Introduction
There is growing recognition of the importance of aerosol particles with diameters D < 1 µm for human
health as well as for their effects on climate. While usually the mass concentration of airborne particles
is quantified both in the environment and at the workplace, various studies have shown the relevance of
the number and surface area concentration to their health effects. Correlations between the incidence of
respiratory diseases and the number concentrations of airborne particles are, e.g. given in [1]. It was
shown that the effects on health due to inhaled particles correlate better with the particle surface area
dose than with the particle mass dose [2] or the particle number dose [3]. To describe the air quality in
terms of dust load, it therefore appears advisable to supplement the parameters of mass concentration
(for PM and PM , see EN 12341 [4]), particle number concentration and number size distribution
10 2,5
(see prEN 16976 [5] and CEN/TS 17434 [6]) with measurements of further metrics, e.g. particle surface
area concentration as a health-relevant metric.
For the measuring device required for the implementation of the measuring method described in this
document, the designation “electrical aerosol monitor based on diffusion charging” abbreviated to DCAM
(Diffusion-Charger-based Aerosol Monitor) is introduced.
kSIST-TS FprCEN/TS 18073:2024
FprCEN/TS 18073:2024 (E)
1 Scope
This document specifies a process for the electrical diffusion charging of aerosols with subsequent
measurement of particle charge. With the aid of this method, it is possible to determine the lung-
deposited surface area (LDSA) concentration of particles in ambient air. Depending on the design of the
electrical diffusion charger, the LDSA of particles in the size range of approximately 20 nm to
approximately 300 nm is measurable.
Furthermore, this document specifies design criteria for LDSA measuring aerosol monitors as well as
performance criteria and the associated test procedures. The performance criteria depend on the
application and they are more stringent when the instrument is operated in an air quality monitoring
station.
In the determination of the LDSA concentration, the share of geometric particle surface area
concentration is determined that can be deposited in the alveolar region of the human lung. Typical
particle surface area concentrations with alveolar deposition measured in urban areas range from
2 3 2 3
5 µm /cm to 50 µm /cm .
Instruments based on this measurement principle can be designed to be very compact with a low power
consumption. This makes them ideally suited for hand-held measurements, other forms of mobile
application or to measure personal exposure. On the other hand, they can be easi
...
