SIST EN 300 175-4 V2.3.1:2010
(Main)Digital Enhanced Cordless Telecommunications (DECT) - Common Interface (CI) - Part 4: Data Link Control (DLC) layer
- Abstract
The present document is one of the parts of the specification of the Digital Enhanced Cordless Telecommunications (DECT) Common Interface (CI). The present document specifies the Data Link Control (DLC) layer. The DLC layer is part 4 of the DECT CI standard and layer 2b of the DECT protocol stack.Two planes of operation are specified for this DLC (sub)layer. These planes are called the Control plane (C-plane) and the User plane (U-plane). The C-plane is mostly concerned with the DECT signalling aspects. It provides a reliable point-to-point service that uses a link access protocol to offer error protected transmission of Network (NWK) layer messages. The C-plane also provides a separate point-to-multipoint (broadcast) service (Lb). The U-plane is only concerned with end-to-end user information. This plane contains most of the application dependent procedures of DECT. Several alternative services (both circuit-mode and packet-mode) are defined as a family of independent entities. Each service provides one or more point-to-point U-plane data links, where the detailed characteristics of those links are determined by the particular needs of each service. The defined services cover a wide range of performance, from "unprotected with low delay" for speech applications to "highly protected with variable delay", for local area network applications.
- Status
- Published
- Publication Date
- 08-Sep-2010
- Technical Committee
- MOC - Mobile Communications
- Current Stage
- 6060 - National Implementation/Publication (Adopted Project)
- Start Date
- 11-Aug-2010
- Due Date
- 16-Oct-2010
- Completion Date
- 09-Sep-2010
Buy Documents
ETSI EN 300 175-4 V2.3.0 (2010-02) - Digital Enhanced Cordless Telecommunications (DECT); Common Interface (CI); Part 4: Data Link Control (DLC) layer
ETSI EN 300 175-4 V2.3.1 (2010-06) - Digital Enhanced Cordless Telecommunications (DECT); Common Interface (CI); Part 4: Data Link Control (DLC) layer
SIST EN 300 175-4 V2.3.1:2010 is the ETSI part of the DECT Common Interface that specifies the Data Link Control (DLC) layer. It defines how the DLC layer carries DECT signalling on the Control plane (C-plane) and user information on the User plane (U-plane) between the Medium Access Control (MAC) layer and the Network (NWK) layer.
What does SIST EN 300 175-4 V2.3.1:2010 specify?
SIST EN 300 175-4 V2.3.1:2010 specifies the DLC layer of the Digital Enhanced Cordless Telecommunications (DECT) Common Interface, which is layer 2b of the DECT protocol stack. It covers both the C-plane, used mainly for signalling and broadcast, and the U-plane, used for end-to-end user information.
The document is organized into an overview of the DLC layer, C-plane service characteristics, C-plane frame structures and procedures, primitives, management procedures, U-plane service characteristics, and U-plane frame structures. In practice, that means the standard tells implementers how DLC links are identified, framed, controlled, managed, and delivered to upper and lower layers.
What are the key requirements of SIST EN 300 175-4 V2.3.1:2010?
SIST EN 300 175-4 V2.3.1:2010 splits DLC operation into two planes. The C-plane provides reliable point-to-point delivery of Network (NWK) layer messages and a separate broadcast service Lb, while the U-plane carries user data through several independent services with different delay and protection profiles. This separation matters because signalling and user traffic are handled with different link behaviors.
- Clause 6 and clause 7 define the C-plane frame structure and field coding. Frames use address, control, length indicator, fill, and checksum fields, and invalid frames are discarded without notification. In practice, receivers must reject bad frames silently and rely on higher-layer recovery.
- Clause 7.3 defines the addressing and link identifiers. SAPI selects the service access point, LLN identifies the LAPC entity, and DLI and DLEI combine LLN with MAC connection information. This is what lets an implementation route each frame to the correct logical link.
- Clause 7.11 defines the command and response set: I, RR, RNR, REJ, SABM, DM, UI, DISC and UA. These cover acknowledged transfer, busy handling, retransmission, re-establishment, disconnect, and unacknowledged transfer.
- Clause 9 defines the operating procedures for class A, class B, class U, and broadcast operation. It covers link establishment, release, suspension, resumption, connection handover, and exception handling. That is the part implementers use to decide when to acknowledge, retransmit, pause, or restart a link.
- Clauses 8 and 10 define primitives and management procedures. They include DL_ESTABLISH, DL_DATA, DL_UNIT_DATA, broadcast primitives, MAC connection management, routing, and ciphering management. These are the interfaces used to connect DLC to MAC, NWK, and the interworking unit.
- Clauses 11 and 12 define the U-plane services and frame types. They include LU1 TRUP, LU2 FREL, LU3 FSWI, LU4 FEC, LU5 BRAT, LU7, LU10 EFREL, and LU16 ESC, together with FU1, FU2, FU3, FU4, FU5, FU6 and FU10 frame structures. In practice, these clauses tell a designer how much protection, delay, buffering, sequencing, and segmentation each bearer type provides.
What terms does SIST EN 300 175-4 V2.3.1:2010 define?
- Digital Enhanced Cordless Telecommunications (DECT): the cordless telecommunications system whose Common Interface is standardized here.
- Data Link Control (DLC): the DECT layer between MAC and NWK that carries signalling and user data.
- Control plane (C-plane): the DLC plane for signalling, reliable point-to-point transfer, and broadcast Lb.
- User plane (U-plane): the DLC plane for end-to-end user information and application-dependent services.
- Link Access Protocol C-plane (LAPC): the C-plane protocol entity that handles C-plane link procedures.
