EN ISO 787-7:2009
(Main)General methods of test for pigments and extenders - Part 7: Determination of residue on sieve - Water method - Manual procedure (ISO 787-7:2009)
General methods of test for pigments and extenders - Part 7: Determination of residue on sieve - Water method - Manual procedure (ISO 787-7:2009)
ISO 787-7:2009 specifies a general method of test for determining the residue on sieve from a sample of pigment or extender dispersed in water.
Allgemeine Prüfverfahren für Pigmente und Füllstoffe - Teil 7: Bestimmung des Siebrückstandes - Wasserverfahren - Handspülverfahren (ISO 787-7:2009)
Dieser Teil von ISO 787 legt ein allgemeines Prüfverfahren zur Bestimmung des Siebrückstandes einer in Wasser aufgeschlämmten Pigment- oder Füllstoffprobe fest.
ISO 787-18, General methods of test for pigments and extenders — Part 18: Determination of residue on sieve — Mechanical flushing procedure, legt ein allgemeines Prüfverfahren zur Bestimmung des Sieb-rückstandes einer Pigment- oder Füllstoffprobe nach einem mechanischen Spülverfahren fest.
Bei den meisten Pigmenten und Füllstoffen führen ISO 787-7 und ISO 787-18 gewöhnlich zu unter¬schied-lichen Ergebnissen. Es ist deshalb wichtig, dass zu einer Anforderung angegeben wird, welches Verfahren anzuwenden ist, und im Prüfbericht, welches Verfahren angewendet wurde.
ANMERKUNG Die in den verschiedenen Teilen von ISO 787 angegebenen allgemeinen Verfahren sind im Allgemeinen auf jedes Pigment oder jeden Füllstoff anwendbar. In die Internationale Norm mit den Anforderungen für das jeweilige Pigment oder den jeweiligen Füllstoff braucht deshalb nur ein Querverweis auf den entsprechenden Teil von ISO 787 aufgenommen zu werden, mit einem Hinweis auf jede Abweichung, die im Hinblick auf die speziellen Eigenschaften des Produktes erforderlich ist. Nur wenn die allgemeinen Verfahren für ein bestimmtes Produkt nicht anwendbar sind, ist ein anderes Verfahren zur Bestimmung des Siebrückstandes festzulegen.
Méthodes générales d'essai des pigments et matières de charge - Partie 7: Détermination du refus sur tamis - Méthode à l'eau - Méthode manuelle (ISO 787-7:2009)
L'ISO 787-7:2009 spécifie une méthode générale d'essai destinée à déterminer le refus sur tamis d'un échantillon de pigment ou de matière de charge dispersé dans l'eau.
Splošne metode preskušanja pigmentov in polnil - 7. del: Določanje ostanka na situ - Metoda z vodo - Ročni postopek (ISO 787-7:2009)
General Information
- Status
- Published
- Publication Date
- 30-Sep-2009
- Withdrawal Date
- 29-Apr-2010
- Technical Committee
- CEN/TC 298 - Pigments and extenders
- Drafting Committee
- CEN/TC 298 - Pigments and extenders
- Current Stage
- 6060 - Definitive text made available (DAV) - Publishing
- Start Date
- 01-Oct-2009
- Completion Date
- 01-Oct-2009
Relations
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Overview
EN ISO 787-7:2009 - "General methods of test for pigments and extenders - Part 7: Determination of residue on sieve - Water method - Manual procedure" - specifies a standardized laboratory procedure for measuring the residue on sieve from a sample of pigment or extender dispersed in water. The method defines sampling, apparatus, dispersion, manual sieving and washing, drying and weighing of the retained fraction, calculation of residue (percent by mass) and mandatory test-report items.
Key topics and technical requirements
- Scope: Applies to pigments and extenders dispersed in water; results can differ from the mechanical flushing procedure (ISO 787-18), so the chosen method must be stated in specifications and reports.
- Sampling: Take a representative sample per ISO 15528.
