(Main)Aerospace series - Fluid fittings, flanged, straight - Sealing by O-ring for 0,8 mm thick tubes
Aerospace series - Fluid fittings, flanged, straight - Sealing by O-ring for 0,8 mm thick tubes
The purpose of this standard is to define the characteristics of the fluid fittings, flanged, straight, sealing by O ring, for 0,8 mm thick tubes.
NOTE Flanged fitting installation hole and assembly, see EN 3633 and TR 3634.
Luft- und Raumfahrt - Rohrverbindungen mit Flansch, gerade - O-Ring-Dichtung für Rohre mit einer Dicke von 0,8 mm
Der Zweck dieser Norm ist die Festlegung der Eigenschaften von geraden Rohrverbindungen mit Flansch und O Ring Dichtung für Rohre mit einer Dicke von 0,8 mm.
ANMERKUNG Einbaulöcher und Einbaurichtlinien für Rohrverbindungen mit Flansch siehe EN 3633 und TR 3634.
Série aérospatiale - Raccords à bride, droits - Etanchéité par joint torique pour tubes de 0,8 mm d'épaisseur
Aeronavtika - Cevna napeljava, s prirobnicami, ravna - Tesnilke O za cevi z debelino 0,8 mm
General Information
- Status
- Published
- Publication Date
- 08-Apr-2008
- Withdrawal Date
- 30-Oct-2008
- Technical Committee
- ASD-STAN - Aerospace
- Drafting Committee
- ASD-STAN/D 3 - Mechanical
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 21-Jan-2024
- Completion Date
- 11-Feb-2026
Relations
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Overview
EN 3630:2008 is a CEN aerospace standard that defines the characteristics of flanged, straight fluid fittings sealed by an O‑ring specifically for tubes with a wall thickness of 0.8 mm. The standard sets out the required configuration, dimensions, tolerances and material requirements for these fittings to ensure interchangeability, reliable sealing and compliance across aerospace fluid systems.
Key topics and requirements
- Scope and purpose: Specifies characteristics for flanged, straight fittings with O‑ring sealing for 0.8 mm thick tubes used in aerospace fluid systems.
- Configuration & dimensions: Detailed geometrical configuration, dimensional tables and tolerances are given (referenced in Figures 1–3 and Tables 1–3 of the standard).
- Material: Specifies use of FE‑PA13 steel in the softened condition according to EN 2462.
- Sealing method: O‑ring sealing details for flange interfaces to ensure fluid tightness.
- Designation & marking: Defines a standard designation format (example: EN 3630 - 140 - 2) and mandates marking per EN 2424 (Style A) as shown in the normative figures.
- Related assembly guidance: Installation hole and assembly practices are covered by EN 3633 and TR 3634 - users must consult these for correct installation and weld‑lip geometry (EN 3635).
- Compliance: The document is a European Standard approved by CEN and intended for adoption as a national standard by member bodies.
Practical applications
- Use EN 3630 when designing, procuring or manufacturing aerospace fluid fittings for hydraulic, pneumatic or fuel sub‑systems where small‑wall‑thickness tubing (0.8 mm) is employed.
- Ensures compatibility and interchangeability of flanged straight fittings across suppliers and airframe platforms.
- Guides quality assurance and inspection teams on marking, dimensional acceptance and material verification.
- Supports maintenance and repair organizations in identifying correct replacement fittings and ensuring correct O‑ring sealing interfaces.
Who should use this standard
- Aerospace design and systems engineers specifying fluid line components.
- Manufacturers and subcontractors producing flanged O‑ring fittings.
- Procurement specialists sourcing standardized fittings.
- Quality, test and maintenance teams ensuring regulatory and interchangeability compliance.
Related standards
- EN 3633 - Installation hole for fluid fittings, flanged (installation geometry)
- TR 3634 - Assembly recommendations for flanged fluid fittings
- EN 3635 - Weld lip geometrical configuration
- EN 2462 - Material specification (FE‑PA13)
- EN 2424 - Marking of aerospace products
Keywords: EN 3630:2008, aerospace fluid fittings, flanged straight fittings, O‑ring sealing, 0.8 mm tube, FE‑PA13, CEN, EN 3633, TR 3634.
