EN ISO 2580-1:1999

SLOVENSKI STANDARD
SIST EN ISO 2580-1:2000
01-maj-2000
3ROLPHUQLPDWHULDOL0DWHULDOL]DREOLNRYDQMHLQHNVWUXGLUDQMHQDRVQRYL
WHUSROLPHURYDNULORQLWULOEXWDGLHQVWLUHQ$%6GHO6LVWHPR]QDþHYDQMDLQ
SRGODJH]DVSHFLILNDFLMH,62
Plastics - Acrylonitrile/butadiene/styrene (ABS) moulding and extrusion materials - Part
1: Designation system and basis for specifications (ISO 2580-1:1997)
Kunststoffe - Acrylnitril/Butadien/Styrol (ABS)-Formmassen - Teil 1:
Bezeichnungssystem und Basis für Spezifikationen (ISO 2580-1:1997)
Plastiques - Acrylonitrile/butadiene/styrene (ABS) pour moulage et extrusion - Partie 1:
Systeme de désignation et base de spécification (ISO 2580-1:1997)
Ta slovenski standard je istoveten z: EN ISO 2580-1:1999
ICS:
83.080.20 Plastomeri Thermoplastic materials
SIST EN ISO 2580-1:2000 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------

SIST EN ISO 2580-1:2000

---------------------- Page: 2 ----------------------

SIST EN ISO 2580-1:2000

---------------------- Page: 3 ----------------------

SIST EN ISO 2580-1:2000

---------------------- Page: 4 ----------------------

SIST EN ISO 2580-1:2000

---------------------- Page: 5 ----------------------

SIST EN ISO 2580-1:2000

---------------------- Page: 6 ----------------------

SIST EN ISO 2580-1:2000
INTERNATIONAL IS0
2580-l
STANDARD
Third edition
1997-07-01
Plastics - Acrylonitrile/butadiene/styrene
(ABS) moulding and extrusion materials -
Part 1:
Designation system and basis for
specifications
Plastiques - Acrylonitrilehtadi&ne/styr&ne (A BS) pour moulage et
extrusion -
Partie I: Systhme de dhignation et base de spkification
Reference number
IS0 2580-l :1997(E)

---------------------- Page: 7 ----------------------

SIST EN ISO 2580-1:2000
ISO2580=1:1997(E)
Foreword
IS0 (the International Organization for Standardization) is a worldwide
federation of national standards bodies (IS0 member bodies). The work of
preparing International Standards is normally carried out through IS0
technical committees. Each member body interested in a subject for which
a technical committee has been established has the right to be represented
on that committee. international organizations, governmental and non-
governmental, in liaison with ISO, also take part in the work. IS0
collaborates closely with the International Electrotechnical Commission
(IEC) on all matters of electrotechnical standardization.
Draft International Standards adopted by the technical committees are
circulated to the member bodies for voting. Publication as an International
Standard requires approval by at least 75 % of the member bodies casting
a vote.
lnternational Standard IS0 2580-l was prepared by Technical Committee
ISOmC 61, Plastics, Subcommittee SC 9, Thermoplastic materials.
This third edition cancels and replaces the second edition (IS0 2580-I :I 990),
the text of which has been brought into accordance with the standard SC 9
frame text.
IS0 2580 consists of the following parts, under the general title Plastics -
Acrylonitrile/butadiene/styrene (A BS) moulding and extrusion materials :
- Part I: Designation system and basis for specifications
- Parf 2: Preparation of test specimens and determination of properties
0 IS0 1997
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced
or utilized in any form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from the publisher.
International Organization for Standardization
Case postale 56 l CH-1211 Geneve 20 l Switzerland
Internet central @ iso.ch
x.400 c=ch; a=400net; p=iso; o=isocs; s=central
Printed in Switzerland
ii