- Apparatus: metal test sieve (ISO 565) - nominal aperture must be reported (45 µm often used); brush, sintered‑glass crucible (porosity P40 per ISO 4793) or 50 ml beaker; oven at (105 ± 2) °C; balances (up to 1 000 g to 0.1 g and high‑precision to 1 mg); desiccator; washbottle.
- Test portion size: typically 10–100 g; up to 1 000 g for very low-residue products. Duplicate determinations are required.
- Dispersion: Water (300–600 ml) with an agreed dispersing agent (typically 0.2–0.5 % of test mass) or mechanical stirring per ISO 3262‑9 (stirrer speed recommended ≤ (500 ± 50) min−1). The dispersing method and agent must be reported.
- Procedure: Pour dispersion through the sieve, rinse until washings are clear, optionally break agglomerates with a brush, transfer residue to crucible/beaker, dry and weigh. If residue melting point < 110 °C, use an agreed lower drying temperature and report it.
- Results: Calculate residue (%) = (mass of residue / mass of test portion) × 100; report mean of two valid determinations to two significant figures; report “less than 0.01 %” when applicable. Precision data are not provided in the standard.
- Test report must include: product ID, reference to ISO 787‑7, sieve aperture and diameter, test mass, dispersion method and dispersant details, whether agglomerates were broken, residue description, deviations and test date.
Applications - who uses this standard
- Quality control and R&D laboratories in paints, coatings, inks and related industries.
- Manufacturers and suppliers of pigments and extenders who must demonstrate particle-size cleanliness or detect oversized agglomerates.
- Procurement, technical specification writers and certification bodies needing a repeatable residue on sieve test for product acceptance.
- Useful for troubleshooting dispersion issues, verifying milling/dispersing efficiency, and comparing batches.
Related standards
- ISO 565 - Test sieves (mesh apertures)
- ISO 4793 - Sintered (fritted) filter porosity classification
- ISO 15528 - Sampling for paints, varnishes and raw materials
- ISO 3262‑9 - Mechanical dispersion equipment for extenders (referenced for alternate stirring)
- ISO 787‑18 - Residue on sieve - Mechanical flushing procedure (alternative method)
Keywords: EN ISO 787-7:2009, residue on sieve, pigments and extenders, water method, manual procedure, sieve test, dispersing agent, ISO 565, test report.
Frequently Asked Questions
EN ISO 787-7:2009 is a standard published by the European Committee for Standardization (CEN). Its full title is "General methods of test for pigments and extenders - Part 7: Determination of residue on sieve - Water method - Manual procedure (ISO 787-7:2009)". This standard covers: ISO 787-7:2009 specifies a general method of test for determining the residue on sieve from a sample of pigment or extender dispersed in water.
ISO 787-7:2009 specifies a general method of test for determining the residue on sieve from a sample of pigment or extender dispersed in water.
EN ISO 787-7:2009 is classified under the following ICS (International Classification for Standards) categories: 87.060.10 - Pigments and extenders. The ICS classification helps identify the subject area and facilitates finding related standards.
