(Main)Aerospace series - Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous - Part 013: Plug, size 1, with ground block, without mounting holes, class B and F - Product standard
Aerospace series - Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous - Part 013: Plug, size 1, with ground block, without mounting holes, class B and F - Product standard
This European Standard specifies the size 1 plug with ground block for disconnect applications used in the family of modular rectangular electrical and optical connector with rectangular inserts. The receptacle corresponding to this plug is defined in EN 4644-012 and EN 4644-014.
Luft- und Raumfahrt - Elektrische und optische Rechtecksteckverbinder, modular, rechteckige Kontakteinsätze, Dauerbetriebstemperatur 175 °C (oder 125 °C) konstant - Teil 013: Freier Steckverbinder, Größe 1, mit Erdungseinrichtung, ohne Montagebohrungen, Klassen B und F - Produktnorm
Série aérospatiale - Connecteur, électrique et optique, rectangulaire, modulaire, à inserts rectangulaires, température de fonctionnement 175 °C (ou 125 °C) continu - Partie 013 : Fiche, taille 1, avec bloc de masse, sans trous de fixation, classes B et F - Norme de produit
La présente norme européenne spécifie les fiches de taille 1 avec bloc de masse pour applications pour panneau de coupure utilisées dans la famille des connecteurs électriques et optiques rectangulaires, modulaires avec des inserts rectangulaires. L'embase correspondant à cette fiche est définie dans l'EN 4644-012 et l'EN 4644-014.
Aeronavtika - Konektor, električni in optični, pravokotni, modularni, pravokotni kontaktni vložki, stalna delovna temperatura 175 °C (ali 125 °C) - 013. del: Vtič, velikost 1, z ozemljitvenim ohišjem, brez pritrdilnih izvrtin, razreda B in F - Standard za proizvod
Ta evropski standard določa vtič velikosti 1 z ozemljitvenim ohišjem za odklopne naprave, ki se uporabljajo v družini modularnih pravokotnih električnih in optičnih konektorjev s pravokotnimi vložki. Vtičnica, ki ustreza temu vtiču, je opredeljena v standardih EN 4644-012 in EN 4644-014.