---------------------- Page: 8 ----------------------

SIST EN ISO 2580-1:2000
INTERNATIONAL STANDARD @ IS0 IS0 2580-l :1997(E)
- Acrylonitrile/butadiene/styrene (ABS) moulding and
Plastics
extrusion materials -
Part 1:
Designation system and basis for specifications
1 Scope
1 .l This part of IS0 2580 establishes a system of designation for acrylonitrile/butadiene/styrene thermoplastic
material, which may be used as the basis for specifications.
1.2 The types of ABS plastic are differentiated from each other by a classification system based on appropriate
levels of the designatory properties
a) Vicat softening temperature
b) melt flow rate
c) lzod impact strength
d) flexural modulus
and on information about basic polymer parameters, intended application and/or method of processing, important
properties, additives, colourants, fillers and reinforcing materials.
1.3 This part of IS0 2580 is applicable to all styrene/acrylonitrile copolymers comprised of a continuous phase,
consisting of copolymers of styrene (and/or an alkyl-substituted styrene) and acrylonitrile, and a dispersed
elastomeric phase based on butadiene, with the continuous phase having more than 10 % (m/m) of acrylonitrile.
It applies to materials ready for normal use, unmodified or modified by colourants, additives, fillers, etc.
This part of IS0 2580 does not apply to materials
a) with an lzod impact strength of less than 3 kJ/m2;
b) containing more than 5 % (m/m) of comonomers other than those mentioned in 1.3;
c) containing less than 40 % (m/m) of butadiene in the elastomer of the elastomeric phase.
1.4 It is not intended to imply that materials having the same designation give necessarily the same performance.
This part of IS0 2580 does not provide engineering data, performance data or data on processing conditions which
may be required to specify a material for a particular application and/or method of processing.
If such additional properties are required, they shall be determined in accordance with the test methods specified in
part 2 of this International Standard, if suitable.
1

---------------------- Page: 9 ----------------------

SIST EN ISO 2580-1:2000
@ IS0
ISO2580=1:1997(E)
1.5 In order to specify a thermoplastic material for a particular application or to ensure reproducible processing,
additional requirements may be given in data block 5 (see clause 3, introductory paragraph).
2 Normative references
The following standards contain provisions which, through reference in this text, constitute provisions of this part of
IS0 2580. At the time of publication, the editions indicated were valid. All standards are subject to revision, and
parties to agreements based on this part of IS0 2580 are encouraged to investigate the possibility of applying the
most recent editions of the standards indicated below. Members of IEC and IS0 maintain registers of currently valid
International Standards.
IS0 1043-l :1997, Plastics - Symbols and abbreviated terms - Patf I: Basic polymers and their special
characteristics.
Part 2: Fillers and reinforcing materials.
IS0 1043.2:1988, Plastics - Symbols -
Determination of nitrogen content.
IS0 1656:1996, Rubber, raw natural, and rubber latex, natural -
- Acrylonitrile/butadiene/styrene (A BS) moulding and extrusion materials - Part 2:
IS0 2580.2:1994, Plastics
Preparation of test specimens and determination of properties.
3 Designation system
The designation system for thermoplastics is based on the following standardized pattern:
Designation
Identity block
I
Individual-item block
International
Description block
(optional) Standard
Data Data Data Data Data
number
block block block block block
block
1 2 3 4 5
The designation consists of an optional description block, reading “Thermoplastics”, and an identity block
comprising the International Standard number and an individual-item block. For unambiguous designation, the
individual-item block is subdivided into 5 data blocks comprising the following information:
- Data block 1: Identification of the plastic by its symbol ABS in accordance with IS0 1043-I and information
about the polymerization process or composition of the polymer (see 3.1).
- Data block 2: Position 1: Intended application or method of processing (see 3.2).
Positions 2 to 8: Important properties, additives and supplementary information (see 3.2).
- Data block 3: Designatory properties (see 3.3).
- Data block 4: Fillers or reinforcing materials and their nominal content (see 3.4).
F
...
