ASTM F2510/F2510M-22

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: F2510/F2510M − 17 F2510/F2510M − 22 An American National Standard
Standard Specification for
Resilient Connectors Between Reinforced Concrete Manhole
Structures and Corrugated Dual- and Triple-Wall
Polyethylene and Polypropylene Pipes
This standard is issued under the fixed designation F2510/F2510M; the number immediately following the designation indicates the year
of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval.
A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope*
1.1 This specification covers the design, material, and minimum performance requirements of resilient connectors used for
connections between reinforced concrete structures conforming to Specifications C478C478/C478M and C913 to annular
corrugated profile wall high density polyethylene (HDPE) and polypropylene (PP) drainage and sewer pipe conforming to
AASHTO M252, M294, and M330 or Specifications F2306/F2306M, F2648/F2648M, F2736F2763/F2763M, F2763F2764/
F2764M, F2764/F2764MF2881/F2881M, and F2947/F2947M.
1.1.1 These connectors are designed to provide a positive seal between the pipe and manholes or other structures subjected to
internal and external hydrostatic pressures less than 10.8 psi [74 KPa].
1.1.2 Testing under this standard is limited to hydrostatic pressures. Alternate air and vacuum pressure testing involve unique
testing protocols and are not addressed under this standard.
1.1.3 Testing under this standard is conducted in a laboratory as a proof of design certification. Actual field performance testing
would be accomplished and accepted under individual project performance standards or pipeline acceptance criteria, which is
outside the scope of this standard.
NOTE 1—Infiltration or exfiltration quantities for an installed system are dependent upon many factors other than the connections between manhole
structures and pipe, and allowable quantities must be covered by other specifications and suitable testing of the installed pipeline and system.
NOTE 2—This specification may be applied to other types of plastic drainage pipe. Consult with manufacturer of pipe for applicability to this standard.
1.2 The values stated in either inch-pound units or SI units are to be regarded separately as standard. Within the text the SI units
are shown in brackets. The values stated in each system may not be exact equivalents: therefore, each system shall be used
independently of the other. Combining values from the two systems may result in non-conformance with the standard.
1.3 The following precautionary caveat pertains only to the test methods portion, Section 7. This standard does not purport to
address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish
appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use. For
a specific precaution statement, see 7.2.3.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
This specification is under the jurisdiction of ASTM Committee F17 on Plastic Piping Systems and is the direct responsibility of Subcommittee F17.20 on Joining.
Current edition approved Dec. 1, 2017Jan. 15, 2022. Published February 2018March 2022. Originally approved in 2006. Last previous edition approved in 20132017 as
F2510/F2510M–07 (2013). –17. DOI: 10.1520/F2510_F2510M-17.10.1520/F2510_F2510M-22.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
F2510/F2510M − 22
2. Referenced Documents
2.1 ASTM Standards:
A493 Specification for Stainless Steel Wire and Wire Rods for Cold Heading and Cold Forging
A666 Specification for Annealed or Cold-Worked Austenitic Stainless Steel Sheet, Strip, Plate, and Flat Bar
C478C478/C478M Specification for Circular Precast Reinforced Concrete Manhole Sections (Metric) C0478_C0478M
C822 Terminology Relating to Concrete Pipe and Related Products
C913 Specification for Precast Concrete Water and Wastewater Structures
D624 Test Method for Tear Strength of Conventional Vulcanized Rubber and Thermoplastic Elastomers
D746 Test Method for Brittleness Temperature of Plastics and Elastomers by Impact
D1566 Terminology Relating to Rubber
F412 Terminology Relating to Plastic Piping Systems
F477 Specification for Elastomeric Seals (Gaskets) for Joining Plastic Pipe
F2306/F2306M Specification for 300 mm to 1500 mm [12 in. to 60 in.] Annular Corrugated Profile-Wall Polyethylene (PE) Pipe
and Fittings for Non-Pressure Gravity-Flow Storm Sewer and Subsurface Drainage Applications
F2648/F2648M Specification for 2 to 60 inch [50 to 1500 mm] Annular Corrugated Profile Wall Polyethylene (PE) Pipe and
Fittings for Land Drainage Applications
F2736 Specification for 6 to 30 in. (152 To 762 mm) Polypropylene (PP) Corrugated Single Wall Pipe And Double Wall Pipe
(Withdrawn 2018)
F2763F2763/F2763M Specification for 12 to 60 in. [300 to 1500 mm] Dual and Triple Profile-Wall Polyethylene (PE) Pipe and
Fittings for Sanitary Sewer Applications
F2764/F2764M Specification for 6 to 60 in. [150 to 1500 mm] Polypropylene (PP) Corrugated Double and Triple Wall Pipe and
Fittings for Non-Pressure Sanitary Sewer Applications
F2881/F2881M Specification for 12 to 60 in. [300 to 1500 mm] Polypropylene (PP) Dual Wall Pipe and Fittings for
Non-Pressure Storm Sewer Applications
F2947/F2947M Specification for 150 to 1500 mm [6 to 60 in.] Annular Corrugated Profile-Wall Polyethylene (PE) Pipe and
Fittings for Sanitary Sewer Applications
2.2 Other Standards:
M252 Standard Specification for Corrugated Polyethylene Drainage Pipe 75 to 250 mm Diameter
M294 Standard Specification for Corrugated Polyethylene Pipe, 300- to 1500-mm (12- to 60-in.) Diameter
M330 Standard Specification for Polypropylene Pipe, 300- to 1500-mm (12- to 60-in.) Diameter
3. Terminology
3.1 Definitions of Terms Specific to This Standard:
3.1.1 Terms relating to plastics and rubber shall be as defined in Terminologies F412 and D1566, respectively.
3.1.2 Terms relating to precast concrete manholes and related products shall be as defined in Terminology C822 and as modified
in 3.2, 3.3, and 3.4.
3.2 connector—the entire assembly including resilient seals and metallic or nonmetallic mechanical devices, if any, used therein.
3.3 pipe—the inlet or outlet pipe connected to the manhole.
3.4 pipe stub—a short section of pipe, installed in the structure as an inlet or outlet pipe, for future connection.
4. Materials and Manufacture
4.1 All materials shall conform to the following requirements:
4.1.1 Resilient materials for connectors and filler rings shall be manufactured from natural or synthetic rubber and shall conform
to the requirements prescribed in Specification F477, Section 6, Low Head Physical Requirements for Elastomeric Seals for Plastic
Pipe.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
F2510/F2510M − 22
4.1.2 Low Temperature Brittle Point. Resilient materials for connectors shall display no fracture at –40 ºF [–40 ºC]–40 °F [–40 °C]
when tested in accordance with Test Method D746.
4.1.3 Tear Resistance. Resilient materials for connectors shall meet a minimum tear resistance of 200 lbf/inlbf/in. [34 kN/m] when
tested in accordance with Test Method D624 with a nicked Die B.
4.2 Mechanical Devices—Expansion rings, tension bands, and take-up devices used for mechanically compressing the resilient
portion of the connector against the pipe, manhole or structure shall be made from a material or materials in combinat
...