EN ISO 787-7:2009 has the following relationships with other standards: It is inter standard links to EN 12503-2:2001, EN 12878:2014. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN ISO 787-7:2009 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Allgemeine Prüfverfahren für Pigmente und Füllstoffe - Teil 7: Bestimmung des Siebrückstandes - Wasserverfahren - Handspülverfahren (ISO 787-7:2009)Méthodes générales d'essai des pigments et matières de charge - Partie 7: Détermination du refus sur tamis - Méthode à l'eau - Méthode manuelle (ISO 787-7:2009)General methods of test for pigments and extenders - Part 7: Determination of residue on sieve - Water method - Manual procedure (ISO 787-7:2009)87.060.10Pigmenti in polnilaPigments and extendersICS:Ta slovenski standard je istoveten z:EN ISO 787-7:2009SIST EN ISO 787-7:2009en,fr01-december-2009SIST EN ISO 787-7:2009SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN ISO 787-7
October 2009 ICS 87.060.10 English Version
General methods of test for pigments and extenders - Part 7: Determination of residue on sieve - Water method - Manual procedure (ISO 787-7:2009)
Méthodes générales d'essai des pigments et matières de charge - Partie 7: Détermination du refus sur tamis - Méthode à l'eau - Méthode manuelle (ISO 787-7:2009)
Allgemeine Prüfverfahren für Pigmente und Füllstoffe -Teil 7: Bestimmung des Siebrückstandes - Wasserverfahren - Handspülverfahren (ISO 787-7:2009) This European Standard was approved by CEN on 5 October 2009.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2009 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN ISO 787-7:2009: ESIST EN ISO 787-7:2009
Reference numberISO 787-7:2009(E)© ISO 2009
INTERNATIONAL STANDARD ISO787-7Second edition2009-10-01General methods of test for pigments and extenders — Part 7: Determination of residue on sieve — Water method — Manual procedure Méthodes générales d'essai des pigments et matières de charge — Partie 7: Détermination du refus sur tamis — Méthode à l'eau — Méthode manuelle
ISO 787-7:2009(E) PDF disclaimer This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but shall not be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In downloading this file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat accepts no liability in this area. Adobe is a trademark of Adobe Systems Incorporated. Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation parameters were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In the unlikely event that a problem relating to it is found, please inform the Central Secretariat at the address given below.
©
ISO 2009 All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or ISO's member body in the country of the requester. ISO copyright office Case postale 56 • CH-1211 Geneva 20 Tel.
+ 41 22 749 01 11 Fax
+ 41 22 749 09 47 E-mail
copyright@iso.org Web
www.iso.org Published in Switzerland
ii © ISO 2009 – All rights reserved
ISO 787-7:2009(E) © ISO 2009 – All rights reserved iii Contents Page Foreword.iv 1 Scope.1 2 Normative references.1 3 Sampling.1 4 Apparatus.2 5 Procedure.2 6 Expression of results.3 7 Test report.4 Annex A (normative)
Mechanical stirrer.5
ISO 787-7:2009(E) iv © ISO 2009 – All rights reserved Foreword ISO (the International Organization for Standardization) is a worldwide federation of national standards bodies (ISO member bodies). The work of preparing International Standards is normally carried out through ISO technical committees. Each member body interested in a subject for which a technical committee has been established has the right to be represented on that committee. International organizations, governmental and non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization. International Standards are drafted in accordance with the rules given in the ISO/IEC Directives, Part 2. The main task of technical committees is to prepare International Standards. Draft International Standards adopted by the technical committees are circulated to the member bodies for voting. Publication as an International Standard requires approval by at least 75 % of the member bodies casting a vote. Attention is drawn to the possibility that some of the elements of this document may be the subject of patent rights. ISO shall not be held responsible for identifying any or all such patent rights. ISO 787-7 was prepared by Technical Committee ISO/TC 35, Paints and varnishes, Subcommittee SC 2, Pigments and extenders. This second edition cancels and replaces the first edition (ISO 787-7:1981), which has been technically revised. The main technical changes are: a) the apparatus clause has been amended; b) a number of modifications have been made to the determination. ISO 787 consists of the following parts, under the general title General methods of test for pigments and extenders: ⎯ Part 1: Comparison of colour of pigments ⎯ Part 2: Determination of matter volatile at 105 °C ⎯ Part 3: Determination of matter soluble in water — Hot extraction method ⎯ Part 4: Determination of acidity or alkalinity of the aqueous extract ⎯ Part 5: Determination of oil absorption value ⎯ Part 7: Determination of residue on sieve — Water method — Manual procedure ⎯ Part 8: Determination of matter soluble in water — Cold extraction method ⎯ Part 9: Determination of pH value of an aqueous suspension ⎯ Part 10: Determination of density — Pyknometer method ⎯ Part 11: Determination of tamped volume and apparent density after tamping ⎯ Part 13: Determination of water-soluble sulfates, chlorides and nitrates ⎯ Part 14: Determination of resistivity of aqueous extract SIST EN ISO 787-7
...
