Aerospace series - Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous - Part 022: Plug, size 2, with mounting holes, class A, C and E - Product standard

This European Standard specifies the size 2 plug for disconnect applications used in the family of modular rectangular electrical and optical connector with rectangular inserts. The receptacle corresponding to this plug is defined in EN 4644-024 or EN 4644-025 or EN 4644-026.

Luft- und Raumfahrt - Elektrische und optische Rechtecksteckverbinder, modular, rechteckige Kontakteinsätze, Dauerbetriebstemperatur 175 °C (oder 125 °C) konstant - Teil 022: Freier Steckverbinder, Größe 2, mit Montagebohrungen, Klassen A, C und E - Produktnorm

Série aérospatiale - Connecteur, électrique et optique, rectangulaire, modulaire, à inserts rectangulaires, température de fonctionnement 175 °C (ou 125 °C) continu - Partie 022 : Fiche, taille 2, avec trous de fixation, classes A, C et E - Norme de produit

Aeronavtika - Konektor, električni in optični, pravokotni, modularni, pravokotni vložki, stalna delovna temperatura 175 °C (ali 125 °C) - 022. del: Vtič, velikost 2, s pritrdilnimi izvrtinami, razredi A, C in E - Standard za proizvod

Ta evropski standard določa vtičnico, velikosti 2, za odklopne naprave, ki se uporabljajo v družini modularnih pravokotnih električnih in optičnih konektorjev s pravokotnimi vložki. Vtičnica, ki ustreza temu vtiču, je opredeljena v standardu EN 4644-024 ali EN 4644-025 ali EN 4644-026.

General Information

Status
Published
Publication Date
03-Nov-2015
Withdrawal Date
30-May-2016
ICS
49.060 - Aerospace electric equipment and systems

49.090 - On-board equipment and instruments
Technical Committee
ASD-STAN - Aerospace
Drafting Committee
ASD-STAN/D 2 - Electrical
Current Stage
6060 - Definitive text made available (DAV) - Publishing
Start Date
04-Nov-2015
Completion Date
04-Nov-2015
Ref Project
SIST EN 4644-022:2016 - Aerospace series - Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous - Part 022: Plug, size 2, with mounting holes, class A, C and E - Product standard

Relations

Refers
EN 4644-024:2015 - Aerospace series - Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous - Part 024: Receptacle size 2, class A, C and E - Product standard
Effective Date
28-Jan-2026
Refers
EN 4644-001:2017 - Aerospace series - Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous - Part 001: Technical specification
Effective Date
28-Jan-2026
Refers
EN 4644-026:2015 - Aerospace series - Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous - Part 026: Receptacle size 2 with ground block, class B and F - Product standard
Effective Date
28-Jan-2026
Refers
EN 4644-025:2015 - Aerospace series - Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous - Part 025: Receptacle, size 2, with flange, class A, C and E - Product standard
Effective Date
28-Jan-2026
Referred By
EN 3155-002:2024 - Aerospace series - Electrical contacts used in elements of connection - Part 002: List and utilization of contacts
Effective Date
28-Jan-2026
Referred By
EN 4644-002:2016 - Aerospace series - Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous - Part 002: Specification of performance and contact arrangements
Effective Date
28-Jan-2026

Overview

EN 4644-022:2015 is a CEN aerospace product standard that defines the size 2 plug (male connector) used for disconnect applications in the modular rectangular family of electrical and optical connectors with rectangular inserts. The series is intended for high-temperature continuous operation (175 °C or 125 °C) and covers mechanical interface, mounting and identification details for plugs in shell classes A, C and E. The matching receptacles are specified in EN 4644-024, EN 4644-025 and EN 4644-026.

Key Topics

  • Scope and purpose
    • Specifies the size 2 plug configuration within the EN 4644 modular rectangular connector family for aerospace use.
  • Operating temperature
    • Rated for continuous operation at 175 °C (or 125 °C) as stated in the series title.
  • Mechanical dimensions and panel cut-out
    • Includes required external dimensions and recommended panel cut-out (figures provided in the standard).
    • Panel fastener information: two screw heads with maximum diameter 6 mm (per figure note).
  • Mounting hole and thread options
    • Three housing types for mounting:
      • D - two clear holes Ø 3.09 mm min (3.20 mm max)
      • L - two 4-40 UNC threaded holes
      • F - two 6-32 UNC threaded holes
  • Mass
    • Maximum mass of the plug: 40 g.
  • Designation and identification
    • Designation format example: EN 4644-022ADX, where the code conveys standard number, shell class, housing type (D/L/F) and polarization according to EN 4644-002.
  • Normative references
    • Relies on series documents for technical specification and performance: EN 4644-001, EN 4644-002 and the corresponding receptacle parts (EN 4644-024/025/026).

Applications

  • Aerospace electrical and optical systems requiring modular, rectangular disconnect connectors rated for elevated continuous temperatures.
  • Use cases:
    • Aircraft wiring harnesses, avionics equipment panels and line-replaceable units (LRUs) where robust, high-temperature plug interfaces are required.
  • Typical users:
    • Connector designers and manufacturers, aerospace systems engineers, procurement/specification teams, qualification and test laboratories.

Related Standards

  • EN 4644-001 - Technical specification for the modular family
  • EN 4644-002 - Specification of performance and contact arrangements
  • EN 4644-024 / EN 4644-025 / EN 4644-026 - Receptacle product standards that mate with the size 2 plug

Keywords: EN 4644-022, aerospace connector, size 2 plug, rectangular modular connector, high-temperature connector, disconnect plug, mounting holes, panel cut-out, shell class.
