This standard specifies the characteristics of lockbolts with protruding head, sheartype, close tolerance, in titanium alloy TI-P64001, anodized, metric series, for use in aerospace applications.
Classification : 1 100 MPa  / 315 °C
In both versions, i.e. with and without pintail these lockbolts fulfill the same function when installed and are statically / dynamically equivalent.
They are intended to be used with collars to EN 4174 or EN 4175.

Luft- und Raumfahrt - Passniete, mit Universalkopf, Schertyp, aus Titanlegierung TI-P64001, anodisiert, metrische Reihe - Klasse: 1 100 MPa (bei Raumtemperatur) / 315 °C

Diese Norm legt die Merkmale von Passnieten mit Universalkopf, für Scherbeanspruchung, aus Titanlegierung TI P64001, anodisiert, metrische Reihe, für Anwendungen in der Luft- und Raumfahrt fest.
Klasse: 1 100 MPa  )/315 °C )
In beiden Ausführungen, d. h. mit und ohne Abrissteil, erfüllen diese Passniete nach dem Einbau die gleiche Funktion und sind statisch und dynamisch gleichwertig.
Sie sind für die Verwendung mit Schließringen nach EN 4174 oder EN 4175 bestimmt.

Série aérospatiale - Rivets à bague sertie, à tête cylindrique, à cisaillement, à tolérance serrée, en alliage de titane TI-P64001, anodisés, série métrique - Classification : 1 100 MPa (à température ambiante) / 315 °C

Aeronavtika - Zapirni vijaki, dvignjena glava, strižni tip, ozka toleranca, iz titanove zlitine TI-P64001, anodizirani, metrska serija - Klasifikacija: 1 100 MPa (pri temperaturi okolice) / 315 °C

General Information

Status
Published
Publication Date
11-Apr-2006
Withdrawal Date
30-Oct-2006
ICS
49.030.60 - Rivets
Technical Committee
ASD-STAN - Aerospace
Drafting Committee
ASD-STAN/D 3 - Mechanical
Current Stage
9093 - Decision to confirm - Review Enquiry
Start Date
31-May-2017
Completion Date
14-Apr-2025
Ref Project
SIST EN 4172:2008 - Aerospace series - Lockbolts, protruding head, sheartype, close tolerance, in titanium alloy TI-P64001, anodized, metric series - Classification: 1 100 MPa (at ambient temperature) / 315 °C

Overview

EN 4172:2006 defines the characteristics of aerospace lockbolts - protruding head, shear-type, close tolerance - manufactured in titanium alloy TI‑P64001, anodized, metric series. The standard is intended for structural aerospace use and carries the material classification: 1 100 MPa (at ambient temperature) / 315 °C. Both versions - with pintail (version P) and without pintail (version S) - are statically and dynamically equivalent when installed. These lockbolts are intended to be used with collars conforming to EN 4174 or EN 4175.

Key Topics

  • Scope and classification: Defines intended aerospace applications and the tensile/temperature classification (1 100 MPa / 315 °C).
  • Configuration and dimensions: Metric geometry, close-tolerance dimensions and mass values are specified (diameter and length codes, tolerances apply after surface treatment).
  • Versions: Version P (pull-type with pintail) and version S (stub-type without pintail) - both functionally equivalent in service.
  • Materials: Titanium alloy per TR 3775 (TI‑P64001) - strength class as above.
  • Surface treatment and lubrication:
    • Anodizing per EN 2808 (titanium anodizing).
    • Lubrication guidance referencing MIL‑L‑87132 (cetyl alcohol).
  • Marking and identification: Marking style per EN 2424, and prescribed description/identity block formats (example: EN4172P040–140G).
  • Technical specification / procurement: Detailed technical requirements and test/spec references are covered and cross-referenced to EN 4176 for related lockbolt specifications.
  • Normative references: Lists the essential standards and technical reports needed to apply EN 4172.

Applications

Who uses EN 4172:2006 and why:

  • Aerospace designers & structural engineers specifying high-strength, lightweight shear fasteners for airframe assemblies.
  • Procurement and quality teams ensuring purchased fasteners meet titanium TI‑P64001 material, anodizing, marking and tolerance requirements.
  • Fastener manufacturers and suppliers producing metric-series lockbolts to aerospace tolerances and surface finishes.
  • Maintenance, repair and overhaul (MRO) operations that replace or verify OEM-standard lockbolts. Practical uses include fastening shear-loaded joints in airframes and aircraft subsystems where titanium’s high strength-to-weight and temperature resistance are required.

Related Standards

  • EN 4174 (collars, swage locking, aluminium)
  • EN 4175 (collars, flanged swage locking, titanium)
  • EN 4176 (technical specification for related lockbolts)
  • EN 2808 (anodizing titanium)
  • EN 2424 (marking of aerospace products)
  • TR 3775 (bolt/pin materials), MIL‑L‑87132 (lubricant)

Keywords: EN 4172:2006, lockbolts, titanium TI‑P64001, aerospace fasteners, anodized, close tolerance, shear-type, protruding head, pintail, EN 4174, EN 4175.

Frequently Asked Questions

EN 4172:2006 is a standard published by the European Committee for Standardization (CEN). Its full title is "Aerospace series - Lockbolts, protruding head, sheartype, close tolerance, in titanium alloy TI-P64001, anodized, metric series - Classification: 1 100 MPa (at ambient temperature) / 315 °C". This standard covers: This standard specifies the characteristics of lockbolts with protruding head, sheartype, close tolerance, in titanium alloy TI-P64001, anodized, metric series, for use in aerospace applications. Classification : 1 100 MPa / 315 °C In both versions, i.e. with and without pintail these lockbolts fulfill the same function when installed and are statically / dynamically equivalent. They are intended to be used with collars to EN 4174 or EN 4175.

This standard specifies the characteristics of lockbolts with protruding head, sheartype, close tolerance, in titanium alloy TI-P64001, anodized, metric series, for use in aerospace applications. Classification : 1 100 MPa / 315 °C In both versions, i.e. with and without pintail these lockbolts fulfill the same function when installed and are statically / dynamically equivalent. They are intended to be used with collars to EN 4174 or EN 4175.

EN 4172:2006 is classified under the following ICS (International Classification for Standards) categories: 49.030.60 - Rivets. The ICS classification helps identify the subject area and facilitates finding related standards.

EN 4172:2006 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