- Lower Layer Management Entity (LLME): the management entity that controls MAC connection and DLC management functions.
- Service Access Point Identifier (SAPI): the field that selects the higher-layer service associated with a frame.
- Logical Link Number (LLN): the number that identifies a LAPC instance for a given link.
Who uses SIST EN 300 175-4 V2.3.1:2010?
SIST EN 300 175-4 V2.3.1:2010 is used by DECT terminal, base station, chipset, and protocol engineers who implement the DLC layer. It is also used by interworking unit developers who map DECT services to other data systems.
Quality teams and test labs use it to verify frame formats, link setup and release, retransmission behavior, broadcast handling, and error handling. Buyers and system integrators use it to check whether a device supports the DECT link service they need for signalling, speech, or data.
Which standards are used with SIST EN 300 175-4 V2.3.1:2010?
- EN 300 175-1 - DECT overview and shared definitions.
- EN 300 175-2 - the DECT Physical Layer (PHL).
- EN 300 175-3 - the Medium Access Control (MAC) layer and lower-layer primitives.
- EN 300 175-5 - the Network (NWK) layer and higher-layer information mapping.
- EN 300 175-6 - identities and addressing.
- EN 300 175-8 - speech and audio coding and transmission.
- EN 301 649 - DECT Packet Radio Service (DPRS).
- ITU-T Q.920 and Q.921 - link-layer conventions used for C-plane field handling.
- ITU-T V.42 and V.110 - data procedures and support for data terminal equipment.
- ITU-T X.200 and X.210 - OSI service and layering terminology.
- ISO/IEC 8073 - the checksum basis used for the link signature calculation.
What does the SIST EN 300 175-4 V2.3.1:2010 document contain?
SIST EN 300 175-4 V2.3.1:2010 contains detailed bit-field definitions, frame layouts, and state procedures for DLC operation. It describes the coding of C-plane addresses and control fields, the primitive set between DLC, MAC, NWK, and the interworking unit, and the management actions for connections, routing, ciphering, and handover.
For the U-plane, it gives service-specific procedures for buffering, segmentation, rate adaptation, retransmission, and integrity handling across several bearer types. The document uses tables and figures to define frame sizes, channel mappings, control octets, sequence handling, and transmission behavior in a way that implementers can turn into protocol logic and conformance tests.
Buy Documents
ETSI EN 300 175-4 V2.3.0 (2010-02) - Digital Enhanced Cordless Telecommunications (DECT); Common Interface (CI); Part 4: Data Link Control (DLC) layer
ETSI EN 300 175-4 V2.3.1 (2010-06) - Digital Enhanced Cordless Telecommunications (DECT); Common Interface (CI); Part 4: Data Link Control (DLC) layer
Get Certified
Connect with accredited certification bodies for this standard
BSI Group
BSI (British Standards Institution) is the business standards company that helps organizations make excellence a habit.
NYCE
Mexican standards and certification body.
ANCE
Mexican certification and testing association.
Sponsored listings
Frequently Asked Questions
SIST EN 300 175-4 V2.3.1:2010 is a standard published by the Slovenian Institute for Standardization (SIST). Its full title is "Digital Enhanced Cordless Telecommunications (DECT) - Common Interface (CI) - Part 4: Data Link Control (DLC) layer". This standard covers: The present document is one of the parts of the specification of the Digital Enhanced Cordless Telecommunications (DECT) Common Interface (CI). The present document specifies the Data Link Control (DLC) layer. The DLC layer is part 4 of the DECT CI standard and layer 2b of the DECT protocol stack.Two planes of operation are specified for this DLC (sub)layer. These planes are called the Control plane (C-plane) and the User plane (U-plane). The C-plane is mostly concerned with the DECT signalling aspects. It provides a reliable point-to-point service that uses a link access protocol to offer error protected transmission of Network (NWK) layer messages. The C-plane also provides a separate point-to-multipoint (broadcast) service (Lb). The U-plane is only concerned with end-to-end user information. This plane contains most of the application dependent procedures of DECT. Several alternative services (both circuit-mode and packet-mode) are defined as a family of independent entities. Each service provides one or more point-to-point U-plane data links, where the detailed characteristics of those links are determined by the particular needs of each service. The defined services cover a wide range of performance, from "unprotected with low delay" for speech applications to "highly protected with variable delay", for local area network applications.
The present document is one of the parts of the specification of the Digital Enhanced Cordless Telecommunications (DECT) Common Interface (CI). The present document specifies the Data Link Control (DLC) layer. The DLC layer is part 4 of the DECT CI standard and layer 2b of the DECT protocol stack.Two planes of operation are specified for this DLC (sub)layer. These planes are called the Control plane (C-plane) and the User plane (U-plane). The C-plane is mostly concerned with the DECT signalling aspects. It provides a reliable point-to-point service that uses a link access protocol to offer error protected transmission of Network (NWK) layer messages. The C-plane also provides a separate point-to-multipoint (broadcast) service (Lb). The U-plane is only concerned with end-to-end user information. This plane contains most of the application dependent procedures of DECT. Several alternative services (both circuit-mode and packet-mode) are defined as a family of independent entities. Each service provides one or more point-to-point U-plane data links, where the detailed characteristics of those links are determined by the particular needs of each service. The defined services cover a wide range of performance, from "unprotected with low delay" for speech applications to "highly protected with variable delay", for local area network applications.
SIST EN 300 175-4 V2.3.1:2010 is classified under the following ICS (International Classification for Standards) categories: 33.070.30 - Digital Enhanced Cordless Telecommunications (DECT); 35.100.20 - Data link layer. The ICS classification helps identify the subject area and facilitates finding related standards.
SIST EN 300 175-4 V2.3.1:2010 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
