EN 530:2010
(Main)Abrasion resistance of protective clothing material - Test methods
Abrasion resistance of protective clothing material - Test methods
This European Standard describes two test methods on abrasion resistance of materials using the same abrasion apparatus. The first method describes the determination of the abrasion resistance of protective clothing materials. The second method describes abrasion pre-treatment of these materials where the test specimens are used afterwards in other test methods or for evaluating the remaining protective properties.
The abradant is regarded to be a woven wool fabric for the purposes of this standard.
If other abradants (e.g. glass paper) are used, they should be specified in the requirement standard. Mounting instructions of special abradants should be described in requirement standards.
This European Standard is applicable as a reference standard on abrasion for standards and specifications on protective clothing textile materials.
Abriebfestigkeit von Material für Schutzkleidung - Prüfverfahren
Diese Europäische Norm beschreibt zwei Prüfverfahren zur Abriebfestigkeit von Materialien, bei denen das gleiche Gerät zur Anwendung kommt. Das erste Prüfverfahren beschreibt die Bestimmung der Abriebfestigkeit von Schutzkleidungsmaterial. Das zweite Prüfverfahren beschreibt die Vorbehandlung durch Abrieb dieser Materialien, bei denen die Prüfmuster nach der Vorbehandlung anderen Prüfverfahren unterzogen werden, oder bei denen die verbleibenden Schutzeigenschaften beurteilt werden.
Als Scheuermittel im Sinne dieser Norm wird ein Wollgewebe festgelegt.
Werden andere Scheuermittel (z. B. Glas-Schleifblätter) verwendet, so sollten diese in der entsprechenden Anforderungsnorm festgelegt werden. Festlegungen zur Befestigung von Scheuermitteln sollten in den Anforderungsnormen angegeben werden.
Diese Europäische Norm kann als Bezugsnorm für die Abriebfestigkeit in Normen und Spezifikationen für textile Schutzkleidungsmaterialien genutzt werden.
Résistance à l'abrasion du matériau constitutif d'un vêtement de protection - Méthodes d'essai
La présente Norme européenne décrit deux méthodes d’essai de résistance à l’abrasion des matériaux,
toutes deux utilisant le même appareillage. La première méthode décrit la détermination de la résistance à
l’abrasion des matériaux constitutifs des vêtements de protection. La seconde méthode décrit un
prétraitement par abrasion de ces matériaux lorsque les échantillons d’essai sont utilisés ultérieurement pour
l’évaluation des propriétés de protection restantes.
L’abrasif de la présente norme est considéré comme étant un tissu de laine.
Si d’autres abrasifs sont utilisés (comme le papier de verre par exemple), il convient qu’ils soient notés dans
les exigences de la norme spécifique. Il convient que les instructions de mise en place des abrasifs spéciaux
soient décrites dans les exigences de la norme.
La présente Norme européenne s’applique comme norme de référence sur l’abrasion pour les normes et les
spécifications relatives aux vêtements de protection.
Material za varovalno obleko, odporen proti obrabi - Preskusne metode
Ta evropski standard opisuje dve preskusni metodi za materiale, odporne proti obrabi, ki uporabljata isti aparat za drgnjenje. Prva metoda opisuje ugotavljanje odpornosti proti obrabi materialov za varovalno obleko. Druga metoda opisuje predobdelavo pri obrabi teh materialov, pri kateri se preskusni primerki uporabijo kasneje pri drugih preskusnih metodah ali za vrednotenje drugih varovalnih lastnosti. V tem standardu je pripomoček za drgnjenje volnena tkanina. Če se uporabljajo drugi pripomočki za drgnjenje (npr. stekleni papir), morajo biti določeni v standardu za zahteve. Navodila za namestitev posebnih pripomočkov za drgnjenje marojo biti opisana v standardih za zahteve. Ta evropski standard se uporablja kot referenčni standard o obrabi za standarde in specifikacije tekstilnih materialov za varovalno obleko.
General Information
Relations
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Material za varovalno obleko, odporen proti obrabi - Preskusne metodeAbriebfestigkeit von Schutzkleidungsmaterial - PrüfverfahrenRésistance à l'abrasion du matériau constitutif d'un vêtement de protection - Méthodes d'essaiAbrasion resistance of protective clothing material - Test methods13.340.10Varovalna oblekaProtective clothingICS:Ta slovenski standard je istoveten z:EN 530:2010SIST EN 530:2010en,fr,de01-oktober-2010SIST EN 530:2010SLOVENSKI
STANDARDSIST EN 530:1996/AC:1998SIST EN 530:19961DGRPHãþD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 530
July 2010 ICS 13.340.10 Supersedes EN 530:1994English Version
Abrasion resistance of protective clothing material - Test methods
Résistance à l'abrasion du matériau constitutif d'un vêtement de protection - Méthodes d'essai
Abriebfestigkeit von Material für Schutzkleidung - Prüfverfahren This European Standard was approved by CEN on 19 June 2010.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2010 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 530:2010: ESIST EN 530:2010
Significant technical changes between this document and the previous edition of this European Standard . 11Annex ZA (informative)
Relationship between this European Standard and the Essential Requirements of EU Directive 89/686/EEC . 12 SIST EN 530:2010
conditioning and testing atmosphere; debris removal; pressure applied; judgement of deterioration in case of using method 1; number of cycles in case of using method 2. In general these parameters are specified in product standards.
in woven fabrics, when two separate threads are completely broken; in knitted fabrics, when one thread is broken down causing a hole to appear; in pile fabrics, when the pile is fully worn off; in nonwovens, when the first hole resulting from the wear is of a diameter at least equal to 0,5 mm; in coated material, when coating surface has the first hole resulting from the wear of a diameter at least equal to 0,5 mm (hole does not have to be through material) 3.2 abrasion rub one revolution of the outer drives of the Martindale abrasion tester 3.3 test interval amount of rubs to be preset for mandatory abrasion stop for breakdown evaluation and for cleaning the specimen and abradant or to change it SIST EN 530:2010
5 Apparatus and materials 5.1 Abrasion machine Martindale abrasion machine as described in EN ISO 12947-1. 5.2 Abradant Woven wool fabric conforming to EN ISO 12947-1:1998, Table 1. If other abradants are used, these shall be specified in the specific product requirement standard.
5.3 Foam Polyetherurethane foam material as specified in EN ISO 12947-1:1998, Table 3. Foam is used in test pieces holders under specimen or abradant. When tested material or abradant have a mass per unit area more than 500 g/m², foam is not used. 5.4 Felt Felt backing as specified in EN ISO 12947-1:1998, Table 2. Felt is used in abrasion tables under the tested material or abradant. 5.5 Cutter Punch or press cutter, to cut a circle of (385,00+) mm in diameter. SIST EN 530:2010
...
