This standard specifies the characteristics of screws with 100° countersunk head, with six lobe recess, short thread, in heat resisting nickel base alloy NI-PH2601 (Inconel 718), for aerospace applications.
Luft- und Raumfahrt - 100°-Senkschrauben, kurzes Gewinde, Sechs-Bogenzahn, aus hochwarmfester Nickelbasislegierung NI-PH2601 (Inconel 718) - Klasse: 1 270 MPa (bei Raumtemperatur) / 650 °C
Diese Norm legt die Eigenschaften für 100°-Senkschrauben mit Sechs-Bogenzahn und kurzem Gewinde aus
hochwarmfester Nickelbasislegierung NI-PH2601 (Inconel 718) zur Verwendung in der Luft- und Raumfahrt
fest.
Série aérospatiale - Vis, 100° à tête fraisée, à filetage court, à empreinte six lobes, en alliage résistant à chaud à base de nickel NI-PH2601 (Inconel 718) - Classification : 1 270 Mpa (à température ambiante) / 650°C
Aeronavtika - Vijaki, 100° ugrezna glava, šestzoba vdolbina, kratek navoj, iz toplotnoodporne zlitine na nikljevi osnovi NI-PH2601 (Inconel 718) - Klasifikacija: 1270 MPa (pri temperaturi okolice)/650 °C
General Information
- Status
- Published
- Publication Date
- 30-Jun-2009
- Withdrawal Date
- 30-Jan-2010
- Technical Committee
- ASD-STAN - Aerospace
- Drafting Committee
- ASD-STAN/D 3 - Mechanical
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 21-Jan-2025
- Completion Date
- 28-Jan-2026
Relations
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Overview
EN 4635:2009 is a CEN aerospace standard that specifies the characteristics of screws with a 100° countersunk head, six‑lobe recess, short thread, made from the heat‑resisting nickel‑base alloy NI‑PH2601 (Inconel 718). The screws are classified for a tensile strength of 1270 MPa at ambient temperature and for use up to 650 °C. The standard was prepared by ASD‑STAN and approved by CEN in 2009.
Key topics
- Product configuration and dimensions: detailed dimensional tables and a figure define head geometry, recess, thread lengths and mass. Sizes covered include MJ3 to MJ12 thread designations (see Table 1 in the standard).
- Material: specification of the heat‑resisting nickel‑base alloy NI‑PH2601 (Inconel 718) and reference to EN 2952 for bar material and mechanical properties.
- Mechanical classification: tensile classification 1270 MPa (ambient) / 650 °C to guide selection for high‑temperature aerospace applications.
- Threads and tolerances: MJ thread series conforming to ISO/EN thread standards (e.g., ISO 3353‑1, ISO 5855‑2); tolerances of form and position according to ISO 7913 (values quoted in micrometres, applicable prior to surface treatment).
- Surface treatment and corrosion control: references to EN 2516 for passivation and decontamination of nickel base alloys.
- Designation and marking: standard gives an example designation format (e.g., EN4635‑040003) and references EN 2424 for marking requirements.
- Related technical specification: EN 2583 referenced for detailed technical specification.
Applications
- Fasteners for aerospace structures and engine components requiring high strength and resistance to elevated temperatures (hot sections, exhaust systems, turbine housings).
- Situations demanding a flush countersunk finish with a secure six‑lobe (Torx‑style) recess, short thread engagement and high fatigue/creep resistance.
- Use cases where material traceability, marking and standardized tolerance control are required by procurement and certification processes.
Who uses this standard
- Aerospace fastener manufacturers and forging suppliers
- Design and stress engineers specifying hardware for high‑temperature zones
- Quality assurance, inspection and procurement teams verifying conformity (marking, material, thread tolerances)
- Maintenance and overhaul organizations requiring correct replacement parts
Related standards
- EN 2952 (NI‑PH2601 bar material), EN 2583 (technical specification), EN 2516 (passivation), EN 2424 (marking)
- ISO 3353‑1, ISO 5855‑2 (threads), ISO 7913 (form/position tolerances), EN 3911 (six‑lobe recess geometry)
Keywords: EN 4635:2009, aerospace screws, Inconel 718, NI‑PH2601, 100° countersunk head, six‑lobe recess, high‑temperature fasteners, MJ threads.
